Hot Rolled Stainless Steel Channel Bar with Bright Surface in 304 316L 310S Grade
Produktdetails
| Modell Nr. | 201 304 316L 310S 2205 | Form | U-Kanal |
|---|---|---|---|
| Technik | Warmgewalzt | Oberflächenbehandlung | Hell |
| Spezifikation | 30*30-100*100 | Winkelstangengröße | 30*30*3 - 200*200*10mm * 6m Länge |
| Kanalleistengröße | 50*30*3 - 200*100*10mm * 6m Länge | Dicke der Winkelstange | 3-10 mm |
| Kanalstabdicke | 3-12 mm | Gewicht der Winkelstange | 0,894-15,0 kg/m |
| Gewicht der Kanalstange | 1,79–35,8 kg/m | Materialqualität | 201 304 310S 316L 321 2205 |
| Standard | ASTM GB DIN | Länge | 6m |
| Verpackung | Wasserfeste Papier- oder Holzpaletten | ||
| Hervorheben | Hot Rolled Stainless Steel Channel Bar,Bright Surface Steel Channel,304 316L 310S Grade U Channel |
||
Produkt-Beschreibung
Stainless Steel Channels & Angle Bars
Professional manufacturer of hot rolled stainless steel channel bars and angle bars in China. Our products are manufactured to meet international standards with superior quality and durability.
Product Specifications
- Product Types: Stainless Steel Angle Bar / Stainless Steel Channel Bar
- Grades Available: 201, 304, 310S, 316L, 321, 2205, and more
- Standards: ASTM, GB, DIN
- Angle Bar Sizes: 30×30×3 - 200×200×10mm × 6m length
- Channel Bar Sizes: 50×30×3 - 200×100×10mm × 6m length
- Services: Custom cutting available
- Packing: Waterproof paper wrapping or wooden pallets
- Brand: TSINGSHAN
Standard Sizes & Weights
Stainless Steel Angle Bar Weight Table (kg/m)
| Size A×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm |
|---|---|---|---|---|---|---|---|---|
| 20×20 | 0.894 | 1.13 | 1.38 | |||||
| 25×25 | 1.13 | 1.45 | 1.77 | 2.06 | ||||
| 30×30 | 1.37 | 1.77 | 2.17 | 2.53 | ||||
| 35×35 | 1.61 | 2.09 | 2.57 | 3.01 | ||||
| 40×40 | 1.85 | 2.41 | 2.97 | 3.49 | ||||
| 45×45 | 2.12 | 2.76 | 3.40 | 4.00 | ||||
| 50×50 | 2.36 | 3.07 | 3.79 | 4.46 | 5.13 | 5.76 | 6.42 | 7.06 |
| 60×60 | 4.58 | 5.42 | 6.24 | 7.03 | ||||
| 63×63 | 5.03 | 5.95 | 6.84 | 7.71 | 8.60 | 9.48 | ||
| 70×70 | 5.42 | 6.42 | 7.39 | 8.34 | 9.31 | 10.3 | ||
| 75×75 | 5.82 | 6.89 | 7.95 | 8.97 | 10.0 | 11.1 | ||
| 80×80 | 7.37 | 8.50 | 9.61 | 10.7 | 11.8 | |||
| 90×90 | 8.33 | 9.65 | 11.90 | 12.2 | 13.4 | |||
| 100×100 | 9.28 | 10.8 | 12.20 | 13.6 | 15.0 |
Stainless Steel Channel Bar Weight Table (kg/m)
| Size H×B (mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | 12mm |
|---|---|---|---|---|---|---|---|---|---|
| 40×20 | 1.79 | ||||||||
| 50×25 | 2.27 | ||||||||
| 60×30 | 2.74 | 3.56 | 4.37 | 5.12 | |||||
| 70×35 | 3.23 | 4.21 | 5.17 | 6.08 | |||||
| 80×40 | 3.71 | 4.84 | 5.96 | 7.03 | |||||
| 90×45 | 4.25 | 5.55 | 6.83 | 8.05 | |||||
| 100×50 | 4.73 | 6.18 | 7.62 | 8.98 | 10.3 | 11.7 | 13.0 | 41.2 | |
| 120×60 | 9.20 | 10.9 | 12.6 | 14.2 | |||||
| 130×65 | 10.1 | 11.9 | 13.8 | 15.5 | 17.3 | 19.1 | |||
| 140×70 | 12.9 | 14.9 | 16.8 | 18.8 | 20.7 | ||||
| 150×75 | 13.9 | 16.0 | 18.1 | 20.2 | 22.2 | 26.3 | |||
| 160×80 | 14.8 | 17.1 | 19.3 | 21.6 | 23.8 | 28.1 | |||
| 180×90 | 16.7 | 19.4 | 22.0 | 24.5 | 27.0 | 32.0 | |||
| 200×100 | 18.6 | 21.6 | 24.5 | 27.4 | 30.2 | 35.8 |
Company Overview
We are a comprehensive stainless steel enterprise specializing in wholesale distribution, material processing, storage, and logistics. Located in Wuxi - the stainless steel trading hub of China, with total investment of 100 million RMB and annual sales exceeding 300 million RMB.
Strategic Partnerships
We maintain long-term cooperative relationships with leading steel mills including Taiyuan Steel, East Steel, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, and South Korea.
Material Range & Processing Capabilities
- Material Grades: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205, 904L
- Specialty Series: High-temperature resistant, duplex stainless steel, super stainless steel
- Processing Equipment: Plasma cutting, coil material opening, laser cutting, 8K mirror finishing, grinding, wire drawing, film coating, titanium plating
- Special Services: Thick plate cutting (up to 150mm), custom shapes, casting parts, forging parts, steel mill customization
Industry Applications
Our materials are widely used in machinery, chemical processing, petroleum, boiler manufacturing, heat exchangers, food machinery, beverage equipment, medical devices, and various industrial sectors.
Product Gallery
Applications
Stainless steel angle bars and channel bars are primarily used for constructing frame structures including high-voltage power transmission towers, steel structure bridge frameworks, tower crane columns and booms on construction sites, workshop columns and beams, and support structures for air conditioning and solar power installations.
These structural components are extensively applied in building construction and engineering projects such as house beams, ship beams, industrial furnaces, and various industrial frameworks. Our stainless steel angle bars and channel bars serve diverse applications across multiple industries and construction sectors.
