GCr15 Steel Round Bar Bearing Steel Bar with Polished Surface OD 6-630mm for Mold Steel Application
Product Details
| Model NO. | GCr15 | Surface Treatment | Polished |
|---|---|---|---|
| Alloy Type | Alloy | Diameter Range | OD 6-630mm |
| Carbon Content | 0.95-1.05% | Silicon Content | 0.15-0.35% |
| Manganese Content | 0.25-0.45% | Chromium Content | 1.4-1.65% |
| Phosphorus Content | ≤0.025% | Sulfur Content | ≤0.025% |
| Molybdenum Content | ≤0.1% | Nickel Content | ≤0.3% |
| Copper Content | ≤0.25% | Hardness HBW | 179-207 |
| Forging Ratio | ≥ 4:1 | ||
| Highlight | Polished Surface Steel Round Bar,OD 6-630mm Bearing Steel Bar,Mold Steel Application GCr15 Steel Bar |
||
Product Description
GCr15 Steel Round Bar - SAE52100 Bearing Steel
GCr15 steel round bars, also known as SAE52100 bearing steel, EN 100Cr6, and DIN 1.2067, are high-performance bearing steel materials manufactured according to GB/T 18254 standards. This bearing steel offers exceptional cost-effectiveness and is widely utilized across various industrial applications.
Available Product Forms
- Hot rolled round bars and square bars
- Cold-drawing bars
- Forged bars
Primary Applications
GCr15 stainless steel round bars are engineered for demanding applications including internal combustion engine shafts, electromobile components, machine tool parts, tractor components, steel rolling machinery, sounding borers, railway vehicles, and mining equipment.
Product Specifications
We supply GCr15 hot rolled round bars with outer diameters ranging from 6mm to 80mm and forged round bars from 80mm to 1200mm. Forged square bars are available from 100mm to 1200mm. Standard tolerances include OD tolerance of 0-3mm and length tolerance of 0-20mm.
Manufacturing Process
Our GCr15 round bars undergo comprehensive production procedures: EAF arc furnace processing, LF purification affinage, VDF treatment, ingot steel formation (bottom gating/argon), forging, annealing, black polishing (turnery), GB/T6402-92 ΙΙ UT testing, and smooth edge sawing.
Chemical Composition (%) - Maximum Values
| Grade | C | Si | Mn | Cr | P | S | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| GB/T 18254 GCr15 | 0.95-1.05 | 0.15-0.35 | 0.25-0.45 | 1.4-1.65 | ≤0.025 | ≤0.025 | ≤0.1 | ≤0.3 | ≤0.25 |
Mechanical Properties
| Grade | Delivery State | Hardness (HBW, max) | Forging Ratio | Grain Size (level) | Nonmetal Ratio |
|---|---|---|---|---|---|
| GB/T 18254 GCr15 | Hot rolled, forged, various annealing states | 179-207 | ≥ 4:1 | ≥ 6 | ≤ 2.0 |
For inquiries about GB/T 18254 GCr15 round bars or other steel grades, please contact our technical sales team for comprehensive product information and pricing.
