1000mm 1219mm 1500mm Width DIN 2.4819 Nickel Alloy Plate Hastelloy C-276 1.0 30.0mm Thickness For Industrial

  • 1000mm 1219mm 1500mm Width DIN 2.4819 Nickel Alloy Plate Hastelloy C-276 1.0 30.0mm Thickness For Industrial
  • 1000mm 1219mm 1500mm Width DIN 2.4819 Nickel Alloy Plate Hastelloy C-276 1.0 30.0mm Thickness For Industrial
  • 1000mm 1219mm 1500mm Width DIN 2.4819 Nickel Alloy Plate Hastelloy C-276 1.0 30.0mm Thickness For Industrial
  • 1000mm 1219mm 1500mm Width DIN 2.4819 Nickel Alloy Plate Hastelloy C-276 1.0 30.0mm Thickness For Industrial
  • 1000mm 1219mm 1500mm Width DIN 2.4819 Nickel Alloy Plate Hastelloy C-276 1.0 30.0mm Thickness For Industrial
Place of Origin China
Brand Name DELTA
Certification ISO
Model Number 2.4819
Minimum Order Quantity 500 kgs
Price 40-45 USD/Kg
Packaging Details standard packing for export
Delivery Time 5 - 12 days based on the quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 3 Ton per week
Product Details
Products Nickel Alloy Plate Grade 2.4819
Thickness 1.0 - 30.0mm Width 1000mm 1219mm 1500mm
Standard ASTM EN Service Cutting
Loading Port Shanghai Port Surface 2B NO.1
Highlight

Hastelloy C-276 Nickel Alloy Plate

,

1000mm Nickel Alloy Plate

,

DIN 2.4819 Nickel Alloy Plate
Leave a Message
Product Description

DIN 2.4819 Nickel Alloy Plate (Hastelloy C-276)



Quick Informations



Grade Hastelloy C276 / 2.4819 Type Sheet, Plate
Thickness 1.0-25.0mm Width 1219mm,1500mm
Length Within 6m Service Laser Cutting



More Specification Informations



Products Name  DIN 2.4819 Nickel Alloy Sheet , Plate
Thickness cold rolled 1.0 - 3.0mm, hot rolled 4.0 - 25.0mm
Standard Size 1000*2000mm,1219*2438mm,1500*6000mm
Surface 2B, NO.1
Brand DELTA
Service Laser cutting
MOQ 2 Kgs
Other Type round bar, strip,coil,pipe.etc
Packing waterproof paper and wooden pallets, wooden box
Loading Port Shanghai Port
Price term EXW,FOB,CIF,CFR
Deliver time within 12 days



DIN 2.4819 is a nickel-chromium-molybdenum alloy plate, which is widely used in high-temperature and corrosive environments. Here is a detailed description of this alloy plate:

Chemical Composition

The main chemical components of DIN 2.4819 (commonly known as Inconel 625) typically include:

  • Nickel (Ni): ≥58%
  • Chromium (Cr): 20.0–23.0%
  • Molybdenum (Mo): 8.0–10.0%
  • Columbium (Cb)/Niobium (Nb): 3.15–4.15%
  • Iron (Fe): ≤5.0%
  • Manganese (Mn): ≤1.0%
  • Silicon (Si): ≤0.5%
  • Carbon (C): ≤0.10%
  • Phosphorus (P): ≤0.015%
  • Sulfur (S): ≤0.015%

This composition endows it with excellent corrosion resistance and high-temperature strength.

Mechanical Properties

  • Tensile Strength: ≥760 MPa (annealed condition)
  • Yield Strength (0.2% Offset): ≥345 MPa
  • Elongation at Break: ≥30%
  • Hardness (HB): ≤220

These properties remain stable even at temperatures up to 700°C, making it suitable for extreme working conditions.

Corrosion Resistance

  • Resistance to Oxidizing Media: Effective against acids (e.g., nitric acid) and chloride solutions.
  • Resistance to Reducing Media: Performs well in environments containing sulfur compounds.
  • Creep and Fatigue Resistance: Maintains structural integrity under long-term high-temperature and stress loads.

High-Temperature Performance

  • It can withstand continuous service temperatures up to 1093°C, with minimal loss of strength.
  • Suitable for applications such as furnace components, gas turbine parts, and chemical processing equipment.

Fabrication and Processing

  • Welding: Can be welded by various methods (e.g., TIG, MIG, and resistance welding) without significant loss of corrosion resistance.
  • Machining: Requires proper tooling and cooling due to its high work-hardening rate.
  • Forming: Can be cold-formed in annealed condition, though heavy forming may require intermediate annealing.

Standards and Equivalents

  • DIN Standard: DIN 2.4819
  • Equivalent Standards:
    • ASTM: N06625
    • ISO: W.Nr. 2.4856
    • UNS: N06625

Typical Applications

  • Aerospace: Engine components and exhaust systems.
  • Marine Engineering: Corrosion-resistant parts in seawater environments.
  • Chemical Industry: Reactors, heat exchangers, and pipes for handling corrosive media.
  • Oil and Gas: Offshore platforms and high-pressure pipelines.

Surface and Heat Treatment

  • Usually supplied in annealed condition with a mill-finished surface.
  • Solution annealing (at 1093–1204°C followed by rapid cooling) can optimize its ductility and corrosion resistance.

DIN 2.4819 nickel alloy plate is valued for its balanced performance in harsh environments, combining high-temperature stability with excellent corrosion resistance, making it a preferred material for critical industrial applications.
