Hot Rolled and Forged Hastelloy C-22 Round Bar Black and Bright Polished Bar in Custom Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C-22 |
| Minimum Order Quantity | 10 kg |
| Price | 40 - 50 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Hastelloy C-22 Round Bar | Grade | Hastelloy C22 |
|---|---|---|---|
| Diameter | 10 - 350mm | Length | Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Bright,black |
Product Description
Hot Rolled and Forged Hastelloy C-22 Round Bar Black and Bright Polished Bar in Custom Length
More Specification Informations
| Products Name | Hastelloy C22 round bar |
| Diameter | 10 - 350mm |
| Length | custom cutting any length as request |
| Surface | bright, Black,pickling,polishing |
| Brand | DELTA |
| Service | cutting, Polishing |
| MOQ | 2 Kgs |
| Other Type | bar, strip,coil,pipe.sheet, plate,wire.etc |
| Packing | Wooden box |
| Loading Port | Shanghai Port |
| Price term | EXW,FOB,CIF,CFR |
| Deliver time | within 12 days |
Hot Rolled and Forged Hastelloy C-22 Round Bar: Black and Bright Polished Bar in Custom Length
Premium Corrosion Resistance for Demanding Applications
Our Hastelloy C-22 round bars represent the pinnacle of nickel-chromium-molybdenum-tungsten alloys, engineered to deliver exceptional performance in the most aggressive corrosive environments. Available in both hot rolled and forged conditions, and in your choice of black (as-supplied) or bright polished surface finishes, we provide the material solution tailored to your specific technical and aesthetic requirements.
Product Forms & Availability
-
Hot Rolled Round Bars: Cost-effective solution with good mechanical properties, suitable for a wide range of general corrosion applications.
-
Forged Round Bars: Superior mechanical strength, grain structure, and directional properties achieved through the forging process. Ideal for high-integrity components like valve stems, fasteners, and pump shafts subject to high stress.
-
Custom Lengths: We specialize in supplying round bars cut to your exact specifications, minimizing waste and reducing your machining time and cost.
Surface Finishes
-
Black Bar: Supplied in a descaled, as-rolled or as-forged condition. This economical finish is perfect for parts that will undergo subsequent machining or where surface appearance is not critical.
-
Bright Polished Bar: Cold drawn and polished to a smooth, shiny finish. This offers excellent dimensional accuracy, a superior surface appearance, and is often used for applications where a clean, finished surface is required with minimal post-processing.
Key Features & Material Advantages of Hastelloy C-22
-
Exceptional, All-Around Corrosion Resistance: Hastelloy C-22 offers outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking.
-
Versatile Oxidizing and Reducing Media Capability: It performs excellently in both oxidizing and reducing environments, including those containing chlorides.
-
Superior Resistance to Wet Chlorine and Mixed Acids: An ideal choice for handling sulfuric acid, nitric acid, acetic acid, and other aggressive chemical media.
-
Excellent Weldability: Hastelloy C-22 is readily welded using common techniques and shows low susceptibility to weld zone degradation.
-
High Thermal Stability: Maintains its properties over a wide temperature range.
Typical Chemical Composition (Weight %)
| Element | Ni (Nickel) | Cr (Chromium) | Mo (Molybdenum) | W (Tungsten) | Fe (Iron) | Co (Cobalt) | C (Carbon) | Mn (Manganese) | Si (Silicon) | P (Phosphorus) | S (Sulfur) | V (Vanadium) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hastelloy C-22 | Bal. | 20 - 22.5 | 12.5 - 14.5 | 2.5 - 3.5 | 2.0 - 6.0 | 2.5 max | 0.015 max | 0.50 max | 0.08 max | 0.02 max | 0.02 max | 0.35 max |
Mechanical Properties (Typical at Room Temperature)
| Condition | Tensile Strength | Yield Strength (0.2% Offset) | Elongation (%) |
|---|---|---|---|
| Annealed | 110 ksi (758 MPa) min | 51 ksi (352 MPa) min | 45% min |
Industries & Applications
Our Hastelloy C-22 round bars are specified across a wide range of critical industries:
-
Chemical Processing: Reactors, vessels, heat exchangers, agitators, and piping systems.
-
Pollution Control: Flue Gas Desulfurization (FGD) systems, scrubbers, and ducting.
-
Pharmaceutical & Fine Chemical: Equipment requiring high purity and resistance to corrosive cleaning agents.
-
Pulp & Paper Industry: Digesters and bleach plants.
-
Waste Treatment: Incinerators and waste handling systems.
-
Marine & Offshore: Components exposed to seawater and saline atmospheres.
Contact us today to discuss your project requirements and receive a competitive quote for your custom-length Hastelloy C-22 round bars. Our technical experts are ready to assist you in selecting the optimal form and finish for your application.
