316L Stainless Steel Plate Hot Rolled with Polished Surface 0.8 - 80.0mm Thick for Industrial Use

Certification	AISI
Minimum Order Quantity	50 kg
Price	US $3.3-3.9 / kg

Product Details

Model NO.	316L	Shape	Round
Technique	Hot Rolled	Surface Treatment	Polished
Thickness Range	0.8 - 80.0mm	Standard Size	12202440, 15003000, 15006000, 20006000mm
Carbon Content	≤0.03%	Chromium Content	16.0 - 18.0%
Molybdenum Content	2.00 - 3.00%	Nickel Content	10.0 - 14.0%
Tensile Strength	≥485 MPa	Yield Strength	≥170 MPa
Elongation	≥40%	Hardness HB	≤217
Max Service Temp	925 °C
Highlight	Hot Rolled Stainless Steel Plate , Polished Surface 316L Stainless Steel Plate , 0.8 - 80.0mm Thick SS Plate

Leave a Message

Product Description

316 Stainless Steel Plate Specifications

Product Details

Product Name: 316L Stainless Steel Plate

Standard: ASTM JIS GB EN DIN

Thickness: Cold Rolled 0.4 - 5.0mm, Hot Rolled 3.0 - 80.0mm

Standard Sizes: Cold Rolled 1000×2000mm, 1219×2438mm, 1500×3000mm | Hot Rolled 1500×6000mm, 1800×6000mm, 2000×6000mm

Brand: POSCO, TISCO, BAOSTEEL, JISCO

Other Available Grades: 201, 304, 309, 310, 317L, 321, 347, 410, 420, 430, 431, 441, 445, 630, 631, 2205, 2507, 904L, 254SMO, S31254, 253MA, etc.

Service: Cutting

Grade 316L is the low carbon version of 316 stainless steel, making it immune from sensitization (grain boundary carbide precipitation). This makes it extensively used in heavy gauge welded components (over about 6mm). There is typically no appreciable price difference between 316 and 316L stainless steel.

The austenitic structure provides excellent toughness, even down to cryogenic temperatures. Compared to chromium-nickel austenitic stainless steels, 316L offers higher creep, stress to rupture, and tensile strength at elevated temperatures.

Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
316L	Min	-	-	-	-	-	16.0	2.00	10.0	-
316L	Max	0.03	2.0	0.75	0.045	0.03	18.0	3.00	14.0	0.10

Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness HB (Max)
316L	485	170	40	217

Corrosion Resistance

Excellent performance in a range of atmospheric environments and many corrosive media - generally more resistant than 304. Subject to pitting and crevice corrosion in warm chloride environments, and to stress corrosion cracking above about 60°C. Considered resistant to potable water with up to about 1000 mg/L chlorides at ambient temperatures, reducing to about 500 mg/L at 60°C.

316 is typically regarded as the standard "marine grade stainless steel," but it is not resistant to warm seawater. In many marine environments, 316 does exhibit surface corrosion, usually visible as brown staining, particularly associated with crevices and rough surface finish.

Heat Resistance

Good oxidation resistance in intermittent service to 870°C and in continuous service to 925°C. Continuous use of 316 in the 425-860°C range is not recommended if subsequent aqueous corrosion resistance is important. Grade 316L is more resistant to carbide precipitation and can be used in the above temperature range. Grade 316H has higher strength at elevated temperatures and is sometimes used for structural and pressure-containing applications above about 500°C.

Heat Treatment

Solution Treatment (Annealing) - Heat to 1010-1120°C and cool rapidly. These grades cannot be hardened by thermal treatment.

Machining

316L stainless steel tends to work harden if machined too quickly. For this reason, low speeds and constant feed rates are recommended. 316L stainless steel is also easier to machine compared to 316 stainless steel due to its lower carbon content.

Hot and Cold Working

Hot Working: 316L stainless steel can be hot worked using the most common hot working techniques. Optimal hot working temperatures should be in the range 1150-1260°C, and certainly should not be less than 930°C. Post-work annealing should be carried out to induce maximum corrosion resistance.

Cold Working: Most common cold working operations such as shearing, drawing, and stamping can be performed on 316L stainless steel. Post-work annealing should be carried out to remove internal stresses.

Applications

Food preparation equipment particularly in chloride environments
Pharmaceuticals
Marine applications
Architectural applications
Medical implants, including pins, screws and orthopedic implants like total hip and knee replacements
Fasteners
