1500mm 2000mm Width 904L Stainless Steel Plates Hot Rolled Alloy 904L Plates
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 904L |
| Minimum Order Quantity | 500 kgs |
| Price | 2100-2500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 904L |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | ASTM A240/240M |
| Loading Port | Shanghai Port | Thickness | 1.0 - 30.0mm |
| Highlight | Hot Rolled 904L Stainless Steel Plates,2000mm Stainless Steel Plates,1500mm Stainless Steel Plates |
||
Product Description
Products Specification
| Product name | 904L Stainless Steel Plate |
| Standard | GB,JIS,DIN,AISI,ASTM,AISI,ASME |
| Thickness | 1.0- 30.0mm |
| Width | 1219 ,1500mm, or as your requirements |
| Length | 3000,6000mm, or as your requirements |
| MOQ | 1MT |
| Surface | 2B NO.1 HL NO.4 8K,checkered |
| Other Grade |
201 304 304L 309S 310S 316L 317L 316LN 321 347 329 409L 410 415 416 420 430 431 436L 439 440A/B/C 444 446 904L 2205 2507 254SMO 253MA ,1.4529,1.4828 Monel400 k500, Inconel 600,601,625,718, Incoloy 800 800H,C276.etc |
| Packing | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
| Cargo ready date | within 25-35 days after confirming orders |
| Delivery Time | About 5-7 days after receive the deposit. |
ASTM SAE AISI 904L Stainless Steel (UNS N08904)
AISI 904L stainless steel (UNS N08904) is a high alloy austenitic stainless steel. Compared with 316L, SS904L has lower carbon (C) content, higher chromium (Cr) content, and approximatively twice the nickel (Ni) and molybdenum (Mo) content of 316L, which makes it have higher high temperature oxidation resistance, pitting resistance, and resistance to reducing acid (eg, sulfuric acid). Nitrogen (N) can reduce the rate of chromium carbide precipitation, thereby reducing the sensitivity of sensitization, it also improve the resistance to pitting and crevice corrosion caused by chlorides. Especially its addition of copper (Cu) makes it useful for all concentrations of sulfuric acid.
Chemical Composition
The following data sheet gives SS 904L stainless steel chemical composition.
| ASTM | UNS | Type | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | Mo | N, ≤ | Cu |
| ASTM A276/A276M | UNS S08904 | 904L | 0.02 | 1.00 | 2.00 | 0.045 | 0.030 | 19.0-23.0 | 23.0-28.0 | 4.0-5.0 | 0.10 | 1.0-2.0 |
| ASTM A240/A240M |
904L Stainless Steel Plate Specification
0.8mm 904L Stainless Steel Sheet,1.0mm 904L Stainless Steel Sheet,1.2mm 904L Stainless Steel Sheet,1.5mm 904L Stainless Steel Sheet,2.0mm 904L Stainless Steel Sheet,2.5mm 904L Stainless Steel Sheet,3.0mm 904L Stainless Steel Sheet,4mm 904L Stainless Steel Plate,5mm 904L Stainless Steel Plate,6mm 904L Stainless Steel Plate,8mm 904L Stainless Steel Plate,10mm 904L Stainless Steel Plate,12mm 904L Stainless Steel Plate,14mm 904L Stainless Steel Plate,16mm 904L Stainless Steel Plate,18mm 904L Stainless Steel Plate,20mm 904L Stainless Steel Plate,22mm 904L Stainless Steel Plate,25mm 904L Stainless Steel Plate,30mm 904L Stainless Steel Plate,32mm 904L Stainless Steel Plate,35mm 904L Stainless Steel Plate,40mm 904L Stainless Steel Plate,1500mm width 904L Stainless steel plate,2000mm width 904L Stainless steel plate,1219mm width 904L Stainless steel plate,1000mm width 904L Stainless steel plate,ASTM A240 904L Stainless steel plate
Typical physical properties of grade 904L stainless steels
| Grade | Density | Elastic Modulus | Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity | Specific Heat 0-100°C | Elec Resistivity | |||
| (kg/m3) | (GPa) | (W/m.K) | (J/kg.K) | (nΩ.m) | |||||
| - | - | 0-100°C | 0-315°C | 0-538°C | At 20°C | At 500°C | |||
| 904L | 7900 | 190 | 15 | - | - | 11.5 | - | 500 | 952 |
