ASTM B152 Alloy 110 Copper Sheet and Plate C110 Flat Plate Bars/ Round Bar
| Place of Origin | CHINA |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | C110 Copper |
| Minimum Order Quantity | 50 kgs |
| Price | 10-12 USD/kgs |
| Packaging Details | carton box, wooden box |
| Delivery Time | 10 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 5 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Copper Plate / Copper Bars | Material | C110 Copper |
|---|---|---|---|
| Thickness | 0.5 - 100mm | Width | 10 - 1500mm |
| Other Products | Pipe, Bar, Sheet, Plate,coil,wire.etc | Other Material | Copper,brass,bronze |
| Standard | ASTM EN DIN GB | Service | Cutting |
| Highlight | 200HV Flat Washer,Q235 Flat Washer,Dacromet Flat Washer |
||
Product Description
ASTM B152 Alloy 110 Copper Sheet and Plate C110 Flat Plate Bars/ Round Bar
DISTRIBUTOR C110 COPPER PLATE, C110 COPPER STRIPS, ASTM B152 ALLOY 110 COPPER COIL, HOT ROLLED COPPER ALLOY 110 SHEETS, C110 COPPER FOIL
| C110 Copper Plate Sizes | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
|---|---|
| C110 Copper Plate Thickness | 0.1mm to 100 mm |
| Width | 10-1500mm |
| C110 Copper Strip Length | 2m, 2.44m, 3m, or as per customer requirement |
| C110 Copper Sheet Finish | 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Cold rolled sheet (CR), Hot rolled plate (HR), |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard Sheet suppliers |
| Specialized supplier of |
|
| C110 Copper profiling |
To provide a full profiling service we use numerous profiling methods including:
|
| C110 Copper Plate available forms | C110 Copper Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| We also offer value added services: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing. | |
ASTM B152 Alloy 110 Copper Sheet and Plate
Standard sheet widths are 36" with a standard thickness ranging from .032" to .750".
Alloy 110 Copper Sheet and Plate weight chart
| Thickness | Width | Length | Lbs per sq. ft. | Approx. Lbs. Per Plate |
|---|---|---|---|---|
| 0.05 | 36 | 96 | 2.33 | 56 |
| 0.0625 | 36 | 96 | 2.88 | 69 |
| 0.080 | 36 | 96 | 3.72 | 89 |
| 0.0937 | 36 | 96 | 4.33 | 104 |
| 0.125 | 36 | 96 | 5.81 | 139 |
| 0.1875 | 36 | 96 | 8.72 | 209 |
| 0.250 | 36 | 96 | 11.63 | 279 |
| 0.375 | 36 | 96 | 17.44 | 419 |
| 0.500 | 36 | 96 | 23.33 | 559 |
| 0.625 | 36 | 96 | 29.07 | 698 |
| 0.750 | 36 | 96 | 34.78 | 835 |
Special offer on following C110 Copper Sheets & Plates material
| C110 Copper Sheet | C110 Copper Plate |
| C110 Copper Precision Strip | C110 Copper Quarto Plate |
| C110 Copper Clad Plates | C110 Copper oil |
| C110 Copper Cold Rolled Coil | C110 Copper Shim Sheet |
| C110 Copper Hot Rolled Coil | C110 Copper Clad Plate |
| C110 Copper Strips | C110 Copper Shim Stock |
| C110 Copper Rolling Sheets | C110 Copper Flat Sheet |
| C110 Copper Diamond Plate | C110 Copper Embossing Foil Sheet |
| C110 Copper Rolling Plate | C110 Copper Flat Shim |
| C110 Copper Perforated Plate | C110 Copper Polished Plate |
| C110 Copper hot rolled plate | C110 Copper cold rolled sheet |
| C110 Copper Coil | C110 Copper 2B Sheet |
| C110 Copper Perforated Sheet | C110 Copper Hairline Sheet |
| Decorative 8K Mirror C110 Copper Sheet | No.4 C110 Copper Sheet |
| C110 Copper Embossing sheets | Etching Plate C110 Copper |
Applications
Copper 110, often referred to as C110, is a copper alloy that has been specifically formulated to have superior electrical and thermal conductivity. The ideal application for this metal would be in any type of equipment where electricity must flow from one point to another, such as wiring or electrical components. C110 Copper is also highly formable, meaning it can bend easily without breaking and does not require a lot of force when being formed into a desired shape. Another important aspect of 110 Copper is its corrosion resistance—it will not corrode over time like most other types of metals do when exposed to the elements. This makes C110 an excellent choice for many different indoor and outdoor components.
What Are the Properties of C110 Copper?
C110 is a form of copper with electrical and thermal conductivity characteristics.
Chemical Composition
The material of choice for the new C110 line is pure copper, which has a 99.9% copper content with the other 0.1% being oxygen.
C110 is a highly conductive copper-based alloy with outstanding electrical and thermal conductivity properties, which is superior to other products available on the market. When heated, it is not brittle or embrittlement-prone like other copper alloys, such as copper alloy 122. C110 also contains the same amount of oxygen that occurs naturally in pure copper (Cu). This makes the alloy ductile, which is beneficial for electronic components that must be free from hazardous impurities and oxide films.
C110 has excellent electrical conductivity, outstanding thermal conductivity, freedom from hydrogen embrittlement, and the potential for cold-working.
Mechanical Information
C110 Copper H02 (Half Hard) Temper
- Ultimate Tensile Strength: 42,100 psi
- Yield Strength: 36,300 psi
- Rockwell Hardness: B40
- Machinability: 20% 1/2″ or 3/4″ brass rod, also known as free-cutting brass rod (C360)
- Melting Point: 1,950-1,980° F
Other Common Names for C110 Copper Alloy
Electrolytic Tough Pitch (ETP) copper is another name for copper alloys with a high carbon content, such as C110. They are also more technically referred to as UNS C11000, CDA 110 ETP, C110, and ISO Cu-ETP.
Applications of C110 Copper Alloy
C110 is commonly used in industrial applications where there is a need for ductility (such as in plumbing or roofing) or electrical conductivity (for example, electromagnets, bus bars, electrical motors, and other electrical equipment). It’s most often utilized in the home/residential/ architectural realm for its color (such as a kitchen backsplash or cutting board) or heat transfer qualities (e.g., pots and pans).
In the building and construction industry, C110 Copper has many applications. These typically include: plumbing hardware, wiring, skylight frames, flashing, gutters, and more.
Copper 110 can be welded with precaution, but generally the sort of inert gases required are not recommended for use with copper.
