S34700 Hot Rolled Polished Surface 347H Stainless Steel Plate with Intergranular Corrosion Resistance
Product Details
| Model NO. | 347 | Shape | Flat |
|---|---|---|---|
| Technique | Hot Rolled | Surface Treatment | Polished |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Production Capacity | 50000kgs |
| Width Range | 600mm~2030 Mm | Thickness Range | 0.1~120.0 Mm |
| Length Range | 300~6000 Mm, Max 18000 Mm | Electrical Resistivity | 70-73 µOhm.cm |
| Elongation At Break | <60% | Brinell Hardness | 160-190 |
| Tensile Strength | 520-1100 MPa | Density | 7.93 G.cm-3 |
| Melting Point | 1400-1425 °C | ||
| Highlight | Hot Rolled Stainless Steel Plate,Polished Surface Metal Plate,Intergranular Corrosion Resistant 347H Stainless Steel Plate |
||
Product Description
S34700 Stainless Steel Metal Plate 347H Stainless Steel Plate
Alloy 347 (S34700) is a stabilized stainless steel plate offering excellent resistance to intergranular corrosion following exposure to temperatures in the chromium carbide precipitation range from 800 to 1500°F (427 to 816°C). This alloy is stabilized by the addition of columbium and tantalum, making it particularly advantageous for high-temperature service due to its superior mechanical properties.
Alloy 347 stainless steel plate provides higher creep and stress rupture properties compared to Alloy 304 and Alloy 304L, making it an ideal choice for applications where sensitization and intergranular corrosion are significant concerns.
Specifications and Standards
AMS 5512, AMS 5646, AMS 5680, ASME SA 240, ASTM A 269, ASTM A 479, ASTM A262 Practice E, MSRR 5632, PWA 300, PWA F17 LCS, UNS S34700, UNS S34709, W. Nr./EN 1.4550
Dimension Ranges
Width: 600mm ~ 2030 mm
Thickness: 0.1 ~ 120.0 mm
Length: 300 ~ 6000 mm, Maximum 18000 mm
Thickness: 0.1 ~ 120.0 mm
Length: 300 ~ 6000 mm, Maximum 18000 mm
Available Surface Finishes
No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating, color-coating, embossing
Industrial Applications
- Chemical Processing Equipment
- Food Processing Equipment and Storage
- Petroleum Refining - fluid catalytic cracking units, polythionic acid service
- Pharmaceutical Production
- Waste Heat Recovery - recuperators
Technical Properties
Electrical Properties
| Property | Value |
|---|---|
| Electrical resistivity (µOhm.cm) | 70-73 |
Mechanical Properties
| Property | Value |
|---|---|
| Elongation at break (%) | <60 |
| Hardness - Brinell | 160-190 |
| Izod impact strength (J.m⁻¹) | 20-136 |
| Modulus of elasticity (GPa) | 190-210 |
| Tensile strength (MPa) | 520-1100 |
Physical Properties
| Property | Value |
|---|---|
| Density (g.cm⁻³) | 7.93 |
| Melting point (°C) | 1400-1425 |
Thermal Properties
| Property | Metric | Imperial |
|---|---|---|
| Coefficient of thermal expansion | 16-18 @ 20-100°C | 11 µm/m°C |
| Maximum use temperature in air | 800°C | |
| Thermal conductivity | 16.4 W/mK | 114 BTU in/hr.ft².°F |
| Thermal expansion co-efficient (@0.000-100°C/32-212°F) | 11 µm/m°C | 6.11 µin/in°F |
