Cold Rolled 2D Finishing 430 Stainless Steel Strips Precision SS Strip 0.05 - 0.5mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 430 / 1.4016 / SUS430 |
| Minimum Order Quantity | 500 kgs |
| Price | 1220 - 1440 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Coil & Band | Thickness | 0.05-3.0mm |
|---|---|---|---|
| Width | Within 1000mm 1219mm | MOQ | 200 Kgs |
| Grade | EN 1.4016 Stainless Steel | Surface | BA 2B NO.4 HL 8K NO.1 2D |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | cold rolled stainless steel strip,cold rolled steel strip,cold rolled strip |
||
Product Description
Cold Rolled 2D Finishing 430 Stainless Steel Strips Precision SS Strip 0.05 - 0.5mm Thickness
Specification Of Stainless Steel Strip
| Product Name | 430 Stainless Steel Strips |
| Material | Stainless Steel |
| Standard | ASTM JIS GB EN |
| Other Grade | 201 202 301 304 304L 309S 310S 316L 317L 410 420 430 436L 441 2205 2507 904L C276 |
| Thickness | 0.05mm-3.0mm |
| Width | 30mm-600mm |
| Finish | No.1, No.2, Bright Annealed, TR, Polished, etc. |
| Edge | Mill edge, Slit edge, Square edge, Round edge, etc. |
| Coating | PE coating, Paper coating |
| Coil ID | 508mm/610mm |
| Payment Terms | T/T, L/C |
| Delivery Time | As per quantity required |
430 Stainless Steel Chemical Composition
430 stainless steel has high chromium but very low nickel content. Chromium content is between 16 and 18%, while nickel content is 0.5% max. Its other constituents are present in trace amounts. There’s a maximum of 1% each of manganese and silicon, 0.12% carbon, and 0.03% and 0.04% respectively for sulfur and phosphorous. As before, the balance is made up of iron, around 80%.
| Grade | C | Si | Mn | P | S | Cr | Ni | Fe |
|---|---|---|---|---|---|---|---|---|
| 430 | 0.12 | 1.00 | 1.00 | 0.04 | 0.02 | 16.00 – 18.00 | 0.5 | Bal |
| TP430 | 0.12 | 1.00 | 1.00 | 0.04 | 0.03 | 16.00 – 18.00 | … | Bal |
430 Stainless Steel Mechanical Properties
| Grade | Tensile Strength (MPa) Min | Yield Strength 0.2% Proof (MPa) Min | Elongation (% In 50mm) Min | Hardness Rockwell B (HR B) Max | Hardness Brinell (HB) Max |
|---|---|---|---|---|---|
| 430 | 483 | 310 | 22 | 85 | 183 |
| TP430 | 415 | 240 | 20 | 90 | 190 |
430 Stainless Steel Physical Properties
| Grade | Density (Kg/M3) | Elastic Modulus (GPa) | Mean Coefficient Of Thermal Expansion (Μm/M/°C) 0-100°C |
Thermal Conductivity (W/M.K) At 100°C |
Specific Heat 0-100°C (J/Kg.K) | Electrical Resistivity (NΩ.M) |
|---|---|---|---|---|---|---|
| 430 | 7750 | 200 | 10.4 | 26.1 | 460 | 600 |
430 Stainless Steel Equivalent Grades
| EU EN |
USA UNS |
Germany DIN,WNr |
Japan JIS |
China GB |
Russia GOST |
|---|---|---|---|---|---|
| X6Cr17 | 430 S43000 |
1.4016 | SUS430 | 1Cr15 | 12KH17 |
Corrosion Resistance
All ferritic grades, such as stainless steel grade 430, have excellent stress corrosion cracking resistance. Grade 430 has good corrosion resistance to numerous substances, such as certain organic acids and nitric acid. The corrosion resistance is maximized in well-polished or buffed conditions. Its pitting and crevice corrosion resistance is quite similar to that of grade 304. 430F is a high-sulphur-free machining grade, and therefore the resistance to pitting and crevice corrosion is comparatively lesser than those grades that are non-free machining.
Welding
To perform any welding, stainless steel grade 430 has to be pre-heated at 150-200°C (302-392°F). In the case of embrittlement in the welded metal, the particular area can be post-weld annealed at 790-815°C (1454-1499°F); however, grain refinement will not happen.
It is recommended that grade 430, 308L, 309 or 310 filler rod should be used based on the application.
The ductility of the welded products can be improved by annealing post-welding at temperatures of 760 to 815°C. However, this is not required for thin welded products. Welding of exhaust tubing of automobiles is carried out without filler rods.
Heat Treatment
Solution annealing can be performed by heating stainless steel grade 430 to 815 – 845°C (1499-1553°F). Then it has to be slow furnace cooled to 600°C (1112°F) and followed by air-cooling quickly – as slow cooling between 540 and 400°C (1004 and 752°F) tends to cause embrittlement.
For sub-critical annealing, heating should be performed to 760-815°C (1400-1499°F), followed by air-cooling or water quenching.
This stainless steel cannot be hardened by thermal treatment.
430 Stainless Steel Applications
This grade of stainless steel can be supplied in all the usual forms: sheet, strip, plate, bar and tube. Its low cost combined with good corrosion resistance lends itself well to the making of domestic appliances. A lot of 430 stainless is used in cookers, washing machines, and dishwashers. Stove element supports are often produced in 430 stainless steel. It can also be found in shallow draw/limited-depth Stainless Steel sinks.
The motor industry uses a lot of 430 stainless steel in its automotive trim and muffler systems. You will also find it used for flue linings, industrial roofing, wall cladding, hinges, and fasteners.
