Hot Dipped Zinc Coated Steel Coil DX51 / 52 / 53 / 54D + Z for Container Plate with 1220*2440mm Specification
Product Details
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Zinc Coating | Z30 - Z275 |
| Aluminum-Zinc Coating | AZ40 - AZ180 | Painting Type | PE, HDP, SMP, PVDF |
| Surface Finish | Regular Spangle / Non-spangle | Coating Thickness | 20-25um/5-10um |
| Coating Layers | Above 2 Layer, Bottom 1 Layer | Pattern Thickness | 0.17 - 1.5mm |
| Heat Resistance | >300°C | Edge Type | Slit Edge |
| Sheet Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | ||
| Highlight | DX51 / 52 / 53 / 54D + Z Galvanized Steel Coil,1220*2440mm Specification Hot Dipped Zinc Coated Steel,Container Plate Application Prepainted Galvanized Steel Coil |
||
Product Description
Hot Dipped Zinc Coated Steel Coil / Strip / Sheet (DX51 / 52 / 53 / 54D + Z) for Outer Walls
High-quality hot dipped zinc coated steel products designed specifically for outer wall applications, available in various grades including DX51, DX52, DX53, and DX54D + Z.
Product Specifications
| Products Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness | Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or custom requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface | Galvanized: Regular spangle / non-spangle Zinc (Z30 - Z275) Galvalume: AZ40 - AZ180 Prepainted: PE, HDP, SMP, PVDF coating types |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Products Center
Prepainted Galvanized Steel Coil (PPGI)
Also known as color plate, PPGI uses cold rolled steel plate and galvanized steel plate as base plates. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, it undergoes continuous coating (roller coating method) followed by baking and cooling.
Benefits: Light weight, attractive appearance, excellent anti-corrosion performance, and direct processing capability. Ideal for construction industry, shipbuilding, vehicle manufacturing, home appliances, electrical industry, and more.
Galvanized Steel Coil
Surface zinc-coated steel plate providing economical and effective rust prevention. Approximately half of the world's zinc production is used in galvanization processes.
Surface Requirements: Available in regular spangle, small spangle, and big spangles. Products feature good appearance without harmful defects such as no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust.
Galvalume Steel Coil
Alloy composed of 55% aluminum, 43% zinc, and 2% silicon solidified at 600°C, forming a dense tetrad junction crystal structure of aluminized iron, silicon, and zinc.
- Excellent corrosion resistance - 3 times better than pure galvanized sheet
- Beautiful zinc flower surface decoration for building exterior panels
- Superior heat resistance - withstands temperatures over 300°C
- Ideal for chimney tubes, ovens, illuminators, and solar lampshades
Feature Products: Pattern Print Prepainted Steel Sheet
| Product | Pattern Print Prepainted Steel Sheet |
|---|---|
| Introduction | Color plate printed on galvanized plate or aluminized zinc plate using transfer printing or film covering technology |
| Features | Bright colors, wide variety including marble grain, camouflage, and wood grain patterns |
| Size | Thickness: 0.17 - 1.5mm (Width less than 1.5mm) |
| Color & Pattern | Customized as per client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um / 5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm / 610mm |
| Application | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
Trade Information
| MOQ | 5 Tons |
|---|---|
| Payment Term | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Information
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions including color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
Partnerships & Applications
We maintain strong cooperative relationships with major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin Zongcheng Steel. Our products are widely used in:
- Steel structure building
- Metal building materials
- Steel silo construction
- Ventilation pipes
- Mechanical and electrical housing
- Home appliance plates
- Elevator manufacturing
- Purification plates
- Automotive stamping parts
With over 8 years of average employee experience, we provide customized supply solutions and technical services for medium and large engineering projects worldwide.
Our Commitment: Adhering to the value concept of sustainable development, we are committed to providing perfect demand solutions and serving as China's premier high-end coating and plating steel products service provider.
