UNS N08926 926 Stainless Steel Strip for High-Temperature Applications
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 926 |
| Minimum Order Quantity | 2 Ton |
| Price | 12-15 USD/kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.5-8.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 500 Kgs |
| Grade | 200 Series 300 Series 300 Series | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
| Highlight | High-Temperature Stainless Steel Strip,UNS N08926 Stainless Steel Strip |
||
Product Description
UNS N08926 926 Stainless Steel Strip for High-Temperature Applications
Product Specifications
| Attribute | Value |
|---|---|
| Products | stainless steel strip |
| Thickness | 0.5-8.0mm |
| Width | within 1500mm |
| MOQ | 500 kgs |
| Grade | 200 series 300 series 300 series |
| Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS |
| Packing | wooden frame and water proof paper |
Detailed Product Information
UNS N08926 926 Stainless Steel Strip High-Temperature Resistant and Durable
| Specification | Details |
|---|---|
| Product Name | Stainless Steel Strips |
| Length | As required |
| Width | 3mm-1219mm or as required |
| Thickness | 0.15 - 3.0mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled / cold rolled |
| Surface Treatment | 2B or according to customer requirement |
| Thickness tolerance | ±0.01mm |
| Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431,434, 440A,904L,2205,2507,926 |
| Application | Widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components. Also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
| MOQ | 1tons. We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit for all kinds of transport, or as required |
| Capacity | 250,000 tons/year |
Introduction to 926 Stainless Steel Strip
926 stainless steel strip, known as a super austenitic stainless steel strip, is highly regarded in various industries for its exceptional properties. N08926 is its UNS (Unified Numbering System) standard grade, while alloy 926 stainless steel strip is the common industry name following the AISI (American Iron and Steel Institute) standard.
Chemical Composition and Microstructure
The chemical composition of 926 stainless steel strip is carefully balanced to endow it with outstanding performance:
| Element | Content Range | Function |
|---|---|---|
| Chromium (Cr) | 19.0 - 21.0% | Forms a passive oxide layer, crucial for corrosion resistance, especially in oxidizing environments. |
| Nickel (Ni) | 24.0 - 26.0% | Stabilizes the austenitic microstructure, enhancing toughness and ductility. |
| Molybdenum (Mo) | 6.0 - 7.0% | Significantly improves resistance to pitting and crevice corrosion. |
| Nitrogen (N) | 0.15 - 0.25% | Strengthens the alloy through solid-solution hardening. |
| Iron (Fe) | Balance | The base metal that provides the structural framework. |
Mechanical and Physical Properties
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥650 MPa |
| Yield Strength | ≥300 MPa |
| Elongation | ≥35% |
Physical Properties
- Density: Approximately 8.1 g/cm³
- Melting Point: Ranges from 1320 - 1390 °C
Standards
| Standard System | Standard Number |
|---|---|
| ASTM | ASTM A240, ASTM B625 |
| EN | EN 10088-1:2005 (X1NiCrMoCuN25-20-7, 1.4529) |
Superior Corrosion Resistance
- Resistance to Pitting and Crevice Corrosion: Very high resistance in media and acidic environments containing sulfur and hydrogen.
- Chloride Ion Stress Corrosion Cracking Resistance: Effective resistance makes it suitable for marine and chemical processing applications.
- General Corrosion Resistance: Good resistance in both oxidizing and reducing media.
Advantages
- High-Temperature Performance: Usable from -196°C to 400°C.
- Good Workability: Can be cold-worked and hot-worked using standard techniques.
- Weldability: Satisfactory with proper procedures and filler materials.
Applications
- Marine Industry: Seawater cooling systems, marine vessels, offshore platforms.
- Chemical Processing: Pipelines, reactors, storage tanks for corrosive chemicals.
- Oil and Gas Industry: Downhole equipment and pipelines in corrosive environments.
- Pollution Control: Scrubbers and exhaust systems in power plants.
