Martensitic S41500 Stainless Steel Plate Corrosion Resistant with Superior Mechanical Properties
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 415 |
|---|---|---|---|
| Thickness | 1.5-50.0mm | Tech | Cold Rolled,hot Rolled , Forged |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B NO.1 |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
Product Description
Martensitic S41500 Stainless Steel Plate Corrosion Resistant with Superior Mechanical Properties
Stainless Steel Plate Specifications
| Name | 415 stainless steel Plate |
| Our Grade |
200 Series: 201 202 300 Series: 301 304,304L,304H,309S,310S,314,316L,316Ti,316H,316LN,317L,321,329,347 400 Series: 409L,410,410S,415,416,420,430,431,436L.439,441,443,444,445,446 Super Stainless Steel: 904L,926,254SMO,654SMO,15-5PH,17-4PH,17-7PH.etc Nickel Alloy: C276, C22,G35,Alloy X,Monel 400,K500,Inconel 600,601,617,625,718,Incoloy 800,800H,800HT,825.etc |
| Technique | Hot Rolled, Cold Rolled,Forged |
| Standard | JIS, AISI, ASTM, DIN, TUV, BV, SUS, etc |
| Thickness | 0.1 – 80.0mm |
| Width range | 10mm – 2000mm |
| Length | Customized |
| Finish | 2B, BA, No.4, 8k, Brushed,Hairline,PVD Coating,Sandblasted |
| Service | Laser Cutting, Bending |
| Sample | Available |
Martensitic S41500 Stainless Steel Plate – Corrosion Resistant with Superior Mechanical Properties
Introduction
S41500 stainless steel is a low-carbon martensitic alloy engineered to deliver an exceptional combination of high strength, good toughness, and moderate corrosion resistance—making it ideal for demanding engineering applications in power generation, oil & gas, marine, and heavy industry. Unlike conventional martensitic grades (e.g., 410 or 420), S41500 features controlled carbon content and strategic additions of nickel and molybdenum, which significantly enhance weldability, ductility, and resistance to stress corrosion cracking.
Supplied as a wrought plate per ASTM A240/A240M Type 415, S41500 offers mechanical properties far exceeding those of standard stainless steels, while maintaining cost-effectiveness compared to duplex or super austenitic alternatives. At [Your Company Name], we provide certified S41500 stainless steel plates in hot-rolled and forged conditions, with custom cutting, machining, and full traceability to support critical infrastructure projects worldwide.
Why Choose Martensitic S41500?
Martensitic stainless steels are known for their hardness and strength—but often at the expense of toughness and weldability. S41500 breaks this trade-off:
- ✅ High Strength: Tensile strength ≥790 MPa after standard heat treatment
- ✅ Excellent Toughness: Charpy impact energy ≥47 J at –20°C
- ✅ Good Weldability: Low carbon (≤0.06%) minimizes cracking risk
- ✅ Moderate Corrosion Resistance: Performs well in freshwater, steam, and mildly acidic environments
- ✅ Precipitation-Hardenable: Achieves peak properties through simple thermal treatment
These attributes make S41500 a top choice for hydroelectric turbine runners, pump shafts, valve components, and other high-stress parts exposed to dynamic loads and moisture.
Chemical Composition (ASTM A240 Type 415 / UNS S41500)
| Element | Content (%) – Typical Range | ASTM A240 Limit |
|---|---|---|
| Carbon (C) | ≤ 0.06 | Max 0.06 |
| Chromium (Cr) | 11.5 – 14.0 | — |
| Nickel (Ni) | 3.5 – 5.5 | — |
| Molybdenum (Mo) | 0.50 – 1.00 | — |
| Manganese (Mn) | 0.50 – 1.00 | Max 1.00 |
| Silicon (Si) | ≤ 0.60 | Max 0.60 |
| Phosphorus (P) | ≤ 0.030 | Max 0.030 |
| Sulfur (S) | ≤ 0.030 | Max 0.030 |
The addition of Ni and Mo refines the microstructure, improves hardenability, and boosts resistance to pitting in chloride-containing environments.
Mechanical Properties (After Heat Treatment – H1025 Condition)
| Property | Minimum Value |
|---|---|
| Tensile Strength | 790 MPa (115 ksi) |
| Yield Strength (0.2% offset) | 620 MPa (90 ksi) |
| Elongation | ≥ 15% |
| Reduction of Area | ≥ 45% |
| Hardness | 28–34 HRC |
| Charpy V-Notch Impact (–20°C) | ≥ 47 J (35 ft·lbf) |
Note: Heat treatment is essential to achieve these properties. Common tempers include:
- H1025: Standard for turbine applications (550°C/1025°F aging)
- H1150D: Dual tempering for maximum toughness in low-temperature or sour service
Corrosion Resistance Performance
While not as corrosion-resistant as 316L or duplex grades, S41500 offers superior performance over basic martensitic steels:
- ✅ Freshwater & Steam: Excellent long-term stability—ideal for hydro turbines
- ✅ Mild Acids & Alkalis: Suitable for chemical processing equipment
- ✅ Atmospheric Exposure: Resists rusting better than carbon steel
- ⚠️ Seawater/High Chlorides: Not recommended without protective coating
Its chromium-rich passive layer, enhanced by molybdenum, provides effective protection against general and localized corrosion in non-aggressive environments.
