Hot Rolled 304 316L 310S 2205 Stainless Steel Angle Bar in 30*30-100*100 Sizes
Product Details
| Model Number | 304 316L 310S 2205 | Shape | Angle |
|---|---|---|---|
| Technique | Hot Rolled | Surface Treatment | Bright |
| Specification Range | 30*30-100*100 | Material | 304 316 310s 2205 |
| Standard | AISI ASTM JIS | Side Length | 20-200mm |
| Thickness | 3-24mm | Quality Per Meter | 0.89-71.17kg/m |
| Equal Angle | Yes | Unequal Angle | Yes |
| HS Code | 7219340000 | Transport Package | Wooden Box |
| Chemical Composition | Not Specified | ||
| Highlight | Hot Rolled stainless steel angle bar,304 316L 310S 2205 angle steel bar,30*30-100*100 ss angle bar |
||
Product Description
Stainless Steel Angle Bar Overview
304, 316L, 310S, and 2205 stainless steel angle bars available in both equal and unequal configurations. These long strips of steel feature perpendicular legs forming angular shapes for structural applications.
Product Specifications
| Product Name | Stainless Steel Angle Bar |
| Material | 304, 316, 310S, 2205 |
| Price Terms | FOB, CIF, CFR, EXW |
| Standard | AISI, ASTM, JIS |
| Packing | According to Requirements |
| Certifications | ISO, SGS, BV |
| Delivery Time | 5-10 days (based on stock and order quantity) |
| Payment Terms | 30% deposit by T/T, 70% before shipment |
Applications
Stainless steel angle bars serve as essential structural components in various construction and engineering applications:
- Building beams and structural frameworks
- Bridge construction and support systems
- Transmission tower structures
- Hoisting and transportation machinery
- Shipbuilding and marine applications
- Industrial furnace construction
- Reaction towers and container racks
- Cable trench supports and power distribution pipes
- Bus support installation and warehouse shelving
Size Specifications
| Specification (mm) | Weight (kg/m) | Specification (mm) | Weight (kg/m) |
|---|---|---|---|
| 20×3 | 0.89 | 80×5 | 6.21 |
| 20×4 | 1.15 | 80×6 | 7.38 |
| 25×3 | 1.12 | 80×7 | 8.53 |
| 25×4 | 1.46 | 80×8 | 9.66 |
| 30×3 | 1.37 | 80×10 | 11.87 |
| 30×4 | 1.79 | 90×6 | 8.35 |
| 36×3 | 1.66 | 90×7 | 9.66 |
| 36×4 | 2.16 | 90×8 | 10.95 |
| 36×5 | 2.65 | 90×10 | 13.48 |
| 40×3 | 1.85 | 90×12 | 15.94 |
| 40×4 | 2.42 | 100×6 | 9.37 |
| 40×5 | 2.98 | 100×7 | 10.83 |
| 45×3 | 2.09 | 100×8 | 12.28 |
| 45×4 | 2.74 | 100×10 | 15.12 |
| 45×5 | 3.37 | 100×12 | 17.90 |
| 45×6 | 3.99 | 100×14 | 20.61 |
| 50×3 | 2.33 | 100×16 | 23.26 |
| 50×4 | 3.06 | 110×7 | 11.93 |
| 50×5 | 3.77 | 110×8 | 13.53 |
| 50×6 | 4.46 | 110×10 | 16.69 |
| 56×3 | 2.62 | 110×12 | 19.78 |
| 56×4 | 3.45 | 110×14 | 22.81 |
| 56×5 | 4.25 | 125×8 | 15.50 |
| 56×8 | 6.57 | 125×10 | 19.13 |
| 63×4 | 3.91 | 125×12 | 22.70 |
| 63×5 | 4.82 | 125×14 | 26.19 |
| 63×6 | 5.72 | 140×10 | 21.49 |
| 63×8 | 7.47 | 140×12 | 25.52 |
| 63×10 | 9.15 | 140×14 | 29.49 |
| 70×4 | 4.37 | 140×16 | 33.39 |
| 70×5 | 5.40 | 160×10 | 24.73 |
| 70×6 | 6.41 | 160×12 | 29.39 |
| 70×7 | 7.40 | 160×14 | 33.99 |
| 70×8 | 8.37 | 160×16 | 38.52 |
| 75×5 | 5.82 | 180×12 | 33.16 |
| 75×6 | 6.91 | 180×14 | 38.38 |
| 75×7 | 7.98 | 180×16 | 43.54 |
| 75×8 | 9.03 | 180×18 | 48.63 |
| 75×10 | 11.09 | 200×14 | 42.89 |
| 200×16 | 48.68 | ||
| 200×18 | 54.40 | ||
| 200×20 | 60.06 | ||
| 200×24 | 71.17 |
