High Strength 321 Stainless Steel Plate 0.6 - 60.0mm SS Plate for Industrial Applications
Product Details
| Model NO. | 321 | Shape | Flat |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Thickness Range | 0.6 - 60.0mm |
| Cold Rolled Thickness | 0.5-3.0 Mm | Hot Rolled Thickness | 3.0-80.0 Mm |
| Standard Size | 1000*2000mm, 1219*2438mm, 1500*3000mm, 1500*6000mm, 1800*6000mm, 2000*6000mm | Finish Options | SATIN, 2B, 2D, BA NO (8), CR, HR, No.1, 1D, No.4, BA, 8K, Hairline, Brush, Mirror |
| Tensile Strength | 515 MPa Min | Yield Strength | 205 MPa Min |
| Elongation | 40% In 50 Mm Min | Hardness Rockwell B | 95 Max |
| Hardness Brinell | 217 Max | ||
| Highlight | High Strength Stainless Steel Plate,321 Stainless Steel Plate,0.6 - 60.0mm SS Plate |
||
Product Description
High Strength 321 Stainless Steel Sheet Plate
Available in thickness range of 0.6 - 60.0mm, designed for industrial applications requiring superior strength and corrosion resistance.
Product Specifications
| Product Type | 321 Stainless Steel Sheet, 321 Stainless Steel Plate |
|---|---|
| Specification | ASTM A240 / ASME SA240 JIS G4305 / EN 10088-2 / GB 24511 |
| Thickness | Cold rolled: 0.5-3.0 mm Hot rolled: 3.0-80.0 mm |
| Standard Size | Cold rolled: 1000×2000mm, 1219×2438mm Hot rolled: 1500×3000mm, 1500×6000mm, 1800×6000mm, 2000×6000mm |
| Finish | SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror, etc. |
| Brand | TISCO, BAOSTEEL, POSCO, JISCO, DONGTE |
| Forms / Shapes | Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
| Other Trade Names | SS 321, SUS 321, Inox 321, DIN 1.4541, UNS S32100, AISI 321, SAE 321 Sheet |
| Our Services | Laser cutting, Fire cutting, bending, Surface polishing, PVC film cover |
Material Overview: Grades 321 and 347 are basic austenitic 18/8 steel (Grade 304) stabilized by Titanium (321) or Niobium (347) additions. These grades resist intergranular corrosion after heating within 425-850°C. Grade 321 is ideal for applications up to 900°C, offering high strength, scaling resistance, phase stability, and subsequent aqueous corrosion resistance.
Grade 321H
A modification of 321 with higher carbon content for improved high-temperature strength.
Welding Considerations
Grade 321 is not recommended as a welding consumable due to poor titanium transfer across high-temperature arcs. Grade 347 is the standard consumable for welding 321, as niobium performs the same carbide stabilization task effectively.
Material Properties
Like other austenitic grades, 321 and 347 offer excellent forming and welding characteristics, outstanding toughness even at cryogenic temperatures, and do not require post-weld annealing. Note: Grade 321 does not polish well and is not recommended for decorative applications.
Chemical Composition
Typical compositional ranges for grade 321 stainless steel:
| Grade | C | Mn | Si | P | S | Cr | Ni | Other |
|---|---|---|---|---|---|---|---|---|
| 321 | ≤0.08 | ≤2.00 | ≤0.75 | ≤0.045 | ≤0.030 | 17.0-19.0 | 9.0-12.0 | Ti=5(C+N) min, ≤0.70 |
| 321H | 0.04-0.10 | ≤2.00 | ≤0.75 | ≤0.045 | ≤0.030 | 17.0-19.0 | 9.0-12.0 | Ti=4(C+N) min, ≤0.70 |
Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Rockwell B (HR B) max | Brinell (HB) max |
|---|---|---|---|---|---|
| 321 | 515 | 205 | 40 | 95 | 217 |
| 321H | 515 | 205 | 40 | 95 | 217 |
Grade Specification Comparison
| Grade | UNS No | British BS | Euronorm No | Japanese JIS |
|---|---|---|---|---|
| 321 | S32100 | 321S31 | 1.4541 | SUS 321 |
| 321H | S32109 | 321S51 | 1.4878 | SUS 321H |
Typical Applications
- Aircraft piston engine manifolds
- Expansion joints
- Firearms production
- Thermal oxidizers
- Refinery equipment
- High temperature chemical process equipment
Product Gallery
About Our Company
GMS is a medium-sized professional company integrating wholesale sales and processing of stainless steel materials, providing customers with comprehensive one-stop services including sales, processing, and logistics distribution.
Our products serve numerous industries including nuclear power engineering, petrochemical, electric furnace, boiler, pressure vessel, electric heating equipment, textile, pharmaceutical, mechanical equipment, kitchen equipment, solar energy, and papermaking equipment, with customers nationwide.
Main products include: 321, 310s, 309S, 316L, 304, 316TI, 410S, 202, 201, 904L, 317L, 2205, 2304 duplex stainless steel, as well as 800H, 600H high nickel alloys. We maintain standing stock of over 3000 tons and can arrange special orders for unique steel types and specifications.
Additional services include embossing (domestic and Japanese), mirror polishing, plate polishing, grinding, flattening, and cutting (laser, water knife, plasma) to meet diverse customer requirements and achieve one-stop procurement services.
