654SMO Stainless Steel Plate (UNS S32654, 1.4652) SS PlateThickness 1.0 - 80.0mm
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 654SMO |
| Minimum Order Quantity | 500 kgs |
| Price | 5000 - 7200 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 654SMO |
|---|---|---|---|
| Thickness | 1.0 - 80.0mm | Width | 1500mm 1800mm 2000mm |
| Surface | NO.1 | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
Product Description
654SMO Stainless Steel Plate (UNS S32654, 1.4652) SS PlateThickness 1.0 - 80.0mm
Products Specification
| Products Name | 654SMO Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,654SMO,253MA,2205,2507.etc |
| Thickness | 1.0 - 80.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
Comprehensive Overview of S32654 Stainless Steel Plate
1. Product Description
S32654 (commonly known as 654SMO) is a super-austenitic stainless steel characterized by ultra-high corrosion resistance, surpassing conventional austenitic grades (e.g., 316L) and even duplex steels. Its composition includes elevated chromium (23–25%), nickel (21–23%), molybdenum (7–8%), and nitrogen (0.45–0.55%), enabling performance comparable to nickel-based alloys like Inconel or Hastelloy in aggressive environments. Key advantages include:
-
Exceptional pitting/crevice corrosion resistance in chloride-rich media (e.g., seawater, acids)16.
-
High strength (yield strength ≥430 MPa) due to nitrogen enhancement, outperforming 254SMO and 904L38.
-
Excellent weldability and toughness across cryogenic to elevated temperatures69.
2. Key Parameters
Chemical Composition (%)135:
| Element | C | Si | Mn | Cr | Ni | Mo | N | Cu |
|---|---|---|---|---|---|---|---|---|
| Range | ≤0.02 | ≤0.05 | 2.0–4.0 | 23–25 | 21–23 | 7.0–8.0 | 0.45–0.55 | 0.3–0.6 |
Physical & Mechanical Properties1710:
-
Density: 8.24 g/cm³
-
Melting Point: 1320–1390°C
-
Tensile Strength: ≥750 MPa
-
Yield Strength: ≥430 MPa
-
Elongation: ≥40%
-
Hardness: ≤250 HB
-
Magnetism: Non-magnetic
3. Standards & Specifications
S32654 plates comply with international standards for quality assurance:
-
Plate Standards: ASTM A240, ASTM A480, ASME SA-240210.
-
Other Product Forms:
-
Tubes: ASTM A312, A358
-
Bars: ASTM A276, A47925.
-
-
Dimensional Tolerance: Adheres to ASTM/EN thickness and flatness norms.
4. Packaging
Plates are protected to prevent damage during transit:
-
Standard Packaging: Wooden crates or pallets with rust-proof paper wrapping and waterproof plastic covering. Edges are guarded with protective strips48.
-
Customization: Cut-to-size plates, surface polishing (e.g., No. 4 finish), or specific coating upon request310.
5. Equivalent Grades
Global designations for S32654 include259:
-
UNS: S32654
-
EN: X1CrNiMoCuN24-22-8 (1.4652)
-
China: 015Cr24Ni22Mo8Mn3CuN (GB/T)
-
Japan: JIS-designated equivalents under development.
6. Applications
S32654 plates are critical in extreme corrosion environments:
-
Offshore/Marine: Seawater piping, heat exchangers, submarine components16.
-
Energy: Flue gas desulfurization (FGD) systems, desalination plants, nuclear wastewater handling310.
-
Chemical Processing: Reactors, scrubbers, and pipelines for acids/chlorides69.
-
Industrial: Bleaching equipment (pulp/paper), high-pressure RO systems, salt/酱油 brewing tanks48.
Why Choose S32654 Plates?
This alloy bridges the gap between standard stainless steels and costlier nickel alloys, offering >55 PRE (Pitting Resistance Equivalent) for longevity in critical infrastructure69. Its versatility in fabrication (welding, forming) and compliance with global standards make it ideal for engineers prioritizing safety and lifecycle cost.
