Customized JIS CGCC Soft Prepainted Galvanized Steel Sheet with 1220*2440mm Specification for Container Plate Application
Product Details
| Thickness | 0.12 - 3.0mm (Galvanized), 0.25 - 3.0mm (Galvalume), 0.12 - 1.2mm (Prepainted) | Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm Or Custom |
|---|---|---|---|
| Length | Custom Length | Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm Or 610mm | Surface Type | Regular Spangle / Non-spangle (Galvanized), AZ40 - AZ180 (Galvalume), PE/HDP/SMP/PVDF (Prepainted) |
| Zinc Coating | Z30 - Z275 (Galvanized) | Aluminum Content | 55% (Galvalume) |
| Silicon Content | 2% (Galvalume) | Coating Thickness | 20-25um/5-10um (Prepainted) |
| Coating Layers | Above 2 Layer, Bottom 1 Layer (Prepainted) | Heat Resistance | >300°C (Galvalume) |
| Sheet Dimensions | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Pattern Thickness | 0.17 - 1.5mm (Pattern Print) |
| Pattern Width | <1.5mm (Pattern Print) | ||
| Highlight | Customized JIS CGCC Soft PPGI Steel Coil,1220*2440mm Specification Color Coated Steel Plate,Container Plate Application Prepainted Galvanized Steel Sheet |
||
Product Description
White, Blue or Customized JIS, CGCC Soft (PPGI / PPGL) Prepainted Color Steel
Our prepainted color steel sheets are available in white, blue, or customized colors, manufactured to JIS and CGCC standards. These PPGI/PPGL products offer superior corrosion resistance and aesthetic appeal for various industrial applications.
Product Specifications
| Products Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
|---|---|
| Thickness | Galvanized steel sheet: 0.12 - 3.0mm Galvalume Steel Sheet: 0.25 - 3.0mm Prepainted Galvanized Steel Sheet: 0.12 - 1.2mm |
| Width | 914mm, 1000mm, 1200mm, 1219mm, 1220mm, 1250mm or according to customer requirements |
| Length | Custom length as per customer requirements |
| Coil Weight | 2 - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface | Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 Galvalume Steel Sheet: AZ40 - AZ180 Prepainted Galvanized Steel Sheet: Painting Type: PE, HDP, SMP, PVDF |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS, etc. |
Products Center
Prepainted Galvanized Steel Coil (PPGI)
Prepanited galvanized steel coil, also known as PPGI or color plate, uses cold rolled steel plate and galvanized steel plate as base materials. After surface pretreatment including degreasing, cleaning, and chemical conversion treatment, the coating is applied using continuous roller coating method, followed by baking and cooling.
Key Advantages: Light weight, attractive appearance, excellent anti-corrosion performance, and direct processing capability. These products serve as innovative raw materials for construction, shipbuilding, vehicle manufacturing, home appliances, and electrical industries, effectively replacing wood while enabling efficient construction, energy conservation, and pollution prevention.
Galvanized Steel Coil
Galvanized sheet refers to zinc-coated steel plate surface. Galvanizing represents an economical and effective rust prevention method, with approximately half of global zinc production used for this process.
Surface Requirements:
- Surface State: Varies based on coating process treatment methods including regular spangle, small spangle, and big spangles
- Quality Standards: Must have good appearance without defects affecting product use such as no plating, holes, cracks, scum, excessive thick plating, abrasion, chromic acid dirt, or white rust
Galvalume Steel Coil
Galvalume steel sheet consists of an aluminized zinc alloy structure composed of 55% aluminum, 43% zinc, and 2% silicon solidified at 600ºC. The complete structure forms a dense tetrad junction crystal of aluminized iron, silicon, and zinc.
- Corrosion Resistance: 3 times better than pure galvanized sheet
- Aesthetic Appeal: Beautiful zinc flower surface decoration suitable for building exterior panels
- Heat Resistance: Withstands temperatures over 300°C, similar to aluminum plated steel plate high temperature oxidation resistance
- Applications: Chimney tubes, ovens, illuminators, and solar lampshades
Feature Products: Pattern Print Prepainted Steel Sheet
| Product | Pattern Print Prepainted Steel Sheet |
|---|---|
| Introduction | Color plate printed on galvanized plate, aluminized zinc plate and other substrates using transfer printing or film covering technology |
| Features | Bright colors, wide variety including marble grain, camouflage, and wood grain printing patterns |
| Size | Thickness: 0.17 - 1.5mm, Width: less than 1.5mm |
| Color and Pattern | Customized according to client requirements |
| Base Material | Galvanized steel sheet / Galvalume steel sheet |
| Coating Thickness | 20-25um/5-10um |
| Coating Type | Above 2 layers, bottom 1 layer |
| Coil ID | Φ510mm/610mm |
| Application | Household appliances, furniture, doors and windows, indoor and outdoor decoration |
Trade Information
| MOQ | 5 Tons |
|---|---|
| Payment Term | TT or 100% LC at sight |
| Packing | Standard Sea Worthy Package |
| Loading Port | Shanghai Port, Qingdao Port, Tianjin Port |
| Container Loading | 20ft container FCL, LCL |
| Delivery Time | Within 15 days |
Company Information
Our company is a modern enterprise specializing in high-end coating plate processing, sales, and circulation, registered in Wuxi City. We offer comprehensive solutions for color coating, galvanized, aluminum zinc plating, zinc aluminum magnesium, and aluminum magnesium manganese high-end metal plates.
Strategic Partnerships
We maintain excellent cooperative relationships with several major domestic steel mills including Ye Hui (China), Baoshan Iron & Steel, Shougang, Magang, Hangang, Rizhao Steel, and Jiangyin ZongCheng Steel.
Application Fields
Our products are widely used in steel structure building, metal building materials, steel silo, ventilation pipes, mechanical and electrical housing, home appliance plate, elevator, purification plate, automotive stamping parts, and other industrial sectors.
Expert Team
Our employees average over 8 years of industry experience, enabling us to provide customized supply solutions and improve supply chain efficiency for our clients.
Our Commitment: We adhere to the value concept of sustainable development and are committed to providing customers with perfect demand solutions. As China's high-end coating and plating steel products service provider, we work hand-in-hand with domestic and foreign customers to create brilliant results.
