Polished Surface 34CrNiMo6 Alloy Steel Round Bar with High Tensile Strength for Mold Steel Applications
Product Details
| Diameter | 13 - 300mm | Length | 6m Or Custom |
|---|---|---|---|
| Surface Treatment | Polished | Tensile Strength | 1000 -1200 N/mm² |
| Hardness | 28-34HRC | Carbon Content | 0.30-0.38 |
| Manganese Content | 0.5-0.8 | Silicon Content | 0.40 Max |
| Phosphorus Content | 0.025 Max | Sulfur Content | 0.035 Max |
| Chromium Content | 1.3-1.7 | Molybdenum Content | 0.15-0.30 |
| Nickel Content | 1.3-1.7 | Quenching Temperature | 850°C |
| Tempering Temperature | 600°C | ||
| Highlight | Polished Surface Alloy Steel Round Bar,High Tensile Strength 34CrNiMo6 Steel Bar,Mold Steel Application 1.6582 Steel Round Bar |
||
Product Description
1.6582 Alloy Engineering Steel 34CrNiMo6 4337 - DIN 17200 EN 10083
1.6582 Alloy Engineering Steel | 34CrNiMo6 | 4337 - DIN 17200 EN 10083
| Products | Alloy Steel Round Bar |
| Diameter | 13 - 300mm |
| Length | 6m or custom cutting as request |
| Grade | Alloy Steel |
| Our Service | Cutting, polishing, packing, heat treatment |
| Brand | BAOSTEEL, XINGCHENG, DSS, CHONGQING, XNSS, HLXT, etc. |
| Standard | GB, ASTM, JIS, EN, DIN |
| Company Type | Storage company and process service |
34CrNiMo6 / 1.6582 Steel Overview
34CrNiMo6 / 1.6582 Steel is a heat treatable, low alloy steel used for a wide range of engineering parts. It is capable of being heat treated to produce a typical tensile strength of 1000-1200 N/mm², combined with good ductility and resistance to shock. This material features excellent hardenability, enabling it to be used for medium tensile strengths in fairly large sections, and attain good wear resistance with excellent impact properties at low temperatures. The material is readily machinable, allowing components to be put into service without the cost of further treatment. It can also be supplied in the annealed condition for increased machinability, requiring hardening and tempering. Typically supplied in the hardened and tempered condition with hardness 28-34HRC.
Standards and Equivalents
| Standard | Grade | Equivalent |
|---|---|---|
| BS EN 10083-3:2006 | 34CrNiMo6 / 1.6582 | ASTM A29:2004 - 4337 |
| BS EN 10250-3:2000 | 34CrNiMo6 / 1.6582 | - |
Chemical Composition
| Standard | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| BS EN 10083-3:2006 | 0.30-0.38 | 0.5-0.8 | 0.40 max | 0.025 max | 0.035 max | 1.3-1.7 | 0.15-0.30 | 1.3-1.7 |
| BS EN 10250-3:2000 | 0.30-0.38 | 0.5-0.8 | 0.40 max | 0.035 max | 0.035 max | 1.3-1.7 | 0.15-0.30 | 1.3-1.7 |
| ASTM A29:2004 (4337) | 0.30-0.40 | 0.6-0.8 | 0.20-0.35 | 0.035 max | 0.040 max | 0.70-0.90 | 0.20-0.30 | 1.65-2.00 |
Mechanical Properties
| Properties | < 16 mm | >16 - 40 mm | >40 - 100 mm | >100 - 160 mm | >160 - 250 mm |
|---|---|---|---|---|---|
| Yield Strength Re [N/mm²] | min. 1000 | min. 900 | min. 800 | min. 700 | min. 600 |
| Tensile Strength Rm [N/mm²] | 1200 - 1400 | 1100 - 1300 | 1000 - 1200 | 900 - 1100 | 800 - 950 |
| Elongation A [%] | min. 9 | min. 10 | min. 11 | min. 12 | min. 13 |
| Reduction of Area Z [%] | min. 40 | min. 45 | min. 50 | min. 55 | min. 55 |
| Toughness CVN [J] | min. 35 | min. 45 | min. 45 | min. 45 | min. 45 |
Heat Treatment
Quenched and Tempered (Q+T) of 34CrNiMo6 Steel
- Heat 34CrNiMo6 round steel slowly to the temperature of 850°C
- Soak at this hardening temperature and quench in oil
- Temper as soon as 34CrNiMo6 steels reach room temperature
- Heat uniformly to the suitable temperature
- Withdraw from the furnace and cool in the air
- The usual tempering temperature is 600°C, depending on actual requirements
Additional Processing Information
Forging
Hot forming temperature: 1100-900°C
Machinability
Machining is best done with this 1.6582 alloy steel in the annealed or normalized and tempered condition. It can be machined by all conventional methods.
Welding
The alloy materials can be fusion or resistance welded. Preheat and post heat weld procedures should be followed when welding this alloy by established methods.
Applications
EN DIN 34CrNiMo6 steel is used to make tools which demand good plasticity and high strength. It is typically selected for large size and important parts, including:
- Heavy machinery axle
- Turbine shaft blade
- High load transmission parts
- Fasteners
- Crank shafts
- Gears
- Heavily loaded parts for motor construction
Company Information
Our company specializes in all kinds of round steel, including materials from major steel mills such as Ling Steel, Xuan Steel, Benshan Steel, Tiangang, Shandong Luli Steel, Rongcheng Steel, Professional, Handan, Laigang, Jiyuan Steel and other major steel mills. We are designated agents in Tianjin with monthly sales of 40,000-60,000 tons of various steel products.
- More than 4 warehouses for stock storage
- Approximately 30 product grades kept in stock long-term
- Over 800 sizes available for short delivery times
- Dedicated processing warehouse for cutting, polishing, and heat treatment
- Global sales network serving various industries including machinery, standard parts, automobiles, gears, forging, and hardware tools
Popularly Used Grades
We manufacture a comprehensive range of steel grades including EN series, C series, S series, SAE/AISI standards, BS970 grades, EN 10088-3 grades, ASTM specifications, DIN standards, and GOST 4543-71 grades.
