Hot Rolled 316LN Stainless Steel Plate - Corrosion Resistant High Strength SS Plate for Industrial Applications
Product Details
| Model NO. | 316LN | Shape | Flat |
|---|---|---|---|
| Technique | Hot Rolled | Surface Treatment | Pickling |
| Thickness | 1.0 - 80.0mm | Width | 1000mm 1219mm 1500mm 2000mm |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Alloy Type | Austenitic Stainless Steel |
| Grade | 316LN | Density | 8.0 G/cm³ |
| Tensile Strength | 520-720 MPa | Yield Strength | 205 MPa |
| Elongation | 40% (min) | Hardness | 170 HB |
| Modulus Of Elasticity | 200 GPa | ||
| Highlight | Hot Rolled Stainless Steel Plate,Corrosion Resistant SS Plate,High Strength 316LN Plate |
||
Product Description
316LN Stainless Steel Plate - Hot Rolled and Forged High-Performance SS Plate
Product Overview
316LN stainless steel is a high-performance, austenitic steel alloy known for its outstanding corrosion resistance, strength, and toughness. This low-carbon version of 316 stainless steel features nitrogen for improved strength and resistance to pitting, crevice corrosion, and stress corrosion cracking. Available in hot-rolled and forged forms, these plates ensure superior mechanical properties and structural integrity for demanding industrial applications.
Product Specifications
| Products Name | 316LN Stainless Steel Plate Sheet |
|---|---|
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316LN, 316TI, 317L, 321, 321H, 347, 348, 409, 410, 410S, 420, 430, 441, 904L, 630, 631, 254SMO, 654SMO, 253MA, 2205, 2304, 2507, etc. |
| Thickness | 0.6 - 80.0mm |
| Width | 1250mm, 1500mm, 1800mm, 2000mm, or custom sizes available |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, or custom lengths as required |
| Service | Laser Cutting |
| Form | Plate / Sheet |
| Cutting Shape | Round, Square, or any special shape as requested |
| Test Certificate | Yes |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA |
| Brand | TISCO, LISCO, BAOSTEEL, POSCO, JISCO |
Technical Specifications
| Parameter | Value |
|---|---|
| Alloy Type | Austenitic stainless steel |
| Grade | 316LN |
| Standard | ASTM A240, ASTM A276, ASTM A479, EN 10088 |
| Thickness Range | 3mm to 150mm |
| Width Range | 1000mm to 2500mm |
| Length Range | 2000mm to 6000mm |
| Density | 8.0 g/cm³ |
| Tensile Strength | 520-720 MPa |
| Yield Strength | 205 MPa |
| Elongation | 40% (min) |
| Hardness | 170 HB |
| Modulus of Elasticity | 200 GPa |
| Thermal Conductivity | 16.2 W/m*K |
| Melting Point | 1375-1400°C |
| Coefficient of Expansion | 16.0 × 10 /°C |
Key Features and Benefits
- Superior Corrosion Resistance: Exceptional resistance to chemicals including sulfuric acid, phosphoric acid, and seawater
- High Strength: Nitrogen content provides greater tensile and yield strength compared to standard 316 stainless steel
- Stress Corrosion Cracking Resistance: Enhanced resistance in chloride environments
- Versatile Applications: Ideal for chemical processing, marine engineering, medical devices, and food processing
- Temperature Resistance: Maintains strength and stability in high-temperature environments
Production Standards
- ASTM A240: Stainless steel plates for pressure vessels and corrosion-resistant applications
- ASTM A276: Standard specification for stainless steel bars and shapes
- ASTM A479: Stainless steel bars for boilers and high-temperature service
- EN 10088: European standard for stainless steel products
- ISO 9001: Quality management system standards
- NACE MR0175: For sour service applications and sulfide stress cracking resistance
Applications
- Marine and Offshore Structures: Excellent resistance to saltwater corrosion
- Chemical Processing: Heat exchangers, reactors, and piping systems for aggressive chemicals
- Aerospace Industry: Aircraft components requiring high stress and environmental resistance
- Food Processing Equipment: Corrosion resistance and easy cleaning properties
- Medical Devices: Non-reactive properties and biocompatibility
- Power Plants: High-temperature systems including steam turbines and boilers
Packaging and Shipping
Plates are carefully packaged with plastic film protection against moisture and dust, then placed in wooden or steel crates. Each package is clearly marked with grade, dimensions, and certification details. Global shipping available via sea, air, or land transport.
Shipping Lead Time: 7-14 days depending on region and order size
Handling & Storage: Store in clean, dry, well-ventilated areas on pallets to avoid surface damage
Handling & Storage: Store in clean, dry, well-ventilated areas on pallets to avoid surface damage
Frequently Asked Questions
What is the difference between 316L and 316LN stainless steel?
The main difference is nitrogen content. 316LN has added nitrogen which enhances strength, especially under extreme conditions, providing better resistance to stress corrosion cracking and improved overall performance compared to standard 316L stainless steel.
Can 316LN stainless steel be welded?
Yes, 316LN can be welded. It is recommended to use low-carbon filler material to prevent carbide precipitation during welding, which could affect corrosion resistance.
What is the maximum temperature that 316LN stainless steel can withstand?
316LN stainless steel can withstand temperatures up to 870°C (1600°F) intermittently and 925°C (1700°F) continuously without significant loss of strength.
Is 316LN stainless steel magnetic?
316LN stainless steel is non-magnetic in the annealed condition but may become slightly magnetic when cold-worked.
How should 316LN stainless steel be cleaned and maintained?
Use mild soap or detergent, warm water, and a soft cloth for cleaning. Avoid harsh chemicals or abrasive cleaners to maintain appearance and properties.
Can 316LN stainless steel be used in cryogenic applications?
Yes, 316LN performs well in cryogenic temperatures and is often used in liquefied natural gas (LNG) storage and transport applications.
What industries typically use 316LN stainless steel plates?
Industries include chemical processing, marine, aerospace, power generation, medical devices, and food processing due to superior corrosion resistance and high strength.
Conclusion
316LN Stainless Steel Plates offer superior strength, corrosion resistance, and versatility for demanding applications across multiple industries. Whether in marine, chemical, or medical sectors, this high-performance material ensures reliability and durability in harsh conditions. Available in hot-rolled and forged forms, these plates meet international standards and are packaged for maximum protection and efficiency.
