Custom-Sized Forged Stainless Steel Plates Perfect for Welding Forming F321 Alloy
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Minimum Order Quantity | 500 kgs |
| Price | 1200-1400 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | SUS630 SUS631 |
|---|---|---|---|
| Thickness | 10.0 -150.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
| Highlight | Custom-Sized Stainless Steel Plates,Welding Stainless Steel Plates,F321 Alloy Stainless Steel Plates |
||
Product Description
Custom-Sized Forged Stainless Steel Plates Perfect for Welding & Forming F321 Alloy
Products Specification
| Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc |
| Thickness | 10 - 150.0mm |
| Width | 1250 -1500mm or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
Forged F321 Stainless Steel Plate – High-Temperature & Corrosion-Resistant Solution
1. Product Overview
Forged F321 stainless steel plate is a titanium-stabilized austenitic stainless steel (similar to 304 but with superior resistance to intergranular corrosion). The forging process enhances its mechanical strength, fatigue resistance, and structural integrity, making it ideal for high-stress, high-temperature applications.
2. Key Parameters & Chemical Composition
| Property | F321 (UNS S32100) |
|---|---|
| Standard | ASTM A182 / A240 / ASME SA182 |
| Composition | Cr: 17-19%, Ni: 9-12%, C: ≤0.08%, Ti: 5×C% min |
| Tensile Strength | ≥515 MPa (75 ksi) |
| Yield Strength | ≥205 MPa (30 ksi) |
| Elongation | ≥40% |
| Hardness | ≤192 HB (Annealed) |
| Density | 8.0 g/cm³ |
| Thermal Stability | Excellent (up to 800°C) |
| Corrosion Resistance | Resists oxidation, intergranular corrosion, and acidic environments |
3. Available Specifications
-
Thickness: 10mm – 300mm (custom forgings available)
-
Width: 1000mm – 2500mm (or as per requirement)
-
Length: 2000mm – 6000mm (or cut-to-size)
-
Surface Finish:
-
Forged & annealed
-
Machined, ground, or polished (No.1, 2B, BA)
-
Pickled or blasted (upon request)
-
4. Standards & Certifications
-
ASTM: A182 (Forged Fittings), A240 (Plates)
-
ASME: SA182, SA240
-
EN: 1.4541 (European Equivalent)
-
Other: NACE MR0175 (for sour service), PED 2014/68/EU
5. Key Features & Advantages
✔ Superior High-Temperature Performance – Resists carbide precipitation (due to Ti stabilization), ideal for 800°C+ environments.
✔ Enhanced Strength via Forging – Improved grain structure vs. cast/cold-rolled plates.
✔ Excellent Corrosion Resistance – Resists intergranular, pitting, and stress corrosion cracking (SCC).
✔ Weldability & Formability – Low carbon content minimizes sensitization during welding.
✔ Customizable – Available in different heat treatment conditions (annealed, solution-treated).
6. Typical Applications
-
Oil & Gas: Pressure vessels, heat exchangers, flare stacks
-
Chemical Processing: Reactors, piping, acid storage tanks
-
Aerospace: Exhaust systems, turbine components
-
Power Plants: Boilers, superheater tubes
-
Automotive: Exhaust manifolds, turbocharger parts
7. Packaging & Delivery
-
Standard Packaging:
-
Wooden crates + waterproof wrapping (for海运)
-
Steel strapping + edge protection (for heavy plates)
-
-
Custom Options:
-
VCI (Vapor Corrosion Inhibitor) coating for long-term storage
-
Labeling with heat numbers & material certs (MTC 3.1/3.2)
-
-
Export Compliance: ISO 10474, EN 10204 certification
8. Why Choose Our Forged F321 Plates?
- Strict Forging Process Control – Ensures uniform density & mechanical properties.
- Full Traceability – Mill test reports (MTR) with chemical & mechanical data.
- Competitive Pricing – Direct factory supply, no middlemen.
- Global Logistics Support – Fast delivery to EU, Americas, Middle East.
Contact us for quotes, technical data sheets (TDS), or custom dimensions!
SEO & Technical Notes:
-
Keywords: *"Forged 321 stainless steel plate supplier," "high-temperature F321 forged plate," "ASTM A182 F321 stainless steel."*
-
Add testing details (PMI, UT, hardness tests) if required.
-
Specify MOQ, lead time, or special certifications (e.g., NORSOK, DNV) if applicable.
Let me know if you need modifications!
