321 Stainless Steel Plate Cold Rolled Sheet for Chemical Industrial Applications

Certification	AISI
Minimum Order Quantity	40 kg
Price	US $2.36-3.36 / kg

Product Details

Model Number	321	Shape	Flat
Technique	Cold Rolled	Surface Treatment	Bright
Thickness Range	0.6 - 16.0mm	Cold Rolled Thickness	0.5-3.0 Mm
Hot Rolled Thickness	3.0-80.0 Mm	Standard Size	12202440, 15003000, 15006000, 20006000mm
Finish Options	SATIN, 2B, 2D, BA NO (8), CR, HR, No.1, 1D, No.4, BA, 8K, Hairline, Brush, Mirror	Tensile Strength	515 MPa Min
Yield Strength	205 MPa Min	Elongation	40% Min
Hardness Rockwell B	95 Max	Hardness Brinell	217 Max
Composition	C 0.08 Max, Mn 2.00 Max, Si 0.75 Max, P 0.045 Max, S 0.030 Max, Cr 17.0-19.0, Ni 9.0-12.0, N 0.10 Max, Ti 5(C+N)-0.70
Highlight	321 Stainless Steel Plate , Cold Rolled Stainless Steel Sheet , Chemical Industrial Stainless Steel Plate

Leave a Message

Product Description

INOX 321 Stainless Steel Plate & Sheet

High-quality 321 stainless steel plates and sheets with thickness range of 0.6-16.0mm, specifically designed for chemical industrial applications requiring superior corrosion resistance and high-temperature stability.

Product Specifications

Product Type: 321 Stainless Steel Sheet, 321 Stainless Steel Plate
Specification: ASTM A240 / ASME SA240 JIS G4305 / EN 10088-2 / GB 24511
Thickness: Cold rolled 0.5-3.0 mm | Hot rolled 3.0-80.0 mm
Standard Sizes: Cold rolled 1000×2000mm, 1219×2438mm | Hot rolled 1500×3000mm, 1500×6000mm, 1800×6000mm, 2000×6000mm
Finish: SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror
Brand: TISCO, BAOSTEEL, POSCO, JISCO, DONGTE
Forms / Shapes: Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate
Other Trade Names: SS 321, SUS 321, Inox 321, DIN 1.4541, UNS S32100, AISI 321, SAE 321 Sheet
Our Services: Laser cutting, Fire cutting, bending, Surface polishing, PVC film cover

Material Characteristics

Grades 321 and 347 are austenitic 18/8 steels (based on Grade 304) stabilized by Titanium (321) or Niobium (347) additions. These grades resist intergranular corrosion after heating within the carbide precipitation range of 425-850°C. Grade 321 is ideal for applications up to 900°C, offering high strength, scaling resistance, phase stability, and subsequent aqueous corrosion resistance.

Grade 321H: Modified version with higher carbon content for improved high-temperature strength.
Welding Note: Titanium doesn't transfer well across high-temperature arcs, so grade 347 is recommended as welding consumable for 321 materials.
Forming & Welding: Excellent forming and welding characteristics, readily brake or roll-formed with outstanding welding properties. Post-weld annealing not required.
Toughness: Excellent toughness even at cryogenic temperatures.
Surface Finish: Does not polish well, not recommended for decorative applications.

Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Ni	Other
321	0.08 max	2.00 max	0.75 max	0.045 max	0.030 max	17.0-19.0	9.0-12.0	Ti=5(C+N) min, 0.70 max
321H	0.04-0.10	2.00 max	0.75 max	0.045 max	0.030 max	17.0-19.0	9.0-12.0	Ti=4(C+N) min, 0.70 max

Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness Rockwell B max	Hardness Brinell (HB) max
321	515	205	40	95	217
321H	515	205	40	95	217

Grade Specification Comparison

Grade	UNS No	Old British BS	Euronorm No	Japanese JIS
321	S32100	321S31	1.4541	SUS 321
321H	S32109	321S51	1.4878	SUS 321H

Typical Applications

Aircraft piston engine manifolds
Expansion joints
Firearms production
Thermal oxidizers
Refinery equipment
High temperature chemical process equipment

Product Gallery

About Our Company

GMS is a medium-sized professional company integrating wholesale sales and processing of stainless steel materials, providing customers with comprehensive one-stop services including sales, processing, and logistics distribution.

Our products primarily serve nuclear power engineering, petrochemical, electric furnace, boiler, pressure vessel, electric heating equipment, textile, pharmaceutical, mechanical equipment, kitchen equipment, solar energy, papermaking equipment and many other industries, with customers nationwide.

Main Products: 321, 310s, 309S, 316L, 304, 316TI, 410S, 202, 201, 904L, 317L, 2205, 2304 duplex stainless steel, as well as 800H, 600H high nickel alloys. We maintain standing stock of over 3000 tons and can arrange special orders for unique steel types and specifications.

Value-Added Services: Embossing (domestic and Japanese), mirror polishing, plate polishing, grinding, flattening, cutting (laser, water knife, plasma) and other processing services to meet diverse customer requirements and achieve one-stop procurement solutions.
