321 Stainless Steel Plate Hot Rolled Heat Resistant for Pressure Vessels Alloy 321 Plate

Certification	AISI
Minimum Order Quantity	50 kg
Price	US $2.35-4.65 / kg

Product Details

Model NO.	321	Shape	Flat
Technique	Cold Rolled	Surface Treatment	Bright
Specification	12202440, 15003000, 15006000, 20006000mm	Thickness	0.1 To 100 Mm
Width	10-2500mm	Length	2m, 2.44m, 3m, Or As Required
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard	Yield Strength	30 Ksi
Tensile Strength	75 Ksi	Elongation	40%
Density	0.286 Lb/in3	Modulus Of Elasticity	28.0 X 106 Psi
Thermal Conductivity	9.3 Btu/ft Hr ˚F
Highlight	Heat Resistant Stainless Steel Plate , Hot Rolled 321 Stainless Steel Plate , Pressure Vessel Grade Alloy 321 Plate

Leave a Message

Product Description

321 Stainless Steel Plate Hot Rolled for Pressure S32168

Alloy 321/321H Heat Resistant Stainless Steel Plate

Product Overview

Grade 321/321H stainless steel is a titanium-stabilized alloy designed for high-temperature service in the 1000-1600°F range. This material offers optimal resistance to intergranular corrosion and polythionic acid stress corrosion cracking when properly stabilized.

This stainless steel grade is readily weldable using common methods including submerged arc welding, with recommended fillers being AWS ER347 bare wire and E347 covered electrodes. It features a machinability rating of 45% relative to AISI B1112.

Available Product Forms

Sheet, Plate, Coil, Strip
Wire, Pipe, Tube, Bar
Profile, Round, Flat, Square, Hexagonal

Specifications & Dimensions

Standards & Certifications

Grade 321/321H
ASTM A240, ASME SA240, BS EN 10028-7, BS EN 10088-2, BS EN 10088-4
EN 10088/2, EN 10088/4 with CE Marking
NACE MR 0175/ISO 15156 Certification

Product Type	321 Stainless Steel Sheet, 321 Stainless Steel Plate
Specification	ASTM A240 / ASME SA240
International Standards	ASTM A480, ASTM A959, ASME IID, EN ISO 9445, EN ISO 18286, EN 10051, EN 10088-1, ISO 15510
Dimensions	Cold rolled: 0.5-6.4 mm \| Hot rolled: 3.0-10.0 mm
Thickness	0.1 to 100 mm
Width	10-2500mm
Length	2m, 2.44m, 3m, or as required

Dimension Ranges

Width: 600mm - 2030mm
Thickness: 0.1 - 120.0mm
Length: 300 - 6000mm (Max 18000mm)

Surface Finishes

No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating, color-coating, embossing

Applications

Aircraft piston engine manifolds
Expansion joints
Firearms production
Thermal oxidizers
Refinery equipment
High temperature chemical process equipment

Material Properties

Chemical Composition (wt%)

Element	321
Carbon	0.08
Chromium	17.0-19.0
Nickel	9.0-12.0
Manganese	2.00
Silicon	0.75
Titanium	5(C+N) min / 0.70 max

Mechanical Properties

Property	321
Yield Strength, min. (ksi)	30
Tensile Strength, min. (ksi)	75
Elongation, min. (%)	40
Hardness, max. (Rb)	95

Physical Properties

Property	321 Data
Density, lb/in³	0.286
Modulus of Elasticity, psi	28.0 x 10⁶
Coefficient of Thermal Expansion, 68-212˚F, /˚F	9.2 x 10⁻⁶
Thermal Conductivity, Btu/ft hr ˚F	9.3

International Equivalents

Common international equivalents include: UNS S32100, AISI 321, DIN 1.4541, EN X6CrNiTi18-10, JIS SUS321, GOST 08X18H10T, and GB 0Cr18Ni11Ti.

Alternative Materials

Grade	Alternative Application
304L	When resistance to intergranular corrosion is required without high-temperature strength needs
3CR12	For mild high-temperature environments up to approximately 600°C
304H	For mild high-temperature environments up to approximately 800°C
310	For operating environments up to 1100°C
