Soft Anneal AISI 301 Stainless Steel Strip 0.1-2.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 201 202 301 304 316L 321 310S 410 430 440C |
| Minimum Order Quantity | 2 Ton |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.1 - 10.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 2 Ton |
| Grade | 200 Series 300 Series 300 Series | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | AISI 301 stainless steel strip,Soft Anneal 301 stainless steel strip,2.0mm stainless strips |
||
Product Description
Soft Anneal AISI301 Stainless Steel Strip Thickness 0.1 - 2.0mm Thickness SS Strips
What Is 301 Stainless Steel Strip
The 301 stainless steel strip has high strength after cold working, which is the first choice for constant force springs manufacturing.
The constant force spring, also known as torsion spring, which is made of 301 stainless steel strip.
The stress can determine the spring diameter, strength and working life.
The action of a constant force spring is similar to the move of stretching a ribbon.
When the spring stretches and rewinds, the working part is tangent to the circle of the spring itself.
As long as the diameter of the spring is constant, the force of the spring is constant.
In an extremely long spring design work, the diameter has an advantage, and the tension increases slightly as the spring stretches.
However, this increased part is relatively small relative to the stretched length and can be ignored in many real life applications.
What Are The Springs Applications?
According to the application principle of them, constant force springs can be divided into linear motion constant type and rotary motion constant torque type.
When linear stretched, the unit of force will be kilogram, N, pound.
Constant force springs can be used for vehicles, automotive industry, counterweights, power sources, power cords, cordless curtains, generator radios and some toys.
What Are The Advantages Of 301 Stainless Steel Strip For Springs?
Austenitic stainless steel strip for springs mainly includes SUS301-CSP and SUS304-CSP.
Compared with 304 stainless steel strip, SUS301 spring steel strip has a slightly lower corrosion resistance, but it is more suitable for spring production with a lower cost.
After the special production process of continuous bright annealing and rolling, which can help achieve good hardness and be suitable for bending processing.
Especially in terms of mechanical properties, 301 spring strip is very good, which is unmatched by manganese steel.
How To Produce One Roll 301 Stainless Steel Strip?
Our high strength precision grade 301 stainless steel strip for springs is available in total annealed condition as well as a variety of hardness choice, such as 1/4 hard, half hard, 3/4 hard, full hard and super extra hard.
The thickness range is from 0.02mm to 3mm.
The maximum hardness of cold rolled 301 stainless steel strip we could produce is up to 630 HV.
Meanwhile, the tensile strength is over 2000 N/mm².
Chemical Composition of Stainless Steel 301 Strip
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 301 | Min | – | – | – | – | – | 16.0 | 2.00 | 10.0 | – |
| max | 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.1 |
ASTM A240 SS 301 Strip Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 201 | 515 | 205 | 35% | 75 | 205 |
Stainless Steel 301 Strip Physical Properties
| Physical Properties (Room Temperature) | ||
| Specific Heat (0-100°C) | 500 | J.kg-1.°K-1 |
| Thermal Conductivity | 14.6 | W.m -1.°K-1 |
| Thermal Expansion | 16.5 | mm/m/°C |
| Modulus Elasticity | 193 | GPa |
| Electrical Resistivity | 7.4 | μohm/cm |
| Density | 7.99 | g/cm3 |
Equivalent Grades of 301 Stainless Steel Strip
| STANDARD | UNS | JIS | WERKSTOFF NR. | AFNOR | BS | GOST | EN |
| SS 301 | S30100 | SUS 301 | 1.4310 | – | – | – | – |
