Duplex Stainless Steel Plate S32205 / S31803 / S32750 Laser Cutting Any Size SS Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 2205 2507 |
| Minimum Order Quantity | 500 kgs |
| Price | 3200 - 3600 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 2205 2507 |
|---|---|---|---|
| Standard Size | 1500*6000mm | Thickness | 2.0 - 40.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
Product Description
Duplex Stainless Steel Plate S32205 / S31803 / S32750 Laser Cutting Any Size SS Plate
Products Specification
| Products | Duplex Stainless Steel Plate |
| Thickness | 1.0- 40.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
High-Performance Duplex Stainless Steel, Cut to Your Exact Requirements
When your application demands exceptional strength, superior corrosion resistance, and precision fabrication, Duplex Stainless Steel Grades S32205 (2205), S31803, and S32750 (2507) deliver unmatched performance. We specialize in CNC laser cutting of hot-rolled duplex stainless steel plates in any size, shape, or thickness from 3.0 mm to 40.0 mm, ensuring rapid turnaround, tight tolerances, and material integrity for the most demanding industries—including oil & gas, marine, chemical processing, desalination, and offshore engineering.
Whether you need a single prototype or high-volume production parts, our advanced fiber and CO₂ laser systems provide clean, accurate cuts with minimal heat-affected zones—preserving the critical dual-phase microstructure that gives duplex steels their renowned durability.
Material Grades Overview
| UNS Number | Common Name | Type | Key Characteristics |
|---|---|---|---|
| S32205 | Duplex 2205 | Standard Duplex | Balanced strength & corrosion resistance; ideal for moderate chloride environments |
| S31803 | Duplex 2205 (older spec) | Standard Duplex | Chemically similar to S32205; often used interchangeably (modern mills typically meet S32205 tighter limits) |
| S32750 | Super Duplex 2507 | Super Duplex | Ultra-high pitting resistance (PREN >40); suited for seawater, sour service, and aggressive chemicals |
Note: While S31803 and S32205 are often grouped together, S32205 has stricter compositional controls (especially nitrogen content) and is preferred for critical applications. All three grades are fully compatible with our laser cutting process.
Why Laser Cut Duplex Stainless Steel?
Traditional cutting methods like plasma or oxy-fuel can compromise duplex steel’s corrosion resistance by altering its microstructure or leaving oxidized edges. Laser cutting eliminates these risks:
- ✅ No thermal distortion in thin-to-medium thicknesses
- ✅ Smooth, dross-free edges—often eliminating secondary finishing
- ✅ Complex geometries cut directly from CAD (DXF, DWG, STEP)
- ✅ Material savings through intelligent nesting software
- ✅ Preserved mechanical & corrosion properties due to controlled, localized heat input
Our process uses high-purity nitrogen assist gas to prevent oxide scale formation, ensuring cut surfaces maintain the alloy’s inherent resistance to pitting and stress corrosion cracking.
Technical Specifications
| Parameter | Details |
|---|---|
| Material Grades | UNS S32205, S31803, S32750 |
| Plate Form | Hot-rolled (mill finish) |
| Thickness Range | 3.0 mm – 40.0 mm |
| Standard Plate Sizes | 2000×6000 mm, 2500×6000 mm (custom blanks available) |
| Cutting Technology | Fiber laser (up to 25 mm), CO₂ laser (25–40 mm) |
| Dimensional Tolerance | ±0.1 mm (≤10 mm), ±0.2 mm (10–25 mm), ±0.5 mm (>25 mm) |
| Edge Quality | ISO 9013 Class 2–3 (smooth, vertical kerf, minimal dross) |
| Surface Options | As-cut, pickled & passivated, beveled edges (for welding) |
| Certifications | EN 10204 3.1/3.2, ASTM A240, NORSOK M-650 (for S32750), full PMI traceability |
Performance Comparison: S32205 vs. S32750
| Property | S32205 / S31803 | S32750 (2507) |
|---|---|---|
| Chromium (Cr) | ~22% | ~25% |
| Molybdenum (Mo) | ~3.0–3.5% | ~3.5–4.0% |
| Nickel (Ni) | ~4.5–6.5% | ~6.0–8.0% |
| Nitrogen (N) | 0.14–0.20% | 0.24–0.32% |
| PREN (Pitting Resistance Equivalent) | 34–38 | 40–45 |
| Yield Strength (min) | 450 MPa | 550 MPa |
| Max Chloride Exposure | Up to ~1,000 ppm | Up to ~5,000+ ppm |
| Typical Use Case | Chemical tanks, pipelines | Subsea manifolds, seawater systems |
PREN = %Cr + 3.3×%Mo + 16×%N — a higher value indicates greater resistance to localized corrosion.
Applications by Industry
- Oil & Gas: Downhole equipment, flowlines, separators, pressure vessels
- Marine & Offshore: Seawater cooling systems, risers, FPSO structural components
- Chemical Processing: Reactors, heat exchangers, acid storage tanks
- Desalination Plants: High-pressure membrane housings, brine heaters
- Power Generation: Flue gas desulfurization (FGD) ducts, scrubber internals
- Pulp & Paper: Bleach plant equipment, digester components
These alloys outperform 316L and even 904L in chloride-rich or acidic environments—reducing maintenance, extending service life, and lowering total lifecycle costs.
Custom Laser Cutting – No Size Too Big or Small
We accept any size requirement:
- Small brackets (50×50 mm)
- Large structural panels (up to 3000×12000 mm with plate joining)
- Intricate perforated patterns, flanges, gaskets, or weld-ready profiles
Simply provide your CAD file, and we’ll deliver:
- Nesting optimization for cost efficiency
- Burr-free edges ready for assembly
- Full documentation (MTRs, PMI reports, dimensional inspection)
Quality Assurance & Compliance
Every batch is traceable to the original melt. Optional services include:
- Positive Material Identification (PMI) via XRF or OES
- Ultrasonic Testing (UT) for plates >20 mm (per ASTM A435/A578)
- Pickling & Passivation to restore optimal surface chromium oxide layer
- Welding procedure support (we recommend qualified procedures to avoid sigma phase formation)
Sustainable, Cost-Effective Engineering
While duplex stainless steels carry a higher upfront cost than austenitic grades, their double the strength allows for thinner sections, reducing weight and material usage. Combined with decades-long service life in corrosive environments, they offer superior ROI—especially in hard-to-access or safety-critical installations.
Get Your Quote Today
We cut any size, any shape, in S32205, S31803, or S32750 duplex stainless steel plate—from 3 mm to 40 mm thick. Fast lead times, global shipping, and engineering support included.
Duplex stainless steel laser cutting, S32205 plate cut to size, S32750 laser cut parts, S31803 stainless steel plate, custom duplex steel fabrication, any size laser cut SS plate, super duplex 2507 cutting service, hot rolled duplex plate 3–40mm, PREN 40 stainless steel parts, offshore grade laser cutting.
