Hot Rolled 253MA Stainless Steel Plate with High Temperature Resistance and Polished Surface

Certification	AISI, ASTM
Minimum Order Quantity	100 kg
Price	US $3.65-8.85 / kg

Product Details

Model NO.	S30815 253Ma	Shape	Flat
Technique	Hot Rolled	Surface Treatment	Polished
Specification	12202440, 15003000, 15006000, 20006000mm	Width Range	600mm~2030 Mm
Thickness Range	0.1~120.0 Mm	Length Range	300~6000 Mm, Max 18000 Mm
Surface Finish	No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating, Color-coating, Embossing	Tensile Strength	600 MPa Min
Yield Strength	310 MPa Min	Elongation	40% Min
Hardness	Rockwell B 95 Max, Brinell 217 Max	Density	7800 Kg/m3
Elastic Modulus	200 GPa
Highlight	High Temperature Resistance Stainless Steel Plate , Hot Rolled 253MA Stainless Steel Plate , Polished Surface UNS S30815 Stainless Steel Plate

Leave a Message

Product Description

253MA Stainless Steel Sheet & Plate (UNS S30815, 1.4835)

253MA is a high-temperature stainless steel grade that combines excellent service properties with ease of fabrication. This austenitic stainless steel resists oxidation at temperatures up to 1150°C and provides superior performance to Grade 310 in carbon, nitrogen, and sulphur-containing atmospheres.

With relatively low nickel content, 253MA offers advantages in reducing sulphide atmospheres compared to high nickel alloys and Grade 310. The inclusion of high silicon, nitrogen, and cerium contents provides excellent oxide stability, high elevated temperature strength, and superior resistance to sigma phase precipitation.

The austenitic structure ensures excellent toughness, even at cryogenic temperatures. This grade is also known by the proprietary designation 2111HTR.

Specifications & Standards

Primary Specifications: ASME SA 182, ASME SA 213, ASTM A 240, ASTM A 276, ASTM A 312, ASTM A 479, UNS S30815, Werkstoff 1.4835

Common Stainless Steel Grade Comparison

ASTM	JIS	AISI	EN
S30100	SUS301	301	1.431
S30400	SUS304	304	1.4301
S30403	-	304L	1.4307
S31008	SUS310S	310S	1.4845
S31603	-	316L	1.4404
S32100	SUS321	321	1.4541
S41008	SUS410S	410S	-
S43000	SUS430	430	1.4016
S43932	-	-	1.451
S44400	SUS444	444	1.4521
S44500	SUS430J1L	-	-

Dimensions & Surface Finish

Available Dimensions:

Width: 600mm - 2030mm
Thickness: 0.1mm - 120.0mm
Length: 300mm - 6000mm (Maximum: 18000mm)

Surface Finishes: No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating, color-coating, embossing

Applications

Typical applications for 253MA stainless steel include:

Furnace components including burners, retorts, conveyor belts, fans
Jigs and baskets, rollers, walking beams, radiant tubes
Electric heater elements, refractory anchors, hoods, flues
Grates, expansion bellows, petrochemical and refinery tube hangers

Equivalent Materials

253MA stainless steel equivalents across various specifications:

ASTM A182 Grade FXM-19	ASTM A269 Grade TPXM-19	ASTM A580 Grade S20910
ASTM A193 Grade B8R Class 1C	ASTM A276 Grade S20910	ASTM A813 Grade TPXM-19
ASTM A193 Grade B8R Class 1D	ASTM A312 Grade TPXM-19	ASTM A814 Grade TPXM-19
ASTM A193 Grade B8RA Class 1C	ASTM A314 Grade S20910	ASTM A943 Grade TPXM-19
ASTM A194 Grade 8R	ASTM A336 Grade FXM-19	ASTM A959 Grade S20910
ASTM A194 Grade 8RA	ASTM A358 Grade A240 XM-19	ASTM A965 Grade FXM-19
ASTM A213 Grade XM-19	ASTM A403 Grade CRXM-19	AISI XM-19
ASTM A240 Grade S20910	ASTM A403 Grade WPXM-19	SAE XM-19
ASTM A249 Grade TPXM-19	ASTM A479 Grade S20910	UNS S20910

Technical Data

Chemical Composition

Element	Min (%)	Max (%)
C	0.05	0.10
Mn	-	0.80
Si	1.10	2.00
P	-	0.040
S	-	0.030
Cr	20.0	22.0
Ni	10.0	12.0
N	0.14	0.20
Ce	0.03	0.08

Mechanical Properties

Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness Rockwell B (HR B) max	Hardness Brinell (HB) max
600	310	40	95	217

Physical Properties

Density (kg/m³)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (mm/m/°C)	Thermal Conductivity (W/m.K)	Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nW.m)
7800	200	17.0 (0-100°C) 18.5 (0-600°C) 19.5 (0-1000°C)	15.0 (at 20°C) 29.0 (at 1000°C)	500	850

International Grade Comparisons

UNS No	Euronorm No	Euronorm Name	Swedish SS	Japanese JIS
S30815	1.4835	X9CrNiSiNCe21-11-2	2368	-

These comparisons are approximate only. The list is intended as a comparison of functionally similar materials not as a schedule of contractual equivalents. If exact equivalents are needed, original specifications must be consulted.

Alternative Grades

Grade	Why it might be chosen instead of 253MA
310	Carburising atmospheres require a higher nickel content
304H	Lower cost alternative, provided the operating temperature is below about 800°C
Nickel Alloys	Carburising atmospheres or temperatures above the 1100-1150°C maximum of 253MA
