UNS S30403 304L Stainless Steel Plate Non-Magnetic, Formable, and Highly Durable in Mild Environments
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 304L |
|---|---|---|---|
| Thickness | 1.5-50.0mm | Tech | Cold Rolled,hot Rolled , Forged |
| Width | 1000mm 1219mm 1500mm Or Customs As Request | Surface | 2B NO.1 |
| Standard | ASTM GB JIS EN DIN | MOQ | 1 Ton |
Product Description
UNS S30403 304L Stainless Steel Plate Non-Magnetic, Formable, and Highly Durable in Mild Environments
Stainless Steel Plate Specifications
| Name | 304L stainless steel Plate |
| Our Grade |
200 Series: 201 202 300 Series: 301 304,304L,304H,309S,310S,314,316L,316Ti,316H,316LN,317L,321,329,347 400 Series: 409L,410,410S,416,420,430,431,436L.439,441,443,444,445,446 Super Stainless Steel: 904L,926,254SMO,654SMO,15-5PH,17-4PH,17-7PH.etc Nickel Alloy: C276, C22,G35,Alloy X,Monel 400,K500,Inconel 600,601,617,625,718,Incoloy 800,800H,800HT,825.etc |
| Technique | Hot Rolled, Cold Rolled,Forged |
| Standard | JIS, AISI, ASTM, DIN, TUV, BV, SUS, etc |
| Thickness | 0.1 – 80.0mm |
| Width range | 10mm – 2000mm |
| Length | Customized |
| Finish | 2B, BA, No.4, 8k, Brushed,Hairline,PVD Coating,Sandblasted |
| Service | Laser Cutting, Bending |
| Sample | Available |
UNS S30403 304L Stainless Steel Plate – Non-Magnetic, Highly Formable, and Durable in Mild Environments
Product Overview
UNS S30403 (AISI 304L) stainless steel plate is the low-carbon variant of the world’s most widely used austenitic stainless steel, engineered for applications demanding excellent formability, non-magnetic properties, and reliable corrosion resistance in mild to moderately aggressive environments.
With a maximum carbon content of 0.03%, 304L eliminates the risk of chromium carbide precipitation during welding—ensuring intergranular corrosion resistance in as-welded conditions without requiring post-weld heat treatment. This makes it ideal for fabricated structures, cryogenic vessels, architectural panels, food processing equipment, and electronic enclosures where magnetic interference must be avoided.
Manufactured to ASTM A240/A240M, ASME SA-240, and EN 10088-2 (1.4307) standards, our 304L plates offer consistent metallurgical quality, full traceability, and global compliance.
Key Characteristics
| Property | Performance |
|---|---|
| Non-Magnetic | Austenitic structure remains non-magnetic in annealed condition (ideal for MRI rooms, sensors, electronics) |
| Highly Formable | Elongation ≥40%; excellent for bending, deep drawing, spinning, and roll forming |
| Weldability | Superior—no sensitization in HAZ; suitable for thick-section welding |
| Corrosion Resistance | Excellent in atmospheric, freshwater, organic acids, and alkaline environments |
| Durability | Long service life with minimal maintenance in indoor or low-chloride outdoor settings |
| Cryogenic Toughness | Retains ductility down to –196°C (–320°F) |
⚠️ Note: Cold working may induce slight magnetism, but this is typically negligible for most non-critical applications.
Technical Specifications
Chemical Composition (Typical – wt%, per ASTM A240)
| Element | Content (%) |
|---|---|
| Chromium (Cr) | 18.0–20.0 |
| Nickel (Ni) | 8.0–12.0 |
| Carbon (C) | ≤0.030 |
| Manganese (Mn) | ≤2.00 |
| Silicon (Si) | ≤0.75 |
| Phosphorus (P) | ≤0.045 |
| Sulfur (S) | ≤0.030 |
| Iron (Fe) | Balance |
- UNS: S30403
- EN: 1.4307
- AISI: 304L
Mechanical Properties (Annealed Condition)
| Property | Typical Value |
|---|---|
| Tensile Strength | 485–620 MPa |
| Yield Strength (0.2% offset) | ≥170 MPa |
| Elongation | ≥40% |
| Hardness | ≤201 HB |
| Density | 8.0 g/cm³ |
| Thermal Conductivity | ~16.2 W/m·K |
| Magnetic Permeability | <1.005 μr (effectively non-magnetic) |
Why Choose 304L for Non-Magnetic & Formable Applications?
