100*50*5*7.5mm Hot Rolled Stainless Steel Channel Grade 304 316L Stainless Steel C Channel
Product Details
| Shape | U Channel | Technique | Hot Rolled |
|---|---|---|---|
| Surface Treatment | Bright | Size | 100*50*5*7.5mm |
| Grade | 304 316L | Angle Bar Size | 30*30*3 - 200*200*10mm |
| Channel Bar Size | 50*30*3 - 200*100*10mm | Length | 6m |
| Thickness Range | 3-12mm | Weight Per Meter | 1.79-35.8kg |
| Material | Stainless Steel | Angle Bar Weight | 0.894-15.0kg |
| Channel Bar Weight | 1.79-35.8kg | Processing Service | Cutting |
| Packing | Waterproof Paper Or Wooden Pallets | ||
| Highlight | 100*50*5*7.5mm Stainless Steel Channel,Grade 304 316L Stainless Steel C Channel,Hot Rolled Stainless Steel U Channel |
||
Product Description
Stainless Steel Channels - 100×50×5×7.5mm Grade 304/316L
High-quality stainless steel C channels manufactured to exacting standards for industrial and construction applications.
Product Specifications
- Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
- Grades Available: 201, 304, 310S, 316L, 321, 2205, etc.
- Standards: ASTM, GB, DIN
- Angle Bar Sizes: 30×30×3 - 200×200×10mm × 6m length
- Channel Bar Sizes: 50×30×3 - 200×100×10mm × 6m length
- Services: Custom cutting available
- Packing: Waterproof paper wrapping or wooden pallets
- Brand: TSINGSHAN
Stainless Steel Angle Bar - Standard Sizes & Weights
| Size A×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm |
|---|---|---|---|---|---|---|---|---|
| 20×20 | 0.894 | 1.13 | 1.38 | |||||
| 25×25 | 1.13 | 1.45 | 1.77 | 2.06 | ||||
| 30×30 | 1.37 | 1.77 | 2.17 | 2.53 | ||||
| 35×35 | 1.61 | 2.09 | 2.57 | 3.01 | ||||
| 40×40 | 1.85 | 2.41 | 2.97 | 3.49 | ||||
| 45×45 | 2.12 | 2.76 | 3.40 | 4.00 | ||||
| 50×50 | 2.36 | 3.07 | 3.79 | 4.46 | 5.13 | 5.76 | 6.42 | 7.06 |
| 60×60 | 4.58 | 5.42 | 6.24 | 7.03 | ||||
| 63×63 | 5.03 | 5.95 | 6.84 | 7.71 | 8.60 | 9.48 | ||
| 70×70 | 5.42 | 6.42 | 7.39 | 8.34 | 9.31 | 10.3 | ||
| 75×75 | 5.82 | 6.89 | 7.95 | 8.97 | 10.0 | 11.1 | ||
| 80×80 | 7.37 | 8.50 | 9.61 | 10.7 | 11.8 | |||
| 90×90 | 8.33 | 9.65 | 11.90 | 12.2 | 13.4 | |||
| 100×100 | 9.28 | 10.8 | 12.20 | 13.6 | 15.0 |
Weights shown in kg per meter
Stainless Steel Channel Bar - Standard Sizes & Weights
| Size H×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | 12mm |
|---|---|---|---|---|---|---|---|---|---|
| 40×20 | 1.79 | ||||||||
| 50×25 | 2.27 | ||||||||
| 60×30 | 2.74 | 3.56 | 4.37 | 5.12 | |||||
| 70×35 | 3.23 | 4.21 | 5.17 | 6.08 | |||||
| 80×40 | 3.71 | 4.84 | 5.96 | 7.03 | |||||
| 90×45 | 4.25 | 5.55 | 6.83 | 8.05 | |||||
| 100×50 | 4.73 | 6.18 | 7.62 | 8.98 | 10.3 | 11.7 | 13.0 | 41.2 | |
| 120×60 | 9.20 | 10.9 | 12.6 | 14.2 | |||||
| 130×65 | 10.1 | 11.9 | 13.8 | 15.5 | 17.3 | 19.1 | |||
| 140×70 | 12.9 | 14.9 | 16.8 | 18.8 | 20.7 | ||||
| 150×75 | 13.9 | 16.0 | 18.1 | 20.2 | 22.2 | 26.3 | |||
| 160×80 | 14.8 | 17.1 | 19.3 | 21.6 | 23.8 | 28.1 | |||
| 180×90 | 16.7 | 19.4 | 22.0 | 24.5 | 27.0 | 32.0 | |||
| 200×100 | 18.6 | 21.6 | 24.5 | 27.4 | 30.2 | 35.8 |
Weights shown in kg per meter
About Our Company
Our company is a comprehensive stainless steel enterprise specializing in wholesale distribution, material processing, storage, and supply chain management. Located in Wuxi - the heart of China's stainless steel trading industry - we have invested over 10 million yuan and achieve annual sales exceeding 300 million yuan.
We maintain long-term partnerships with leading steel mills including Taiyuan Steel, East Steel, Zhang Pu Steel, Hongxing Steel, Zhejiang Qingshan Steel, and others. We also distribute premium imported stainless steel plates from Sweden, North America, South Africa, Japan, and South Korea.
Material Range: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L, high-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series.
Processing Capabilities: Plasma cutting, coil material opening, laser cutting, 8K mirror finishing, grinding, wire drawing, film coating, titanium plating, plate cutting, strip processing, and custom fabrication.
Specialized Services: Thick plate cutting (up to 150mm), circular cutting, square cutting, shaped cutting, casting parts, forging parts, and custom orders to meet specific customer requirements.
Product Gallery
Applications
Stainless steel angle bars and channel bars are essential structural components used in:
- Frame structures for high-voltage power transmission towers
- Main beam frameworks for steel structure bridges
- Columns and booms for construction site tower cranes
- Columns and beams for industrial workshop construction
- Support structures for air conditioning and solar power systems
- Building structures including house beams and ship beams
- Industrial furnace construction and support systems
Our stainless steel angle bars and channel bars are widely applied across multiple industries including construction, shipbuilding, industrial manufacturing, and infrastructure development.
