Durable Monel 400 Round Steel with Excellent Resistance to Acids & Saline Environments, Customizable Sizes, ASTM B165 Compliant

Zertifizierung	ISO, ASTM
Min Bestellmenge	20 KG

Produktdetails

Form	Runden	Technik	kaltgewalzt
Oberflächenbehandlung	In Essig einlegen	Durchmesserbereich	4~300mm
Dickenbereich	1.0 ~ 100 mm	Breitenbereich	1~1500mm
Größe der quadratischen Stange	44-100100mm	Längenoptionen	2 m, 5,8 m, 6 m
Zugfestigkeit	70.000–85.000 psi	Streckgrenze	25.000–45.000 psi
Verlängerung	35 bis 50%	Härte	Rockwell B 65-85
Schmelzbereich	2370-2460°F	Dichte	0,319 lb/in³
Wärmeleitfähigkeit	15,5 BTU-in/h-ft²-°F
Hervorheben	Excellent Resistance Monel 400 Round Steel , Customizable Sizes Nickel Alloy Round Bar , ASTM B165 Compliant Monel 400 Round Bar

Hinterlass eine Nachricht

Produkt-Beschreibung

Durable Monel 400 Round Steel

Premium nickel-copper alloy offering exceptional resistance to acidic and saline environments with customizable sizing options, fully compliant with ASTM B164 standards.

Product Specifications

Standard	AISI, ASTM, BS, DIN, GB, JIS
Grade	Monel series: 400, K500 Inconel series: 600, 601, 625, 718, 725 Incoloy series: 800, 800H, 825, 925 Hastelloy series: B, B2, B3, C, C-276, C-4, C-22 Pure: Ni200, Ni201
Specifications	Round bar: Diameter: 4-300mm Flat bar: Thickness: 1.0-100mm, Width: 1-1500mm Square bar: Size: 4×4-100×100mm Length: 2m, 5.8m, 6m, or as required Surface: Black, peeled, polishing, bright, sand blast, hair line, etc.
Price Term	Ex-work, FOB, CFR, CIF, etc.
Delivery Time	Standard sizes in stock, prompt delivery or as per order quantity
Package	Export standard package, bundled or as required Container sizes: 20ft GP (24-26CBM), 40ft GP (54CBM), 40ft HG (68CBM)

Material Properties & Performance

Superior Corrosion Resistance

Monel 400 demonstrates extraordinary resistance in both oxidizing and reducing environments, with exceptional performance in sulfuric acid, phosphoric acid, and alkaline solutions. In seawater immersion, corrosion rates remain below 1 mil per year (0.025 mm/year).

Enhanced Mechanical Strength

Excellent mechanical properties across wide temperature ranges: tensile strength 70-85 ksi (480-585 MPa), yield strength 25-45 ksi (170-310 MPa). Maintains strength and toughness from -200°F (-129°C) to 1000°F (538°C).

Physical Characteristics

Density: 0.319 lb/in³ (8.83 g/cm³)
Melting range: 2370-2460°F (1300-1350°C)
Thermal conductivity: 15.5 BTU-in/hr-ft²-°F (22.4 W/m·K)
Specific heat capacity: 0.092 BTU/lb-°F (385 J/kg·K)

Technical Specifications

Chemical Composition (ASTM B164)

Nickel (including cobalt): 63.0% minimum
Copper: 28.0-34.0%
Iron: 2.5% maximum
Manganese: 2.0% maximum
Carbon: 0.3% maximum
Silicon: 0.5% maximum
Sulfur: 0.024% maximum

Mechanical Properties

Tensile Strength: 70,000-85,000 psi (480-585 MPa)
Yield Strength (0.2% offset): 25,000-45,000 psi (170-310 MPa)
Elongation in 2 inches: 35-50%
Hardness: Rockwell B 65-85
Modulus of Elasticity: 26,000 ksi (179 GPa)

Customizable Size Range

Standard diameters: 0.125 inches to 12 inches (3 mm to 300 mm)
Lengths: Random mill lengths up to 20 feet (6 meters) or cut-to-size specifications
Tolerance: Hot-rolled bars ±0.005 inches, Cold-drawn bars ±0.002 inches
Surface finishes: Hot-rolled, turned, polished, or centerless ground
Special processing: Peeling, turning, and precision grinding available

Industry Applications

Marine Engineering

Marine shafting, propeller shafts, pump components, fasteners, offshore platforms, shipbuilding, and desalination plants. Non-magnetic properties enhance marine suitability.

Chemical Processing

Valve components, pump parts, mixer shafts, and heat exchanger components for handling sulfuric acid and other aggressive chemicals.

Oil and Gas

Downhole tools, valve trim, pump components, and instrumentation parts with resistance to sour gas (H2S) environments and high-pressure conditions.

Specialized Industries

Aerospace fuel systems, power generation feedwater heaters, pharmaceutical equipment, and pulp/paper processing components.

Quality Assurance & Manufacturing

Rigorous quality control using vacuum induction melting (VIM) and electro-slag remelting (ESR) techniques ensures chemical homogeneity and purity. Complete traceability and material certification per ASTM B164 requirements.

Quality Documentation

Certified Material Test Reports (CMTR)
Chemical Analysis Certificates
Mechanical Test Reports
Non-Destructive Testing Reports (UT, MT, PT as required)
Origin and Mill Certificates

Compliance & Certifications

ASTM B164 ASME SB-164 NACE MR0175/ISO 15156 DIN JIS GB

Competitive Advantages

Technical Superiority: Consistent microstructure and mechanical properties with excellent machinability (30% relative to free-cutting brass)
Customization Capabilities: Special sizes, tolerances, surface finishes, and heat treatment conditions
Supply Chain Reliability: Strategic inventory management and established mill relationships
Proven Performance: Decades of experience in critical applications worldwide
Technical Support: Metallurgical expertise for material selection and fabrication optimization
Environmental Responsibility: Sustainable manufacturing and recyclable materials
