Nickel Alloy 718 Seamless Steel Pipe Tube DN10 - DN300 Custom Cutting Any Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Nickel Alloy 718 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Pipe | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | DN10 - DN300 | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 0.5 - 40.0mm |
| Highlight | DN300 Nickel Alloy Seamless Steel Pipe,DN10 Nickel Alloy Seamless Steel Pipe,Custom Cutting alloy 718 tube |
||
Product Description
Nickel Alloy 718 Seamless Steel Pipe Tube DN10 - DN300 Custom Cutting Any Length
Products Specification
|
Model
|
Nickel Tubes Pipes
|
|||
|
Material Grade
|
Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc |
|||
|
Diameter
|
a) Capillary Tube Outer Diameter: 0.2mm-6.mm
Welding Tube Outer Diameter: 6.mm- 840mm
Seamless Tube Outer Diameter: 6mm-630mm
|
|||
|
b) Capillary Tube Wall Thickness: 0.02mm-2mm
Welding Tube Wall Thickness: 0.5-150mm
Seamless Tube Wall Thickness: 0.5-60mm
|
||||
|
c) Length: ≤500mm Or in coil
|
||||
|
Tolerance
|
a) Outer Diameter: +/- 0.01mm
|
|||
|
b) Thickness: +/- 0.01mm
|
||||
|
c) Length: +/- 0.1mm
|
||||
|
Surface Treatment
|
Polishing,Annealing, Bright, Pickling
|
|||
|
Type
|
Welded,Seamless
|
|||
|
Shape
|
Round,Square,Irregular
|
|||
|
Application
|
medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.
|
|||
Inconel 718 Nickel Alloy 718 Tube
Alloy 718 is a high-strength, corrosion-resistant nickel chromium material used at -423° to 1300°F.
The age-hardenable alloy can be readily fabricated, even into complex parts. Its welding characteristics,
especially its resistance to postweld cracking, are outstanding.
The ease and economy with which Alloy 718 can be fabricated, combined with good tensile, fatigue, creep,
and rupture strength, have resulted in its use in a wide range of applications
Nickel (plus Cobalt) .......................................................................50.00-55.00
Chromium......................................................................................17.00-21.00
Iron ...............................................................................................Balance*
Niobium (plus Tantalum)................................................................4.75-5.50
Molybdenum .................................................................................2.80-3.30
Titanium.........................................................................................0.65-1.15
Aluminum ......................................................................................0.20-0.80
Cobalt ..........................................................................................1.00 max.
Carbon..........................................................................................0.08 max.
Manganese ..................................................................................0.35 max.
Silicon ..........................................................................................0.35 max.
Phosphorus..................................................................................0.015 max.
Sulfur............................................................................................0.015 max.
Boron ...........................................................................................0.006 max.
Copper...........................................................................................0.30 max.
| Yield Strength (Mpa) |
Tensile Strength (Mpa) |
Elongation (%) |
Reduction (%) |
Hardness (HRC) |
Charpy Impact (J) |
||||||
| 1034 | 1270 | 12 | 15 | 331 |
Alloy 718 has excellent corrosion resistance to many media. This resistance,
which is similar to that of other nickel-chromium alloys, is a function of its composition.
Nickel contributes to corrosion resistance in many inorganic and organic, other than strongly oxidizing,
compounds throughout wide ranges of acidity and alkalinity.
It also is useful in combating chloride-ion stress-corrosion cracking.
Chromium imparts an ability to withstand attack by oxidizing media and sulfur compounds.
Molybdenum is known to contribute to resistance to pitting in many media.
Type and Grade of our Nickel Alloy Pipe
1. Inconel Alloy (Inconel718,Inconel 625,Inconel 725,InconelX-750,
Inconel600,Inconel690,Inconel601 Inconel 617ect)
2. Incoloy Alloy (Incoloy 825,Incoloy 800,Incoloy800H,Incoloy800HT,
Incoloy901,incoloyA-286, Incoloy925/926,etc)
3. Cobalt-based Superalloy(Hayness188/GH5188,Hayness25/ Alloy L605,Co50,etc)
4. Precision alloys(Ni36,4J29,1J79,4J42,4J50,1J22)
5. Hastelloy alloy(Hastelloy C-276,Hastelloy B,HastelloyG30,HastelloyB3,
HastelloyC-22 HastelloyX, Hastelloy C-4)
6. Monel alloy (Monel400,MonelK500)
7. Permalloy alloy(1J79.1J85)
8. Nimonic Alloys (Nimonic 90, Nimonic 80A, Nimonic 75 ,Nimonic 60)
9.Waspaloy Alloy and other Material
