Hot Rolled Bright Surface Stainless Steel Angle Bar 3030-100100 SS Angle Bar

Minimum Order Quantity	30 kg
Price	US $1.65-2.98 / kg

Product Details

Model NO.	201 304 316L 310S 2205	Shape	Angle
Technique	Hot Rolled	Surface Treatment	Bright
Specification	3030-100100	Grade	201 304 310S 316L 321 2205
Standard	ASTM GB DIN	Angle Bar Size	30303 - 20020010mm * 6m Length
Channel Bar Size	50303 - 20010010mm * 6m Length	Thickness Range	3-10mm
Length	6m	Weight Per Meter	0.894-15.0kg
Material	Stainless Steel	Processing Service	Cutting
Packing	Waterproof Paper Or Wooden Pallets
Highlight	Hot Rolled Stainless Steel Angle Bar , Bright Surface SS Angle Bar , 3030-100100 Steel Angle Bar

Leave a Message

Product Description

Stainless Steel Angle Bar & Channel Bar

High-quality 304, 316L, 310S, 2205 stainless steel angle bars and channel bars available in sizes ranging from 20x20mm to 100x100mm. Our products meet international standards and are suitable for various industrial applications.

Product Specifications

Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
Grades: 201, 304, 310S, 316L, 321, 2205
Standards: ASTM, GB, DIN
Angle Bar Size: 30×30×3 - 200×200×10mm × 6m length
Channel Bar Size: 50×30×3 - 200×100×10mm × 6m length
Service: Cutting
Packing: Waterproof paper surround or wooden pallets
Brand: TSINGSHAN

Stainless Steel Angle Bar Specifications

Size A×B (mm)	3mm	4mm	5mm	6mm	7mm	8mm	9mm	10mm
20×20	0.894	1.13	1.38
25×25	1.13	1.45	1.77	2.06
30×30	1.37	1.77	2.17	2.53
35×35	1.61	2.09	2.57	3.01
40×40	1.85	2.41	2.97	3.49
45×45	2.12	2.76	3.40	4.00
50×50	2.36	3.07	3.79	4.46	5.13	5.76	6.42	7.06
60×60			4.58	5.42	6.24	7.03
63×63			5.03	5.95	6.84	7.71	8.60	9.48
70×70			5.42	6.42	7.39	8.34	9.31	10.3
75×75			5.82	6.89	7.95	8.97	10.0	11.1
80×80				7.37	8.50	9.61	10.7	11.8
90×90				8.33	9.65	11.90	12.2	13.4
100×100				9.28	10.8	12.20	13.6	15.0

Weight per meter (kg)

Stainless Steel Channel Bar Specifications

Size H×B (mm)	3mm	4mm	5mm	6mm	7mm	8mm	9mm	10mm	12mm
40×20	1.79
50×25	2.27
60×30	2.74	3.56	4.37	5.12
70×35	3.23	4.21	5.17	6.08
80×40	3.71	4.84	5.96	7.03
90×45	4.25	5.55	6.83	8.05
100×50	4.73	6.18	7.62	8.98	10.3	11.7	13.0	41.2
120×60			9.20	10.9	12.6	14.2
130×65			10.1	11.9	13.8	15.5	17.3	19.1
140×70				12.9	14.9	16.8	18.8	20.7
150×75				13.9	16.0	18.1	20.2	22.2	26.3
160×80				14.8	17.1	19.3	21.6	23.8	28.1
180×90				16.7	19.4	22.0	24.5	27.0	32.0
200×100				18.6	21.6	24.5	27.4	30.2	35.8

Weight per meter (kg)

Company Overview

We are a comprehensive stainless steel enterprise specializing in wholesale, material processing, storage, and distribution. Located in Wuxi - the stainless steel trading center, with a total investment of 10 million yuan and annual sales exceeding 300 million yuan.

We maintain long-term cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribute stainless steel plates imported from Sweden, North America, South Africa, Japan, and Korea.

Material Range & Processing Capabilities

Available Materials: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205, 904L, high-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series.

Processing Equipment: Plasma cutting machines, coil material opening equipment, laser cutting machines, 8K mirror finishing, grinding wire drawing, film and titanium plating equipment.

Specialized Services: Thick plate cutting (up to 150mm), cutting rounds, squares, shaped parts, casting parts, forging parts. Custom orders available according to customer specifications.

Product Applications

Stainless steel angle bars and channel bars are primarily used for frame structures including:

High-voltage power transmission towers
Steel structure bridge frameworks
Tower crane columns and booms on construction sites
Workshop columns and beams
Air-conditioning and solar-powered shelf supports
Building structures and engineering construction
Ship beams and industrial furnaces

Our stainless steel products are widely used in machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, medical equipment, and various other industries.

Product Gallery