✅ Electronics & Medical: Safe for use near sensitive instruments (e.g., MRI machines, lab equipment)
✅ Architectural Interiors: Brushed or mirror finishes with no magnetic attraction—ideal for modern design
✅ Food & Pharma: Smooth, non-porous surfaces support hygiene and CIP/SIP cleaning
✅ Cryogenic Tanks: No embrittlement at ultra-low temperatures
✅ Custom Fabrication: Easily formed into complex shapes—hoods, trays, ducts, enclosures
Unlike ferritic or martensitic steels, 304L’s stable austenitic structure ensures dimensional stability and aesthetic consistency after forming or welding.
Available Product Details
| Parameter | Specification |
|---|---|
| Grade | UNS S30403 / 304L / 1.4307 |
| Standards | ASTM A240, ASME SA-240, EN 10088-2 |
| Form | Hot-rolled plate (≥4.5 mm), Cold-rolled sheet (<4.5 mm) |
| Thickness Range | 0.5 mm to 100 mm (Common stock: 1.0, 2.0, 3.0, 4.0, 6, 8, 10, 12, 16, 20, 25, 30 mm) |
| Standard Sizes | • 1000 × 2000 mm • 1219 × 2438 mm (4' × 8') • 1500 × 3000 mm • 1500 × 6000 mm |
| Surface Finishes | • 2B (standard matte) • No.1 (hot-rolled, descaled) • BA (bright annealed) • No.4 (brushed) • Mirror, Hairline, Embossed (custom) |
| Certifications | EN 10204 3.1/3.2 MTR, PMI, ISO 9001, RoHS, FDA-compliant grades available |
All plates are stored indoors to prevent surface contamination and maintain finish integrity.
Ideal Applications by Sector
| Industry | Use Cases |
|---|---|
| Medical & Electronics | MRI room shielding, sensor housings, non-magnetic tooling, cleanroom furniture |
| Architecture | Interior wall panels, elevator cabs, decorative trim, handrails (non-marine) |
| Food & Beverage | Mixing tanks, conveyor guards, hopper liners, sanitary enclosures |
| HVAC & Ducting | Exhaust systems in non-corrosive environments, custom-formed duct sections |
| Cryogenics | Liquid nitrogen/oxygen storage vessels, transfer lines |
| General Fabrication | Machine guards, control cabinets, brackets, frames requiring complex bends |
Fabrication Best Practices
- Forming: Excellent cold formability; springback is moderate. Anneal if severe deformation causes work hardening.
- Welding: Use ER308L filler. Maintain interpass temp <150°C. No post-weld annealing needed.
- Machining: Moderate machinability—use rigid setups, sharp tools, and high lubrication.
- Finishing: Electropolishing enhances non-magnetic surface purity and corrosion resistance.
- Handling: Avoid contact with carbon steel tools to prevent iron contamination (can cause rust spotting).
Quality Assurance
Every delivery includes:
- Mill Test Report (MTR) with chemical & mechanical data
- Positive Material Identification (PMI) via XRF/OES
- Optional surface roughness (Ra) certification for hygienic applications
- Full compliance with ASTM, ASME, EN, FDA (where applicable)
Material sourced from ISO-certified mills with strict melt chemistry control.
Sustainability & Lifecycle Benefits
- 100% recyclable with high scrap value
- Low environmental impact due to long service life and minimal maintenance
- Energy-efficient over decades of use
- Supports green building and circular economy initiatives
Order Information
- MOQ: 1 piece (cut-to-size); 500 kg (mill order)
- Lead Time:
- Stock: 3–7 working days
- Mill production: 3–5 weeks
- Value-Added Services:
✅ Precision laser/waterjet cutting
✅ Edge deburring & radius forming
✅ Surface polishing (Ra 0.4–3.2 µm available)
✅ VCI packaging for export - Global Shipping: FOB, CIF, or DDP terms
Contact us for a free sample, material data sheet, or application-specific consultation.
Conclusion
When your project demands a non-magnetic, highly formable, and durable stainless steel that performs reliably in mild environments, UNS S30403 304L plate delivers the perfect balance of functionality, safety, and cost-efficiency. Trusted across industries from healthcare to architecture, it remains the benchmark low-carbon austenitic stainless steel for smart, sustainable engineering.
