ASTM A240 UNS N08926 Nickel Base Alloy Plate with High Corrosion Resistance and Thickness 1.0 - 16.0mm Alloy 926 Plate

証明	ISO, ASTM, EN, DIN
最小注文数量	10kg
価格	US $27 / kg

商品の詳細

型番	N08926	形	四角
技術	冷間圧延	表面処理	ピクルスにすること
厚さの範囲	1.0～16.0mm	長さのオプション	2000mm、2438mm、3000mm、5800mm、6000mm、12000mm
幅オプション	40mm-600mm、1000mm、1219mm、1500mm、1800mm、2000mm、2500mm、3000mm、3500mm	表面仕上げ	BA、2B、NO.1、NO.4、4KのHL、8K
クロムの内容	19.00～21.00％	ニッケル含有量	24.00～26.00%
モリブデン含有量	6～7%	炭素含有量	≤0.02％
シリコン含有量	≤0.50%	マンガンの内容	≤1.00%
温度範囲	-196℃～400℃
ハイライト	ASTM A240 UNS N08926 Nickel Base Alloy Plate , High Corrosion Resistant Alloy 926 Plate , Thickness 1.0 - 16.0mm Incoloy 926 Plate

メッセージ

製品の説明

ASTM A240 UNS N08926 Nickel Base Alloy Plate

Incoloy 926 (N08926) nickel alloy is a high corrosion resistant super austenitic stainless steel containing high chromium and molybdenum content. It maintains excellent corrosion resistance in harsh environments including high temperatures, seawater, and flue gas desulfurization equipment, with performance comparable to Hastelloy and titanium in certain applications.

Product Specifications

Thickness	1.0 - 16.0mm
Length	2000mm, 2438mm, 3000mm, 5800mm, 6000mm, 12000mm, etc
Width	40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Standard	ASTM, AISI, JIS, GB, DIN, EN
Surface	BA, 2B, NO.1, NO.4, 4K, HL, 8K
Technique	Cold Rolled, Hot Rolled
Edge	Mill Edge, Slit Edge
Certification	ISO, SGS, BV

Chemical Composition

Element	Content (%)
C	≤0.02
Si	≤0.50
Mn	≤1.00
P	≤0.030
S	≤0.010
Cr	19.00-21.00
Ni	24.00-26.00
Mo	6-7

Key Features

High resistance to pitting and crevice corrosion in halide media and acidic environments containing H2S
Effective resistance to chloride ion stress corrosion cracking (SCC)
Resistant to various corrosions in both oxidizing and reducing environments
Enhanced mechanical performance compared to Cronifer 1925 LC-Alloy 904L
Improved metallurgical stability compared with Ni18 alloys
Certified for pressure vessel manufacturing (VdTUV-196°C to 400°C and ASME certification)

Applications
