316Ti Stainless Steel Plate ASME SA240 Hot Rolled SS Plate S31635 Heat Resistant Steel
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 316Ti |
| Minimum Order Quantity | 500 kgs |
| Price | 1700- 2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 316Ti |
|---|---|---|---|
| Thickness | 3.0 - 80.0mm | Width | 1500mm 1800mm 2000mm |
| Surface | NO.1 | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | S31635 Stainless Steel Plate,316Ti Hot Rolled Stainless Steel Plate,ASME SA240 Stainless Steel Plate |
||
Product Description
316Ti Stainless Steel Plate ASME SA240 Hot Rolled SS Plate S31635 Heat Resistant Steel
Products Specification
| Products Name | 316Ti Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc |
| Thickness | 3.0 - 80.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
Hot - Rolled 316Ti Stainless Steel Sheet Product Information
The hot - rolled 316Ti stainless steel sheet is a high - performance material that combines the excellent properties of 316Ti stainless steel with the unique advantages brought by the hot - rolling process. Through high - temperature processing, it features enhanced mechanical properties, improved microstructure, and better formability in large - scale applications. This makes it a preferred choice for a wide range of industrial and construction projects that demand strength, durability, and corrosion resistance.
1. Key Parameters
1.1 Chemical Composition
1.2 Mechanical Properties
- Tensile Strength: ≥515 MPa
- Yield Strength (0.2% offset): ≥205 MPa
- Elongation at Break: ≥40%
- Hardness (HB): ≤187
- Density: 7.98 g/cm³
The hot - rolling process further refines the grain structure, enhancing the overall mechanical performance and ensuring consistent quality across the sheet.
2. Similar Grades
- ASTM/ASME: S31635
- EN/DIN: 1.4571
- JIS: SUS316Ti
These similar grades share comparable chemical compositions and performance characteristics, but slight differences in manufacturing standards and specific application focuses may exist.
3. Standards
Our hot - rolled 316Ti stainless steel sheets comply with multiple international and national standards:
- ASTM A240/A240M: Specifies requirements for chromium and chromium - nickel stainless - steel plate, sheet, and strip for pressure vessels and for general applications.
- EN 10028 - 7: Deals with flat products made of stainless steels for pressure purposes.
- GB/T 4237: Chinese standard for hot - rolled stainless steel plates, sheets, and strips.
- JIS G4305: Japanese standard for hot - rolled stainless steel plates, sheets, and strips.
Compliance with these standards ensures the product's reliability, quality, and suitability for various applications worldwide.
4. In - Stock Specifications
- Thickness: 3 - 50 mm
- Width: 1000 - 2000 mm
- Length: 2000 - 12000 mm
We maintain a large inventory of hot - rolled 316Ti stainless steel sheets in standard sizes, ready for immediate delivery. Custom sizes can also be produced according to customer requirements, with short lead times.
5. Packaging Methods
- Inner Packaging: Each sheet is protected with a layer of anti - rust paper or plastic film to prevent scratches and rust during transportation and storage.
- Outer Packaging: The sheets are bundled together with steel straps and placed on wooden pallets or in steel racks to ensure stability. For large orders, they can be packed in containers to minimize the risk of damage during long - distance transportation.
6. Applications
- Chemical Industry: Ideal for manufacturing chemical reactors, pipelines, storage tanks, and heat exchangers due to its excellent resistance to a wide range of chemicals.
- Petroleum and Gas Industry: Used in oil refineries, offshore platforms, and pipelines, where it can withstand harsh environments and corrosive media.
- Power Generation: Applied in power plants for components such as boiler parts, condensers, and exhaust systems, thanks to its high - temperature resistance and durability.
- Construction and Architecture: Suitable for large - scale building structures, bridges, and architectural facades, providing both strength and aesthetic appeal. The hot - rolled surface texture can also add a unique visual effect to architectural designs.
- Mechanical Manufacturing: Used to produce various mechanical parts, such as gears, shafts, and frames, that require high strength, corrosion resistance, and good formability.
