Heat Resistant Grade 304 Stainless Steel Wire Mesh with Twill Weave Tortoise Shell Net for Boiler Applications
Product Details
| Material Type | Stainless Steel Plate | Weave Technique | Twill Weave |
|---|---|---|---|
| Wire Mesh Width | 1m | Technique | Punching |
| Nickel Content | 8% | Height | 8-40mm |
| Thickness | 1.2-2.0mm | Hole Size | 40x40-50x50mm |
| Area Per Piece | 0.6-2m² | Length | 1070-1550mm |
| Width | 562-1300mm | Grades Available | 201, 304, 410S, 310S, S32205, 304L, 321, 309S, 316L, 420, 430 |
| Hexagonal Fixing Power | Enhanced | Heat Resistance | High |
| Lining Material Fastness | Raised | ||
| Highlight | Heat Resistant Stainless Steel Wire Mesh,Grade 304 Tortoise Shell Net,Twill Weave Punching Hole Wire Mesh |
||
Product Description
Heat Resistant Stainless Steel Tortoise Shell Net
Available in Grades: 201, 304, 410S, 310S, S32205, 304L, 321, 309S, 316L, 420, 430, and more
Standard Product Specifications
| Grade | Height (mm) | Thickness (mm) | Hole Size (mm) | Whole Size | Area (m²/PCS) | Length × Width (mm) |
|---|---|---|---|---|---|---|
| Carbon Steel | 8 | 1.2 | 40×40 | 8-1.2-40×40 | 0.6 | 1070×562 |
| Carbon Steel | 10 | 1.2 | 40×40 | 10-1.2-40×40 | 0.6 | 1070×562 |
| Carbon Steel | 15 | 1.5 | 50×50 | 15-1.5-50×50 | 1 | 1550×650 |
| Carbon Steel | 15 | 1.75 | 50×50 | 15-1.75-50×50 | 1 | 1550×650 |
| Carbon Steel | 20 | 1.75 | 50×50 | 20-1.75-50×50 | 2 | 1550×1300 |
| 0Cr13 | 10 | 1.2 | 40×40 | 10-1.2-40×40 | 0.6 | 1070×562 |
| 0Cr13 | 20 | 1.75 | 50×50 | 20-1.75-50×50 | 1.9 | 1550×1230 |
| 0Cr13 | 25 | 1.75 | 50×50 | 25-1.75-50×50 | 1.9 | 1550×1230 |
| 0Cr13 | 40 | 1.75 | 50×50 | 40-1.75-50×50 | 1.9 | 1550×1230 |
| 304 | 8 | 1.2 | 40×40 | 8-1.2-40×40 | 0.6 | 1070×562 |
| 304 | 10 | 1.2 | 50×50 | 10-1.2-50×50 | 1 | 1550×650 |
| 304 | 20 | 1.75 | 50×50 | 20-1.75-50×50 | 1.88 | 1540×1225 |
| 304 | 25 | 1.75 | 50×50 | 25-1.75-50×50 | 1.9 | 1550×1230 |
| 304 | 40 | 1.75 | 50×50 | 40-1.75-50×50 | 1.9 | 1550×1230 |
| S32205 | 10 | 1.2 | 40×40 | 10-1.2-40×40 | 0.73 | 1340×590 |
| 0Cr25Ni20 | 10 | 1.2 | 40×40 | 10-1.2-40×40 | 0.6 | 1070×562 |
| 0Cr25Ni20 | 20 | 2.0 | 50×50 | 20-2.0-50×50 | Custom as request: length 1550 × width | |
Product Advantages
- Enhanced fixing power with lining material through hexagonal hexsteel design
- Effectively strengthens self-connecting property of lining material
- Prevents heat insulation layer from peeling off
- Increases fastness and durability of lining material
Applications
Used for pouring shapeless lining material and lining material fixing applications. We have supplied necessary metal parts for major mainframe factories and various lining metal components for numerous petrochemical manufacturers.
Our products are widely used in petrochemical large devices, particularly as key lining parts conducive to catalyst systems and industrial insulation applications.
Product Images
