NO.1 2B Surface 316H Austenitic Stainless Steel Plate 1.4436 SS Plate Hot And Cold Rolled With Thickness 0.6 30.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 316H / S31609 |
| Minimum Order Quantity | 500 kgs |
| Price | 5000 - 7200 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 316H / S31609 |
|---|---|---|---|
| Thickness | 0.6 - 30.0mm | Width | 1219mm 1500mm 1800mm 2000mm |
| Surface | NO.1 2B | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | 1.4436 316H Stainless Steel Plate,Austenitic 316H Stainless Steel Plate,316H Stainless Steel Plate 1.4436 |
||
Product Description
316H Austenitic Stainless Steel Plate Hot Rolled and Cold Rolle 1.4436 SS Plate
Products Specification
| Products Name | 317L Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 317L, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,654SMO,253MA,2205,2507.etc |
| Thickness | 0.6 - 30.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
Introduction of 316H Stainless Steel
316H stainless steel is a type of austenitic stainless steel with the UNS number S31609. It is standardized under AISI and ASTM specifications and is known for its enhanced properties compared to standard 316H Stainless Steel .
Chemical Composition
The chemical composition of 316H Stainless Steel includes:
●
Carbon (C): 0.04~0.10
●
Manganese (Mn): ≤2.00
●
Silicon (Si): ≤0.75
●
Chromium (Cr): 16.0~18.0
●
Nickel (Ni): 10.0~14.0
●
Phosphorus (P): ≤0.045
●
Sulfur (S): ≤0.03
●
Molybdenum (Mo): 2.0~3.0
Key Properties
1.
High Temperature Strength: The higher carbon content in 316H provides improved strength at elevated temperatures, making it suitable for applications requiring high-temperature performance.
2.
Corrosion Resistance: Like other 316 grades, 316H offers excellent resistance to corrosion, particularly in environments with chlorides, making it suitable for marine and chemical processing applications.
3.
Weldability: It possesses good welding properties and can be welded using various standard welding methods. However, due to its higher carbon content, it may require post-weld heat treatment to avoid sensitization and intergranular corrosion.
4.
Austenitic Structure: The austenitic structure of 316H Stainless Steel grants it excellent toughness, even at low temperatures.
Applications
316H Stainless Steel is widely used in industries such as:
●
Petrochemical and natural gas
●
Chemical processing
●
Power generation
●
Paper and pulp production
●
Marine environments
Comparison with 316 and 316L
316H has a higher carbon content compared to 316 and 316L, which enhances its high-temperature strength. However, this also means it is more susceptible to sensitization during welding. 316L, with its lower carbon content, offers better resistance to intergranular corrosion but may not perform as well in high-temperature applications.
Heat Treatment
●
Melting Point: 1375~1450°C
●
Solution Annealing: 1010~1150°C
Standards and Grades
316H Stainless Steel is recognized under various international standards, including:
●
ASTM A959, A240/A240M
●
SAE J405
●
DIN 1.4436 (German standard)
●
EN X3CrNiMO17-13-3 (European standard)
