321 Stainless Steel Hot Rolled Plate Excellent Oxidation Resistance, ASTM Certified
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 321 / 1.4541 |
| Minimum Order Quantity | 500 kgs |
| Price | 2000 - 3200 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 321 / 1.4541 |
|---|---|---|---|
| Thickness | 3.0 - 80.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
Product Description
321 Stainless Steel Hot Rolled Plate Excellent Oxidation Resistance, ASTM Certified
Products Specification
| Products Name | 321 Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc |
| Thickness | 3.0 - 80.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
321 Stainless Steel Plate – Advanced Engineering Profile
- Designation: UNS S32100 / Werkstoff Nr. 1.4541
- Structure: Titanium-Stabilized Austenitic Steel
- Compliance: ASTM A240, EN 10088-3, ISO 9445
Properties & Benefits of 321 Stainless Steel Plate
-
Thermal Fatigue Resistance
Engineered to withstand repeated thermal cycling (e.g., rapid heating/cooling) without cracking, thanks to titanium’s carbide stabilization. Ideal for jet engine components and afterburner systems. -
Stress Corrosion Cracking (SCC) Mitigation
Superior resistance to chloride-induced SCC compared to 304/304L, validated per ASTM G36 testing in boiling MgCl₂ environments. -
Cryogenic Compatibility
Maintains ductility and toughness down to -320°F (-196°C), suitable for LNG storage and cryogenic piping.
Material Science Insights of 321 Stainless Steel Plate
-
Metallurgical Design
Titanium (Ti ≥ 5×C) binds carbon to form TiC, preventing chromium depletion at grain boundaries. Post-production stabilization annealing ensures homogeneous microstructure. -
Phase Stability
Retains austenitic structure even after prolonged high-temperature exposure, avoiding harmful sigma phase formation below 1600°F (870°C).
Performance Benchmarking
| Property | 321 Stainless | 304 Stainless | 316L Stainless |
|---|---|---|---|
| Max Service Temp | 1500°F (815°C) | 1400°F (760°C) | 1400°F (760°C) |
| Creep Strength | 18 MPa @ 1000°F | 12 MPa @ 1000°F | 14 MPa @ 1000°F |
| HCl Resistance | Good (≤10% conc.) | Poor | Moderate |
Advanced Applications of 321 Stainless Steel Plate
-
Aerospace: Combustion chamber liners, thrust reversers.
-
Semiconductor: CVD reactor chambers, wafer handling arms.
-
Renewable Energy: Concentrated solar power (CSP) receiver tubes.
-
Additive Manufacturing: Powder feedstock for high-temp 3D printed parts.
-
Defense: Hypersonic vehicle thermal protection subsystems.
Smart Manufacturing Options
-
Digital Twin Integration
-
Receive material certificates with QR codes linking to real-time batch analytics (melt chemistry, hot-rolling parameters).
-
-
AI-Optimized Cutting
-
AI-driven nesting software minimizes waste for complex geometries (≤0.5% scrap rate).
-
-
Surface Engineering
-
Laser texturing for controlled roughness (Ra 0.1–5.0 µm) or anti-fouling patterns.
-
Supply Chain Agility
-
Stock Availability:
-
Prime plates: 1/8" to 4" thickness (48" x 120" standard).
-
JIT delivery: Cut-to-size blanks within 72 hours (continental US/EU).
-
-
Custom Solutions:
-
Clad plates with Inconel 625 for extreme corrosion/erosion zones.
-
Pre-oxidized "Black Oxide" finish for enhanced emissivity in radiant heating.
-
Quality Protocols
-
Testing Suite:
-
Eddy current testing for sub-surface flaws.
-
Hydrogen embrittlement screening (ASTM F1940).
-
ASTM E112 grain size verification (7–8 ASTM scale).
-
-
Batch Tracking:
-
Blockchain-based traceability from EAF melt to final inspection.
-
Environmental Leadership
-
Carbon Footprint:
-
32% lower CO₂/kg vs. industry average (verified by EPD International).
-
-
Circular Economy:
-
Closed-loop recycling program: Return end-of-life plates for credit.
-
Technical Support:
-
Free FEM simulations for thermal stress analysis.
-
On-site weld procedure qualification (PQR/WPQ).
