DC01 DC04 SPCC Cold Rolled Steel Coil with 0.11-2.0mm Thickness and Slit Edge for Industrial Applications

Minimum Order Quantity	1 Ton
Price	US $690-1,150 / Ton

Product Details

Model NO.	DC01 DC04 SPCC	Edge Type	Slit Edge
Width Range	10-2000mm	Thickness Range	0.11-2.0mm
Normal Width	750mm,914mm,1000mm,1219mm,1220mm,1250mm	Length	Custom
Tolerance	Thickness +/-0.02mm, Width +/-0.02mm	Coil ID	508/610 Mm
Coil Weight	3-10 Tons	Production Capacity	1500 Tons Per Month
Surface Treatment	Oil/dry/passivation/pickling	Yield Strength	140~280 MPa (DC01)
Tensile Strength	270~410 MPa (DC01)	Elongation	≥28% (DC01)
Carbon Content	≤0.12% (DC01)
Highlight	DC01 DC04 SPCC cold rolled steel coil , 0.11-2.0mm thickness cold rolled steel coil , slit edge cold rolled steel strip

Leave a Message

Product Description

DC01 SPCC-SD Cold Rolled Steel Coil & DC04 Cold Rolled Steel Strip

Cold-rolled steel sheet, also known as cold-rolled plate or cold plate, is manufactured from hot-rolled carbon structural steel strips through further cold rolling to achieve thicknesses under 4mm. Processed at room temperature, it eliminates iron oxide formation, resulting in superior surface quality and dimensional accuracy. Combined with annealing treatment, cold-rolled steel offers enhanced mechanical and technological properties compared to hot-rolled steel, making it the preferred choice in numerous applications, particularly in household appliance manufacturing.

Chemical Composition

Grade	C	Mn	P	S	Alta
DC01, SPCC	≤0.12	≤0.60	≤0.045	≤0.045	≥0.020
DC02, SPCD	≤0.10	≤0.45	≤0.035	≤0.035	≥0.020
DC03, SPCE	≤0.08	≤0.40	≤0.030	≤0.030	≥0.020
DC04, SPCF	≤0.06	≤0.35	≤0.025	≤0.025	≥0.015

Mechanical Properties

Grade	RCL (Mpa)	RM (MPa)	A80mm (%)	R90
DC01	140~280	270~410	≥28
DC02	140~240	270~370	≥34	≥1.4
DC03	120~210	270~350	≥38

Product Specifications

Standards: AISI, ASTM, DIN, GB, JIS, BIS, EN
Materials: SPCC, SPCD, SPCE, ST12-15, DC01-06, Q195A-Q235A, Q195, Q235AF
Thickness: 0.11-2.0mm
Width: 20-1250mm
Normal Width: 750mm, 914mm, 1000mm, 1219mm, 1220mm, 1250mm
Length: Customized according to customer requirements or cut to sheet
Tolerance: Thickness +/-0.02mm, Width +/-0.02mm
Coil ID: 508/610 mm
Coil Weight: 3-10 tons
Production Capacity: 1500 tons per month
Surface Treatment: Oil/dry/passivation/pickling

Applications

Galvanized steel, PPGI, doors, household appliances, manufacturing, shipping, building construction, and various other industrial applications.

Company & Order Information

About Our Company:

Shandong Zhongcan Steel New Material Co., Ltd. is located in Taian City, Shandong Province. We welcome visits to our factory.

Available Sizes:

Cold rolled steel coil: 0.12-2.0mm × Width × Coil
Cold rolled steel sheet: 0.12-2.0mm × Width × Length

Can we send samples before order?

Yes, we provide free samples and are confident you will be satisfied with our product quality.

Delivery Terms:

EXW, FOB (Shanghai), or CIF to your discharge port.

Delivery Time:

Standard delivery: approximately 10 days. Color steel coil/sheet: typically about 30 days, with some sizes requiring approximately 30 days.
