304H SS Plate High Strength Heat Resistant Stainless Steel Thickness 1/8" To 2" Annealed Finish
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 304H / S30409 |
| Minimum Order Quantity | 500 kgs |
| Price | 1700- 2000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 304H / S30409 |
|---|---|---|---|
| Thickness | 3.0 - 80.0mm | Width | 1500mm 1800mm 2000mm |
| Surface | NO.1 | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | 304H SS Plate,Annealed Finish SS Plate,1/8” to 2” SS Plate |
||
Product Description
304H SS Plate High Strength Heat-Resistant Stainless Steel Thickness 1/8" to 2" Annealed Finish
Products Specification
| Products Name | 304H Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc |
| Thickness | 3.0 - 80.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
Product Information: 304H Stainless Steel Plate
1. Material Grade:
304H Stainless Steel (UNS S30409, ASTM A240/A240M, ASME SA-240)
2. Overview:
304H is a high-carbon variation of the classic 304 austenitic stainless steel, specifically designed for enhanced strength and creep resistance at elevated temperatures (typically above 500°C / 932°F). The "H" denotes higher carbon content (0.04–0.10%), which stabilizes the structure against sensitization and ensures superior performance in high-heat applications like pressure vessels, boilers, and heat exchangers. It retains excellent corrosion resistance, formability, and weldability.
3. Key Features & Benefits:
-
High-Temperature Strength: Optimized for sustained service up to 815°C (1500°F).
-
Creep Resistance: Minimizes deformation under mechanical stress at elevated temperatures.
-
Corrosion Resistance: Resists oxidation, scaling, and general corrosion in acidic/caustic environments.
-
Austenitic Structure: Non-magnetic, ductile, and easy to fabricate/weld.
-
H-Grade Compliance: Meets ASME Boiler and Pressure Vessel Code requirements for high-temperature use.
4. Chemical Composition (Typical % Weight):
| Element | Carbon (C) | Chromium (Cr) | Nickel (Ni) | Manganese (Mn) | Silicon (Si) | Phosphorus (P) | Sulfur (S) | Iron (Fe) |
|---|---|---|---|---|---|---|---|---|
| Content | 0.04–0.10 | 18.0–20.0 | 8.0–10.5 | ≤2.0 | ≤0.75 | ≤0.045 | ≤0.030 | Balance |
5. Mechanical Properties (Room Temperature):
-
Tensile Strength: ≥515 MPa (75 ksi)
-
Yield Strength (0.2% Offset): ≥205 MPa (30 ksi)
-
Elongation: ≥40% (in 50mm)
-
Hardness (Brinell): ≤201 HB
-
Density: 8.0 g/cm³
6. High-Temperature Performance:
-
Max Continuous Service Temp: 870°C (1600°F)
-
Max Intermittent Service Temp: 925°C (1700°F)
7. Available Forms & Dimensions:
-
Thickness: 3mm – 100mm (Custom sizes available)
-
Width: 1000mm, 1219mm (48"), 1500mm, 2000mm (Custom widths)
-
Length: 2000mm, 2438mm (96"), 3000mm, 6000mm (Custom lengths)
-
Form: Hot-Rolled (HR) or Cold-Rolled (CR) Plates
8. Surface Finishes:
-
Hot-Rolled: No.1, Scale-Free Annealed
-
Cold-Rolled: 2B (Standard Bright), BA (Mirror Bright), No.4 (Brushed), HL (Hairline)
-
Special: Pickled, Passivated, Sandblasted
9. Standards & Certifications:
-
ASTM A240/A240M, ASME SA-240
-
EN 10028-7: X6CrNi18-10
-
ISO 9445, JIS G4304
-
Material Test Certificates (MTC) per EN 10204 3.1/3.2
10. Applications:
-
Boiler & Pressure Vessel Components
-
Heat Exchangers & Condensers
-
High-Temperature Pipelines & Valves
-
Power Generation Systems (Gas Turbines)
-
Chemical Processing Equipment
-
Furnace Parts & Heat Treatment Fixtures
11. Fabrication Notes:
-
Welding: Use 308H or 347 filler metal; pre/post-weld heat treatment not typically required.
-
Machining: Low work-hardening rate allows good machinability (use sharp tools + coolants).
-
Forming: Excellent ductility supports bending, stamping, and deep drawing.
12. Packaging:
-
Wooden crates/pallets with waterproof wrapping.
-
Edge protectors and anti-rust paper for corrosion prevention.
Why Choose 304H Plate?
Ideal for critical applications demanding heat resistance + corrosion protection, 304H delivers unmatched reliability in extreme conditions. Its controlled carbon content prevents carbide precipitation during welding/heat exposure, ensuring long-term structural integrity.
Customization Options:
-
Precision cutting (waterjet, laser, plasma)
-
Beveled edges for welding
-
Non-standard dimensions & finishes
Contact us for quotes, technical specs, or material certifications!
