ASTM A387 Gr2 CL2 Alloy Steel Plates Superior Performance in High Stress Environments
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO 9001 |
| Model Number | SA387 GR12 CL2 |
| Minimum Order Quantity | 10 kgs |
| Price | 540 - 890 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | SA387 GR12 CL2 | Thickness | 3.0 - 200.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Material | Carbon Steel, Alloy Steel, Stainless Steel |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
Product Description
ASTM A387 Gr2 CL2 Alloy Steel Plates Superior Performance in High Stress Environments
Products Specification
| Product Name | SA387 GR12 CL2 Steel Plate |
| Thickness | 3mm~300mm,2mm-100mm is common thickness,also can customize |
| Width | 1000~3000mm,common width is 1250mm,1500mm,2000mm,2200mm |
| Length | 1000~12000mm,can as your request cut |
| Surface | Clean,finished, blasting and painting or as your request |
| Delivery | Hot Rolled, Controlled Rolling,Normalizing,Annealing, Tempering,Quanching, Q+T |
| Packing | Steel Strapping,fixing in the Container,can customize |
| Thickness tolerance | ±0.3mm |
| Application | It is mainly used to make structural parts such as car girder, beam, transmission shaft and car chassis parts, which can reduce the weight of the parts. |
SA387 Gr12 Cl2 Chromium-Molybdenum Alloy Steel Plate
Key Specifications
| Property | Detail |
|---|---|
| Standard | ASTM SA387 / ASME SA387 |
| Grade & Class | Grade 12, Class 2 (Normalized and Tempered Condition) |
| Composition | Low-Alloy Steel: C≤0.15%, Cr 0.80-1.25%, Mo 0.45-0.65% |
| Equivalent Material | EN 1.7335 / 15CrMoR (China) / JIS SUS410J3T (Japan) |
| Thickness Range | 5 mm – 250 mm (Customizable) |
| Dimensions | Width: 1500–4500 mm | Length: 6000–18000 mm (Other Sizes on Request) |
Key Features & Benefits
- High-Temperature Strength
Resistant to creep and oxidation at service temperatures up to 538°C (1000°F), ideal for elevated-pressure environments.
- Hydrogen Service Compatibility
Proven resistance to hydrogen embrittlement and H₂S corrosion, compliant with NACE MR0175 for sour service applications.
- Pressure Vessel Performance
Optimized for fabrication of reactors, heat exchangers, and boilers under ASME Section VIII, Div. 1 regulations.
- Controlled Heat Treatment
Supplied in Normalized + Tempered (N+T) condition per Class 2 requirements, ensuring uniform microstructure and impact toughness.
- Weldability & Formability
Pre-certified for welding (P-No. 4 Group 1 per ASME IX) with low crack susceptibility.
Typical Applications
-
Petrochemical: Hydrogen reactors, hydrocrackers, catalytic converters.
-
Power Generation: Boiler drums, steam headers, superheater tubes.
-
Oil & Gas: Pressure vessels in refineries, LNG heat exchangers.
-
General Process Equipment: High-temperature storage tanks and piping.
Certifications & Testing
-
Mandatory Tests:
-
Tensile & Yield Strength (Room & Elevated Temp)
-
Charpy V-Notch Impact Test (-30°C / -22°F min)
-
Hardness Survey (HBW 163–220)
-
-
Optional Tests:
-
Ultrasonic Testing (ASTM A578 Level III)
-
HIC/SSC Resistance (NACE TM0284/TM0177)
-
PMI (Positive Material Identification)
-
-
Certificates:
-
Mill Test Report (MTR) per EN 10204 3.1
-
ASME Material Traceability
-
PED 2014/68/EU Annex I (Optional)
-
Packaging & Delivery
-
Surface Protection: Anti-rust oiled or VCI paper wrapping.
-
Packaging: Steel-strapped bundles with edge guards.
-
Marking: Heat no., grade, size, standard etched per ASTM A6.
-
Lead Time: 4–8 weeks (stock-dependent).
Why Choose Our SA387 Gr12 Cl2 Plates?
-
Global Compliance: Fully traceable to ASME, ASTM, and PED standards.
-
Technical Support: Dedicated metallurgical advisory for fabrication (PWHT, welding procedures).
-
Custom Solutions: Cut-to-size, pre-machining, and non-destructive testing (NDT) services.
