Smooth Edge 316L/316H/316Ti Stainless Steel Strips and Coils Width 5 - 1500mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 300 Series / 400 Series |
| Minimum Order Quantity | 2 Ton |
| Price | 1500-2500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Strip | Thickness | 0.5-8.0mm |
|---|---|---|---|
| Width | Within 1500mm | MOQ | 500 Kgs |
| Grade | 200 Series 300 Series 300 Series | Surface | BA 2B NO.4 HL 8K NO.1 |
| Standard | ASTM EN GB JIS | Packing | Wooden Frame And Water Proof Paper |
Product Description
Smooth Edge 316L/316H/316Ti Stainless Steel Strips and Coils Width 5 - 1500mm
Products Specification
| Product Name | Stainless Steel Strips |
| Length | As required |
| Width | 3mm-1219mm or as required |
| Thickness | 0.15 - 3.0mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled / cold rolled |
| Surface Treatment | 2B or according to customer requirement |
| Thickness tolerance | ±0.01mm |
| Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431,434, 440A,904L,2205,2507 |
| Application | It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
| MOQ | 1tons.We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
| Capacity | 250,000 tons/year |
The 316-series austenitic stainless steels are renowned for their corrosion resistance, especially in aggressive environments. While sharing a base composition (chromium, nickel, molybdenum), variants like 316L, 316H, and 316Ti differ in carbon content and alloying elements, leading to distinct mechanical properties, corrosion behaviors, and applications. Below is a detailed technical comparison.
1. 316L Stainless Steel Strip
Key Features:
-
Low Carbon Content (≤0.03%): Minimizes carbide precipitation during welding, enhancing corrosion resistance in welded structures17.
-
Enhanced Corrosion Resistance: Superior to 304/316 in chloride-rich environments (e.g., marine, chemical processing) and resistant to sulfuric, acetic, and phosphoric acids1410.
-
Temperature Limits: Continuous use up to 870°C (intermittent to 925°C). Avoid prolonged exposure at 450–850°C to prevent carbide sensitization17.
Standards & Dimensions:
-
Standards: ASTM A240 (U.S.), EN 1.4404 (EU), JIS G4303 (Japan)16.
-
Dimensions:
-
Thickness: 0.025–5.0 mm (precision strips down to ±0.01 mm tolerance)148.
-
Width: 3–1,219 mm (custom slitting available)410.
-
-
Surface Finishes: 2B (matt), BA (bright annealed), 6K–9K mirror, brushed, satin168.
-
Hardness: Ranges from soft (HV 160) to extra-hard (HV 600), achievable via cold rolling45.
Applications:
-
Marine hardware, medical implants, pharmaceutical equipment, and food processing conveyors due to non-reactivity and hygiene410.
-
Architectural components in coastal areas (resists salt-induced pitting)17.
2. 316H Stainless Steel Strip
Key Features:
-
High Carbon Content (0.04–0.10%): Boosts high-temperature strength via carbide strengthening39.
-
Elevated Temperature Performance: Suitable for continuous service up to 815°C (e.g., furnace parts)29.
-
Corrosion Resistance: Similar to 316L but prone to sensitization in welds; post-weld annealing is critical3.
Standards & Dimensions:
-
Standards: ASTM A240 (316H), ASME SA24069.
-
Dimensions: Aligns with 316L (thickness: 0.1–6.0 mm; width: up to 1,500 mm)310.
-
Hardness: Typically supplied in annealed condition (HV 150–200); high-temp stability prioritizes over hardness3.
Applications:
-
High-temperature systems: Heat exchangers, boiler components, and exhaust manifolds9.
-
Chemical processing equipment where creep resistance is essential3.
3. 316Ti Stainless Steel Strip
Key Features:
-
Titanium Stabilization (Ti ≥5×C content): Forms Ti carbides, suppressing chromium carbide precipitation and preventing intergranular corrosion in welds369.
-
Acid Resistance: Excels against sulfuric, phosphoric, and acetic acids39.
-
Mechanical Properties: Higher yield strength (≥205 MPa) vs. 316L, with elongation ≥40%3.
Standards & Dimensions:
-
Standards: UNS S31635, EN 1.4571, JIS SUS316Ti36.
-
Dimensions: Thickness: 0.03–6.0 mm; Width: 5–1,219 mm (hot-rolled up to 2,000 mm)39.
-
Surface/Finish: Mirror (8K), brushed, No.1 industrial finish69.
Applications:
-
Chemical tank linings, heat exchangers, and sulfuric acid reactors39.
-
Aerospace components requiring combined corrosion resistance and strength6.
Comparative Summary
| Property | 316L | 316H | 316Ti |
|---|---|---|---|
| Carbon Content | ≤0.03% | 0.04–0.10% | ≤0.08% + Ti stabilization |
| Key Alloy | Mo (~2.1%) | Mo + high C | Mo + Ti (~0.4–0.7%) |
| Corrosion Resistance | Excellent (low-C welds) | Good (sensitization risk) | Superior (acid/weld zones) |
| Max Service Temp | 870°C (continuous) | 815°C (continuous) | 925°C (intermittent) |
| Primary Applications | Marine, medical, food | High-temp industrial | Chemical processing, aerospace |
| Standards | ASTM A240/EN 1.4404 | ASTM A240/ASME SA240 | EN 1.4571/UNS S31635 |
