Corrosion Resistant Bright Annealed ASTM B575 Hastelloy C276 Sheet and Plate
Product Details
| Model NO. | Hastelloy C276 | Shape | Flat |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Production Capacity | 50000kgs |
| Thickness Range | 0.1mm To 100 Mm | Width Range | 10-2500mm |
| Hardness Options | Soft, Hard, Half Hard, Quarter Hard, Spring Hard | Temper | Annealed |
| Condition | Polished On Both Sides | Finish Options | Hot Rolled Plate (HR), Cold Rolled Sheet (CR), 2B, 2D, BA NO(8), SATIN |
| Length Options | 2m, 2.44m, 3m, Or As Required | Surface Finish | No.1, 2B, BA, No.3 |
| HS Code | 75062000 | ||
| Highlight | Corrosion Resistant Hastelloy C276 Sheet,Bright Annealed Hastelloy C276 Plate,ASTM B575 Hastelloy Alloy Sheet |
||
Product Description
Hastelloy Alloy Plate Annealed Hastelloy C276 Sheet
ASTM B 575 Corrosion Resistant Bright Annealed Hastelloy C276 Super Alloy Sheet Plate
Hastelloy C-276 is considered one of the most versatile corrosion-resistant alloys available, offering excellent performance in numerous chemical process environments. This alloy demonstrates superior resistance to ferric and cupric chlorides, hot contaminated organic and inorganic media, chlorine, formic and acetic acids, acetic anhydride, seawater, brine, hypochlorite, and chlorine dioxide solutions.
Alloy C-276 resists formation of grain boundary precipitates in the weld heat-affected zone, making it suitable for most chemical processes in the as-welded condition. The material provides excellent resistance to pitting and stress corrosion cracking.
Available Forms
- Sheet
- Plate
- Bar
- Pipe & Tube (welded & seamless)
- Wire
Specifications and Dimensions
| Hastelloy C276 Sheet ASTM Specification | ASTM B 575; ASTM B 906; ASME SB 575; ASME SB 906, ISO 6208, DIN 17750, VdTÜV 400/12.98 |
| Alloy C276 Plate Specification | MSRR, AMS, BS, ASTM B575 / ASME SB575 |
| Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", Cut to size available |
| Thickness | 0.1mm to 100 mm |
| Width | 10-2500mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| Temper | Annealed |
| Condition | Polished on both sides |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Quality Assurance
- Huge Stock, Timely delivery
- Raw Materials Certificate
- EN 10204/3.1B
- 100% Radiography Test Report
- High special strength, high melt point
- Third Party Inspection Report
- Excellent corrosive resistance, good thermal resistance
- Customer support after-sales service
- Strict Control from Raw Material to Finished Hastelloy C276 plate
Profiling Services
We provide comprehensive profiling services using multiple methods:
- Plasma Plate Cutting
- Laser Plate Cutting
- Oxy-propane Flame Cutting
Product Specialization
- Hastelloy C276 Sheet: material under 3/16" [5.00 mm] in thickness and 24" [600 mm] and over in width
- Hastelloy C276 Plate: material 3/16" [5.00 mm] and over in thickness and over 10" [250 mm] in width
- Hastelloy C276 Strip: cold-rolled material under 3/16" [5.00 mm] in thickness and under 24" [600 mm] in width
- Hastelloy C276 Clad plate: composite steel plate made by bonding Hastelloy C276 plate
- Free Quote, Inquiry answered within 24 hours
Dimension Range
| Width | 914~2030 mm |
| Thickness (Cold rolled Sheet) | 0.1~6.0 mm |
| Thickness (Hot rolled Sheet) | 3MM~100 mm |
| Length | 300~6000 mm |
| Surface Finish | No.1, 2B, BA, No.3 |
Applications
- Stack liners
- Ducts
- Dampers
- Scrubbers
- Heat exchangers
- Reaction vessels
- Evaporators
Product Details
| Product Type | Hastelloy C276 ASTM B575 Sheet, Hastelloy C276 ASTM B575 Plate |
| Specification | ASTM B575 / ASME SB575 |
| Tolerances | EN 10258/ DIN 59381, EN 10151 2.4819 Hastelloy C-276 Strips, EN 10088 Hastelloy C276 SB575 strips |
| Dimensions | Cold rolled Alloy C276 Plates 0.5-6.4 mm, Hot rolled Alloy C276 Plates 3.0-10.0 mm |
| HS Code | 75062000 |
