Hastelloy C276 Nickel Alloy Round Bar Custom Cutting in Length with EN 10204-3.1 Certificate and Corrosion Resistance

Certification	ISO, AISI, ASTM, GB, EN
Minimum Order Quantity	50 kg
Price	US $40 / kg

Product Details

Diameter	5-300mm	Length	Within 6m/PC
Surface Treatment	Pickling	Tensile Strength	≥ 690 MPa
Yield Strength	≥ 283 MPa	Elongation	≥ 40%
Hardness	≤ 241 HB	Density	8.9 G/cm³
Melting Range	1325-1370°C	Nickel Content	52.0 - 60.0%
Molybdenum Content	15.0 - 17.0%	Chromium Content	14.5 - 16.5%
Tungsten Content	3.0 - 4.5%	Carbon Content	≤ 0.01%
Silicon Content	≤ 0.08%
Highlight	Custom Cutting in Length Hastelloy C276 Round Bar , EN 10204-3.1 Certificate Nickel Alloy Round Bar , Corrosion Resistant Alloy 276 Round Bar

Leave a Message

Product Description

Hastelloy C276 Nickel Alloy Round Bar

Premium nickel-molybdenum-chromium-tungsten alloy round bars with custom cutting capabilities and full EN 10204-3.1 certification for industrial applications.

Product Specifications

Diameter Range	5-300mm
Length	Custom cutting any length as requested
Surface Finish	Bright, black, pickling, polishing
Brand	DELTA
Services	Cutting, polishing
Minimum Order Quantity	2 Kgs
Other Available Forms	Bar, strip, coil, pipe, sheet, plate, wire, etc.

Material Overview

Hastelloy® C276 (UNS N10276, W.Nr. 2.4819) is a premium nickel-molybdenum-chromium-tungsten alloy renowned for its exceptional corrosion resistance across a wide range of aggressive chemical environments—both oxidizing and reducing. Our Hastelloy C276 round bars are precision-manufactured to meet international standards and can be custom-cut to your exact length requirements, ensuring seamless integration into your industrial applications.

Ideal for use in chemical processing, oil & gas, pollution control, and marine engineering, C276 round bars offer unmatched durability in the presence of chlorides, acids, and high-temperature corrosive media.

Chemical Composition

Element	Content (%)
Nickel (Ni)	52.0 - 60.0
Molybdenum (Mo)	15.0 - 17.0
Chromium (Cr)	14.5 - 16.5
Iron (Fe)	≤ 5.0
Tungsten (W)	3.0 - 4.5
Carbon (C)	≤ 0.01
Manganese (Mn)	≤ 1.00
Silicon (Si)	≤ 0.08
Phosphorus (P)	≤ 0.040
Sulfur (S)	≤ 0.030
Cobalt (Co)	≤ 2.5

Note: C + S ≤ 0.05% as per ASTM B574. This balanced composition provides superior resistance to pitting, crevice corrosion, and stress corrosion cracking—even in wet chlorine, hypochlorite, and chloride-rich environments.

Mechanical Properties

Property	Value
Tensile Strength (Rm)	≥ 690 MPa (100 ksi)
Yield Strength (Rp0.2)	≥ 283 MPa (41 ksi)
Elongation (A5)	≥ 40%
Hardness (HB)	≤ 241
Density	8.9 g/cm³
Melting Range	1325-1370°C (2417-2498°F)

These properties ensure excellent formability, weldability, and structural reliability under demanding service conditions.

Standards & Certifications

ASTM B574: Standard Specification for Nickel-Molybdenum Alloy Rod
ASME SB574
UNS N10276
W.Nr. 2.4819 (DIN/EN)
ISO 6208
NACE MR0175 / ISO 15156 (for sour service)
EN 10204-3.1 Certificate: Full mill test report with chemical & mechanical data, heat number traceability, and conformity declaration

All products undergo rigorous quality control, including ultrasonic testing (UT), dimensional inspection, and surface finish verification.

Key Features

Outstanding corrosion resistance in oxidizing & reducing acids (e.g., sulfuric, hydrochloric, phosphoric)
Resistant to pitting, crevice corrosion, and SCC in chloride environments
Weldable without post-weld heat treatment—no sensitization or carbide precipitation
Stable performance from cryogenic to 1000°C (short-term)
Custom lengths available: From 100 mm to 6000 mm (or as per client request)
Surface finishes: Peeled, ground, polished, or black (as-rolled)

Equivalent Grades

Region	Grade Designation
USA	UNS N10276, ASTM B574, ASME SB574
Germany	W.Nr. 2.4819, NiMo16Cr15W
China	NS3304
France	NC17D4M
Japan	NW 0276
ISO	ISO 15156 (for oil & gas)

Common Applications

Chemical Processing: Reactors, agitators, shafts, valves, pump parts
Flue Gas Desulfurization (FGD): Scrubber internals, dampers, fans
Oil & Gas: Downhole equipment, sour gas service components
Pharmaceutical & Pulp/Paper: Bleaching vessels, digesters
Waste Treatment: Acid neutralization systems
Marine Engineering: Seawater piping, heat exchangers
Nuclear Industry: Fuel reprocessing equipment

Its ability to withstand mixed acids, hot seawater, and contaminated process streams makes it indispensable in high-integrity systems.

Packaging & Shipping

To ensure safe delivery and prevent surface damage:

Bars are individually wrapped in anti-rust paper or VCI film
Bundled with steel straps and labeled with heat number, grade, dimensions, and certificate reference
Packed in wooden crates or pallets compliant with ISPM 15 for international shipping
Optional: Vacuum-sealed packaging for long-term storage
Shipping worldwide via air, sea, or land freight
Lead time: 3-15 days (stock items); 4-6 weeks for custom orders

All Shipments Include:

Commercial Invoice
Packing List
EN 10204-3.1 Certificate
Material Safety Data Sheet (MSDS)

Other Nickel-Based Alloys Available

Alloy Family	Common Grades
Hastelloy®	C22 (N06022), C2000 (N06200), B2/B3 (N10665/N10675), G30 (N06030), X (N06002)
Inconel®	600 (N06600), 625 (N06625), 718 (N07718), X-750 (N07750)
Incoloy®	800/800H (N08800), 825 (N08825), 925 (N09925)
Monel®	400 (N04400), K500 (N05500)
Pure Nickel	Nickel 200/201 (N02200/N02201)
Duplex Stainless Steels	2205 (S31803), 2507 (S32750), Zeron 100 (S32760)
