Alloy 904L / UNS N08904 / 1.4539 Stainless Steel Plate Laser Cutting Any Shape For Chemial Area
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 904L / 1.4539 |
| Minimum Order Quantity | 500 kgs |
| Price | 2100-2500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 904L / 1.4539 |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | ASTM A240/240M |
| Loading Port | Shanghai Port | Thickness | 0.6 - 30.0mm |
| Highlight | 1.4539 Stainless Steel Plate,Alloy 904L Stainless Steel Plate,UNS N08904 Stainless Steel Plate |
||
Product Description
Alloy 904L / UNS N08904 / 1.4539 Stainless Steel Plate Laser Cutting Any Shape for Chemial Area
Products Specification
| Product name | 904L / 1.4539 Stainless steel plate |
| Standard | GB,JIS,DIN,AISI,ASTM,AISI,ASME |
| Thickness | 0.6 - 30.0mm |
| Width | 1219 ,1500mm, or as your requirements |
| Length | 3000,6000mm, or as your requirements |
| MOQ | 1MT |
| Surface | 2B NO.1 HL NO.4 8K |
| Other Grade |
201 304 304L 309S 310S 316L 317L 316LN 321 347 329 409L 410 415 416 420 430 431 436L 439 440A/B/C 444 446 904L 2205 2507 254SMO 253MA ,1.4539,1.4828 Monel400 k500, Inconel 600,601,625,718, Incoloy 800 800H,C276.etc |
| Packing | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
| Cargo ready date | within 25-35 days after confirming orders |
| Delivery Time | About 5-7 days after receive the deposit. |
Standard Specification of 904L Stainless Steel Plate
|
Country |
North America |
Russia |
Japan |
United Kingdom |
Europe |
Russia |
France |
America |
Australia |
United States |
America |
United States |
Australia |
German |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
STANDARD |
UNS |
WERKSTOFF NR. |
JIS |
BS |
EN |
GOST |
AFNOR |
ASTM |
ASME |
AMS |
ANSI |
SAE |
AS |
DIN |
|
SS 904L |
N08904 |
1.4539 |
SUS 904L |
904S13 |
X1NiCrMoCu25-20-5 |
STS 317J5L |
Z2 NCDU 25-20 |
ASTM A240 |
ASME SA -240 |
AMS 5511 |
ANSI SS 904L |
SAE SS 904L |
– |
1.4539 |
|
Grade |
Density (kg/m3) |
Melting point |
Elastic modulus (GPa) |
Electric resistivity (nΩ.m) |
|---|---|---|---|---|
|
904L |
7.95 g/cm3 |
1350 °C (2460 °F) |
200 |
850 |
|
Grade |
Mean Co-eff of thermal expansion (µm/m/°C) |
Thermal conductivity (W/m.K) |
Specific heat 0-100°C (J/kg.K) |
|||
|---|---|---|---|---|---|---|
|
0-100°C |
0-315°C |
0-538°C |
At 20°C |
At 500°C |
||
|
904L plate |
15 |
– |
– |
13 |
– |
500 |
|
Grade |
Yield strength 0.2% Proof (MPa) min |
Tensile strength (MPa) min |
Elongation (% in 50mm) min |
Hardness |
|
|---|---|---|---|---|---|
|
Rockwell B (HR B) |
Brinell (HB) |
||||
|
904L plate |
220 |
490 |
35 |
70-90 typical |
– |
The SS 904l stainless steel plate is a non-stabilized austenitic stainless steel grade. A 904l Stainless Steel Sheet is designed with a superior chemical composition of chromium, nickel, molybdenum, and other alloys. The versatile 904l Sheet is a thin metal grade designed with superior resistance to corrosive and oxidative media. The DIN 1.4539 Flat Sheet has good tolerance to chloride stress corrosion cracking. They also have good resistance to pitting in harsh environments. The 904L SS Rolling Sheets are designed in sizes between 0.5mm to 6mm. The robust sheets are utilized in applications that don’t require higher strength and stability like the 904l Stainless Steel Plate.
The versatile 904L stainless steel sheet has a smooth surface finish and tolerances. These sheets are designed with excellent mechanical properties. The 904L Stainless Rolling Plate has a minimum yield strength of 220mpa with a minimum tensile strength of 490mpa. The robust ASTM A240 UNS N08904 Strips can be elongated by 36% in the system. However, the strips have a hardness between 70-90 Rockwell B. The Stainless Steel 904L Coil can be easily welded and processed following shop fabrication procedures.
Material equivalent stainless steel 904L coil
904L stainless rolling plate physical properties
Thermal properties of DIN 1.4539 flat sheet
Mechanical properties of ASTM A240 UNS N08904 stripsStainless Steel 904L Plate Value Added Services
- Cladding
- Heat Treatment
- Annealed
- Pickling, Polish
- Rolling
- Cutting
- Bending
- Forging
- Minor Fabrication Etc.
