Hot Rolled SUS304 Mirror Stainless Steel Plate with PVC Coating for Decoration and Kitchenware
Product Details
| Model NO. | 304 | Shape | Flat |
|---|---|---|---|
| Technique | Hot Rolled | Surface Treatment | Polished |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Thickness | Cold Rolled:0.4mm-3mm Hot Rolled: 3.0mm-100mm |
| Width | 1000 1219mm 1250mm 1500mm 1800mm 2000mm | Length | 1000mm-6000mm |
| Material | Stainless Steel | Finish | 2B, BA, HL, Mirror, NO1, NO 4, 8K |
| Carbon Content | 0.08 Max (304), 0.03 Max (304L), 0.04-0.10 (304H) | Nickel Content | 8.00 - 10.50 (304), 8.00 - 12.00 (304L), 8.00 - 10.50 (304H) |
| Chromium Content | 18.00 - 20.00 | Tensile Strength | 520 MPa Min (304), 485 MPa Min (304L), 520 MPa Min (304H) |
| Hardness | HB 202 Max (304), HB 183 Max (304L), HB 202 Max (304H) | ||
| Highlight | Hot Rolled Stainless Steel Plate,SUS304 Mirror Stainless Steel Plate,PVC Coating SS Plate |
||
Product Description
Hot Rolled SUS304 Mirror Stainless Steel Plate
Slit edge with common PVC coating for superior protection and performance.
Product Specifications
| Product Name | Stainless Steel Plate |
| Thickness | Cold rolled: 0.4mm-3mm | Hot rolled: 3.0mm-100mm |
| Width | 1000mm, 1219mm, 1250mm, 1500mm, 1800mm, 2000mm or customized |
| Length | 1000mm-6000mm or as requested |
| Material | Stainless Steel |
| Finish | 2B, BA, HL, Mirror, NO1, NO4, 8K |
| Standard | ASTM, AISI, DIN, EN, GB, JIS |
Available Materials
200 Series: 201, 202, 202cu, 204
300 Series: 301, 302, 303, 304, 304L, 310, 310S, 316, 316L
400 Series: 409, 409L, 410, 420, 430, 431, 439
Others: 2205, 2507, 904L, 317L, 254SMO, 253MA, 630, etc.
300 Series: 301, 302, 303, 304, 304L, 310, 310S, 316, 316L
400 Series: 409, 409L, 410, 420, 430, 431, 439
Others: 2205, 2507, 904L, 317L, 254SMO, 253MA, 630, etc.
Brands
TISCO, BAOSTEEL, ZPSS, LISCO, JISCO
Applications
Decoration Industry, Kitchenware, Building, Elevator
304 Stainless Steel Overview
Grade 304 is the most commonly used stainless steel. It is an austenitic, corrosion-resistant steel with excellent strength, toughness, fabrication characteristics and weldability. The low carbon version, 304L, may be required for full corrosion resistance when thicker sections are welded. The 304H version has a guaranteed minimum carbon content, which ensures good strength at high temperatures.
Typical Applications
- Brewing and dairy equipment
- Evaporators, drums, barrels
- Heat exchangers
- Hospital equipment
- Refrigeration parts
- Chemical and food processing
- Shop fittings, bench tops, kitchens
- Kitchen utensils, sinks, wash troughs
- Hand rails, dishwashers, clothes dryers
- Ovens, heating trays, air conditioning equipment
- Guttering and rain water goods
- Counters and display cabinets
- Commercial oven hoods, beer barrels
Chemical Composition
| Grade | Carbon | Silicon | Manganese | Phosphorus | Sulphur | Nickel | Chromium | Nitrogen |
|---|---|---|---|---|---|---|---|---|
| 304 Spec (max) | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 8.00-10.50 | 18.00-20.00 | 0.10 |
| 304 Typical | 0.045 | 0.49 | 1.22 | 0.028 | 0.005 | 8.3 | 18.2 | 0.045 |
| 304L Spec (max) | 0.03 | 0.75 | 2.00 | 0.045 | 0.030 | 8.00-12.00 | 18.00-20.00 | 0.10 |
| 304L Typical | 0.020 | 0.42 | 1.46 | 0.028 | 0.005 | 9.1 | 18.3 | 0.048 |
Mechanical Properties
| Grade/Thickness | 0.2% Proof Stress (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness HB (max) |
|---|---|---|---|---|
| 304 Spec (min) | - | 205 | 520 | 40 |
| 304 0.3-3.5mm | 260 | 660 | 55 | 160 |
| 304 3.6-6mm | 250 | 600 | 55 | 160 |
| 304 >6mm | 240 | 580 | 55 | 155 |
Available Products
We can supply 304 stainless steel as plate, coil, sheet, strip, round, hexagon, flat bar, angles, tube, pipe and welding consumables.
Finishing Options
No1 (hot rolled, annealed and pickled), 2D (cold rolled), 2B (cold rolled, skin passed), N4 (polished), BA (bright annealed). Flat products are available surface protected with white polyethylene (PE) film. Protection with blue poly vinyl chloride (PVC) for deep drawing or black PVC (for heavy forming) is also available.
Corrosion Resistance
Grade 304 stainless steel has excellent corrosion resistance in many environments. It gives good service in atmospheric conditions, resisting most environments except for marine conditions, or where industrial pollution is heavy. Best appearance is maintained where the design allows even rain washing of the surface. Pitting and crevice corrosion may occur at higher chloride content, and 200 ppm is accepted as the upper limit. Grade 304 stainless steel is not generally used in seawater.
Primary Applications
Kitchenware, household electrical appliances, building decoration due to low cost, good corrosion resistance and formability.
- Architecture Building: Surface, Pillar, Window frame, Stair hand-rail
- Kitchen Utensil: Washing machine drum, Gas range stove, Plate, Housewares, Hollowware
- Others: Computer components, Automotive trim
Packing & Delivery
Stainless steel coil is packed with kraft paper, plastic plate and wooden pallet. Packaged strongly to avoid damage during transportation, and can be customized according to regulations and customer requests. Products are clearly tagged on the outside for easy identification and quality information.
Shipping Information
| MOQ | 1 Ton |
| Price Term | FOB |
| Payment | L/C at sight or 30% TT as deposit |
| Delivery Time | 20-30 days after receiving deposit by T/T or L/C |
| Sample | Samples free, express charges borne by customer |
Product Images
About Our Company
Our company is a professional stainless steel trading company integrating sales, processing, distribution and storage. We always carry out the "high efficiency, mutual benefit, service first" business philosophy and service purpose, adhere to reasonable and preferential prices, beyond customer expectations of service, to provide the society with a variety of inexpensive quality stainless steel products.
The company specializes in the distribution of domestic and imported cold and hot rolled stainless steel coils and plates, operating steel types: 201, 202, 304, 321, 316L, 444, 409, 430, 309S, 310S and more. Products come from leading manufacturers including Shanxi TISCO, Guangzhou Lianzhong, Zhangjiagang Pohang, Ningbo Baoxin, AvestaPolarit, Outokumpu, and POSCO.
We provide additional processing services including opening, grinding, slitting, and shearing. Our products are widely used in chemical machinery, pharmaceutical machinery, food machinery, drying equipment, environmental protection equipment, metallurgical machinery, pressure vessels, and kitchen equipment.
