Prime 321 Stainless Steel Plate Hot Rolled with 3.0mm - 150.0mm Thickness EN10088-1

Certification	AISI
Minimum Order Quantity	50 kg
Price	US $2.65-4.85 / kg

Product Details

Model NO.	321	Shape	Flat
Technique	Cold Rolled	Surface Treatment	Bright
Thickness Range	10.0mm - 150.0mm	Width Range	500-2000mm
Length Range	1000-6000mm	Surface Finish	No.1 / No.4 / BA / 2B/HL/mirror/polished/brushed
Carbon Content	0.08 Max	Manganese Content	2.00 Max
Silicon Content	0.75 Max	Chromium Content	17.0 - 19.0
Nickel Content	9.0 - 12.0	Titanium Content	5(C+N) - 0.70
Production Capacity	50000kgs
Highlight	321 Stainless Steel Plate , Hot Rolled Stainless Steel Plate , 3.0mm - 150.0mm Thickness SS Plate

Leave a Message

Product Description

Prime Hot Rolled 321 Stainless Steel Plate

Thickness: 3.0mm - 150.0mm | Standard: EN10088-1

Product Overview

Material: Original Type 321 Stainless Steel Plate
Thickness Range: 10.0mm - 150.0mm
Processing Services: Waterjet Cutting, Laser Cutting
Surface Finish: Hot Rolled NO.1
Brands: TISCO, BAOSTEEL

Technical Specifications

Commodity	321 Stainless Steel Plate
Main Grades	201, 202, 304, 304L, 316, 316L, 317L, 310S, 321, 904L, 410, 430, 2205, 2507, 904L
Brand	TISCO, BAOSTEEL, POSCO, JISCO, LISCO
Certification	SGS, BV, IQI, TUV, ISO
Thickness	10.0-150mm or custom requirements
Width	500-2000mm or custom requirements
Length	1000-6000mm or custom requirements
Surface Options	No.1 / No.4 / BA / 2B / HL / Mirror / Polished / Brushed
Standard	JIS, AISI, ASTM, GB, DIN
Delivery Time	Approximately 10 days
Minimum Order Quantity	1 Ton

About 321 Stainless Steel

Titanium-bearing stainless steels are stabilized against carbide precipitation and designed for operation within the damaging temperature range where carbide precipitation develops. In this type of steel, carbon combines preferentially with titanium to form harmless titanium carbide, leaving chromium in solution to maintain full corrosion resistance. Type 321 is basic type 304 modified by adding titanium in an amount at least 5 times the carbon plus nitrogen contents.

Chemical Composition

Element	Min (%)	Max (%)
C	-	0.08
Mn	-	2.00
Si	-	0.75
P	-	0.045
S	-	0.030
Cr	17.0	19.0
Ni	9.0	12.0
N	-	0.10
Ti	5(C+N)	0.70

Key Features

Immune to intergranular corrosion when heated within carbide precipitation range
Titanium addition eliminates chromium carbide formation at grain boundaries
Superior high temperature properties compared to 304 or 304L
Suitable for intermittent heating up to 1500°F, continuous service to 1650°F
Excellent weldability in field applications
Type 321H variant offers higher carbon content for improved high temperature creep properties

Applications

Aircraft exhaust manifolds
Expansion joints and bellows
Furnace components
Heating element tubing
Heat exchangers
High temperature mineral processing screens
Spiral welded tubes for burner pipes and flues

Technical Background

Grades 321 and 347 are austenitic 18/8 steels (Grade 304) stabilized by titanium (321) or niobium (347) additions. These grades resist intergranular corrosion after heating within the carbide precipitation range of 425-850°C. Grade 321 is ideal for applications up to 900°C, combining high strength, scaling resistance, phase stability, and subsequent aqueous corrosion resistance.

Grade 321H provides improved high temperature strength with higher carbon content. While 321 offers excellent forming and welding characteristics with outstanding toughness even at cryogenic temperatures, it doesn't polish well for decorative applications. Grade 304L is often preferred for resistance to intergranular corrosion after welding, but 321 maintains superior hot strength above 500°C.

Alternative Grade Comparison

Alternative Grade	Selection Criteria
304L	When requirement is for intergranular corrosion resistance without high temperature strength needs
3CR12	For mild high temperature environments up to approximately 600°C
304H	For mild high temperature environments up to approximately 800°C
310	For operating environments up to 1100°C - exceeding 321 capabilities
S30815 (253MA)	For operating environments up to 1150°C - exceeding 321 capabilities