Product Offerings & Custom Capabilities
| Feature | Specification |
|---|---|
| Standard | ASTM A240/A240M Type 415 |
| UNS Number | S41500 |
| Common Names | Type 415, F6NM (cast equivalent), 1.4313 (EN), X3CrNiMo13-4 |
| Form | Hot-rolled plate, forged plate, precision blanks |
| Thickness Range | 6 mm – 150 mm (standard); up to 500 mm via forging |
| Max Dimensions | 3000 mm (W) × 12,000 mm (L) |
| Surface Finish | As-rolled, pickled, 2B, machined |
| Certification | EN 10204 3.1 MTR, PMI, UT (ASTM A435), impact test reports |
| Value-Added Services | Laser/waterjet cutting, CNC milling, drilling, beveling, surface grinding, stress relieving |
All plates are ultrasonically tested for internal integrity—critical for rotating or pressure-containing components.
Comparison with Other Stainless Grades
| Property / Grade | S41500 (Martensitic) | 316L (Austenitic) | 410 (Martensitic) | 2205 (Duplex) |
|---|---|---|---|---|
| Tensile Strength | 790 MPa | 515 MPa | 520 MPa | 620 MPa |
| Yield Strength | 620 MPa | 205 MPa | 290 MPa | 450 MPa |
| Weldability | Good (low C) | Excellent | Poor | Moderate |
| Corrosion Resistance | Moderate (freshwater) | Excellent | Low | Very Good |
| Cost | Medium | High | Low | High |
| Best For | Turbines, shafts | Chemical tanks | Cutlery, fasteners | Offshore pipes |
S41500 uniquely bridges the gap between strength and fabricability.
Key Applications
- Hydroelectric Power: Runner blades, guide vanes, shafts, crown rings
- Oil & Gas: Valves, pump components, downhole tools (NACE-compliant when H1150D treated)
- Marine Engineering: Propeller shafts, rudders, seawater pumps (in low-chloride zones)
- Industrial Machinery: High-wear plates, gears, and structural supports
- Defense & Aerospace: Landing gear fittings, actuator housings
Technical Support & Compliance
We ensure every S41500 plate meets global standards:
- ASTM A240/A240M (plate specification)
- ASTM A751 (chemical analysis)
- NACE MR0175/ISO 15156 (for sour service, with proper heat treatment)
- EN 10088-3 / 1.4313 (European equivalence)
Our metallurgical team provides:
- Welding procedure recommendations (WPS support)
- Heat treatment guidelines
- Material selection consulting
Frequently Asked Questions (FAQ)
Q: Is S41500 magnetic?
A: Yes—it’s martensitic and therefore ferromagnetic, which can be advantageous for certain sensors or lifting applications.
A: Yes—it’s martensitic and therefore ferromagnetic, which can be advantageous for certain sensors or lifting applications.
Q: Can it be used without heat treatment?
A: Not recommended. As-rolled S41500 lacks required strength and toughness. Heat treatment (e.g., H1025) is mandatory for structural use.
A: Not recommended. As-rolled S41500 lacks required strength and toughness. Heat treatment (e.g., H1025) is mandatory for structural use.
Q: How does it compare to CA6NM?
A: Nearly identical chemistry. CA6NM is the cast version (ASTM A743), while S41500 is wrought plate (ASTM A240). Use S41500 for rolled/forged plate applications.
A: Nearly identical chemistry. CA6NM is the cast version (ASTM A743), while S41500 is wrought plate (ASTM A240). Use S41500 for rolled/forged plate applications.
Q: Do you offer small quantities?
A: Yes—no minimum order. We cut plates to your exact size, even for prototypes.
A: Yes—no minimum order. We cut plates to your exact size, even for prototypes.
Martensitic S41500 stainless steel plate, ASTM A240 Type 415, high strength corrosion resistant steel, S41500 plate supplier, turbine-grade stainless steel, low carbon martensitic steel, forged S41500 plate, custom cut stainless steel plate, hydro turbine material, S41500 vs 316L, precipitation hardening stainless steel, X3CrNiMo13-4 plate, S41500 mechanical properties, corrosion resistant martensitic steel.
