Hot Rolled Abrasion Resistant Steel Plate AR400 AR450 AR500 AR550 with Thickness 5.0 - 60.0mm

Minimum Order Quantity	1 Ton
Price	US $842-1,210 / Ton

Product Details

Thickness Range	5.0 - 60.0mm	Width Range	10-2600mm
Production Capacity	50000kgs	Technique	Hot Rolled
Related Materials	NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600	Length Options	6m, 8m, 10m Or Custom
Yield Strength AR500	1250 MPa	Tensile Strength AR500	1450 MPa
Elongation AR500	8%	Hardness Range AR500	450-540
Yield Strength AR400	1000 MPa	Tensile Strength AR400	1250 MPa
Elongation AR400	10%	Hardness Range AR400	360-480
Impact Strength AR400	-40C
Highlight	AR400 AR450 AR500 AR550 Abrasion Resistant Steel Plate , Thickness 5.0 - 60.0mm Wear Resistant Steel Plate , Hot Rolled AR Steel Plate

Leave a Message

Product Description

UT Condition Abrasion Resistant Steel Plate

Premium abrasion resistant steel plates in AR400, AR450, AR500, and AR550 grades with thickness range of 5.0 - 60.0mm, designed for extended service life in demanding industrial applications.

Product Specifications

Description	Abrasion Resistant Steel Plate
Thickness Range	5.0 - 80.0mm
Related Materials	NM360, NM400, NM450, NM500, NM550, NM600, AR360, AR400, AR450, AR500, AR600
Dimensions	Width: 1500mm, 2000mm, 2200mm \| Length: 6m, 8m, 10m or custom lengths

Commercial Terms

Price Terms	EX-Work, FOB, CFR, CIF
Main Markets	Europe, South America, Africa, Oceania, USA, Germany, India, Iran, Dubai, Iraq, Vietnam, Ireland, Singapore
Payment Terms	T/T, L/C, Western Union
Delivery Time	Based on order quantity

Product Overview

Abrasion Resistant (AR) steel plate is manufactured in the as-rolled condition specifically for long service life in harsh operating environments. These steel plate products are ideal for applications in mining, quarrying, conveyors, material handling, construction, and earthmoving equipment.

Designers and plant operators select AR plate steel to extend service life of critical components while reducing unit weight. The benefits of using wear-resistant plate steel in applications involving impact and sliding contact with abrasive materials are substantial.

Abrasion resistant alloy steel plates provide excellent resistance to both sliding and impact abrasion. The high carbon content in the alloy enhances hardness and toughness, making it ideal for applications requiring high impact or abrasion resistance.

Chemical Composition

Grade	C	Si	Mn	P	S	Cr	Ni	Mo	B
AR500	0.30	0.7	1.70	0.025	0.015	1.00	0.70	0.50	0.005
AR450	0.26	0.7	1.70	0.025	0.015	1.00	0.70	0.50	0.005
AR400	0.25	0.7	1.70	0.025	0.015	1.50	0.70	0.50	0.005
AR300	0.18	0.7	1.70	0.025	0.015	1.50	0.40	0.50	0.005

Mechanical Properties

Grade	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation A	Impact Strength Charpy V 20J	Hardness Range
AR500	1250	1450	8	-30°C	450-540
AR450	1200	1450	8	-40°C	420-500
AR400	1000	1250	10	-40°C	360-480
AR300	900	1000	11	-40°C	-

Application Guide

AR400: Premium abrasion resistant steel plates that are heat-treated and exhibit through-hardening with improved forming and welding capabilities
AR450: Abrasion resistant plate used where slightly greater strength is required beyond AR400
AR500: Suitable for mining, forestry and construction applications
AR600: Utilized in high-wear areas including aggregate removal, mining, and manufacture of buckets and wear bodies

Shipping & Packaging

Delivery	Within 7-30 days after order confirmation
Packaging	Standard seaworthy export packing with bundled steel straps, customizable as required
Shipping Time	5-7 work days after delivery
Shipping Method	By Sea
Shipping Port	Shanghai

Transport cargo to port by truck with road coverage and port coverage. Shipping available by bulk or container with standard seaworthy export packaging.
