904L Stainless Steel Plate for Pressure Vessel Anti Acid Hot Rolled UNS N08904
Product Details
| Model NO. | 904L | Shape | Flat |
|---|---|---|---|
| Technique | Hot Rolled | Surface Treatment | Polished |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Thickness Range | 3.0 - 30.0mm |
| Width Range | Within 2000mm | Length Range | Within 8000mm |
| Standard | ASTM A240 | Standard Size | 1500 X 6000mm |
| Surface | NO.1 | Edge | Slit Edge |
| Carbon Content | 0.02 | Manganese Content | 2.00 |
| Nickel Content | 23.0-280 | ||
| Highlight | Pressure Vessel Stainless Steel Plate,Anti Acid 904L Stainless Steel Plate,Hot Rolled UNS N08904 Stainless Steel Plate |
||
Product Description
904L Stainless Steel Plate for Pressure Vessels & Acid Resistance
Premium UNS N08904 stainless steel plates designed for demanding industrial applications requiring exceptional corrosion resistance.
Product Specifications
| Thickness | 3.0 - 30.0mm |
| Width | Within 2000mm |
| Length | Within 8000mm |
| Standard | ASTM A240 |
| Standard Size | 1500 x 6000mm |
| Surface | NO.1 |
| Edge | Slit Edge |
| Manufacturer | BAOSTEEL |
Material Overview
Grade 904L stainless steel is a non-stabilized austenitic stainless steel with low carbon content. This high-alloy stainless steel contains added copper to improve resistance to strong reducing acids such as sulphuric acid. The material offers excellent resistance to stress corrosion cracking and crevice corrosion, while being non-magnetic with superior formability, toughness, and weldability.
Key Features of Grade 904L
- Non-magnetic properties
- Superior corrosion resistance compared to Type 316L and 317L
- Excellent resistance to sulphuric, phosphoric, and acetic acids
- High resistance to crevice and stress corrosion cracking
- Excellent formability and weldability
Chemical Composition
| Element | Content (%) |
|---|---|
| C | 0.02 |
| Mn | 2.00 |
| Si | 1.0 |
| P | 0.045 |
| S | 0.035 |
| Cr | 19.0-23.0 |
| Mo | 4.0-5.0 |
| Ni | 23.0-28.0 |
| Cu | 1.0-2.0 |
Typical Applications
- Cooling equipment for seawater
- Chemical processing of sulphuric, phosphoric, and acetic acids
- Heat exchangers and condenser tubes
- Gas washing systems
- Control and instrumentation
- Oil and gas industry equipment
- Pharmaceutical production
- Wiring in electrostatic precipitators
Available Stock Sizes
| No. | Thickness (mm) | Size |
|---|---|---|
| 1 | 2.0 | 1219×2438mm |
| 2 | 2.5 | 1219×2438mm |
| 3 | 3.0 | 1219×2438mm / 1500×6000mm |
| 4 | 4.0 | 1500×6000mm |
| 5 | 5.0 | 1500×6000mm |
| 6 | 6.0 | 1500×6000mm |
| 7 | 8.0 | 1500×6000mm (1800/2000mm width) |
| 8 | 10.0 | 1500×6000mm (1800/2000mm width) |
| 9 | 12.0 | 1500×6000mm (1800/2000mm width) |
| 10 | 14.0 | 1500×6000mm (1800/2000mm width) |
| 11 | 16.0 | 1500×6000mm (1800/2000mm width) |
| 12 | 18.0 | 1500×6000mm |
| 13 | 20.0 | 1500×6000mm |
| 14 | 22.0 | 1500×6000mm |
| 15 | 24.0 | 1500×6000mm |
| 16 | 26.0 | 1500×6000mm |
| 17 | 28.0 | 1500×6000mm |
| 18 | 30.0 | 1500×6000mm |
