Heat Resistant Alloy 1.4828 Stainless Steel Sheet Plate Coils AISI309S SS Sheet EN10095
Product Details
| Products | Stainless Steel Plate | Grade | 1.4828 |
|---|---|---|---|
| Width | 1500mm 1219mm 1000mm | Surface | NO.1 2B |
| Brand | POSCO TISCO BAOSTEEL | Standard | EN 10095:1999 |
| Loading Port | Shanghai Port | Thickness | 0.4 - 20.0mm |
| Highlight | Heat Resistant Alloy Stainless Steel Sheet,AISI309S Stainless Steel Sheet,EN10095 Stainless Steel Sheet |
||
Product Description
Heat Resistant Alloy 1.4828 Stainless Steel Sheet Plate Coils AISI309S SS Sheet EN10095
Products Specification
| Product name | 1.4828 Stainless steel Sheet / plate |
| Standard | EN 10095:1999 |
| Thickness | 0.4 - 20.0mm |
| Width | 1219, 1500mm, or as your requirements |
| Length | 2438, 3000,6000mm, or as your requirements |
| MOQ | 1MT |
| Surface | 2B NO.1 |
| Packing | standard export packing (inside:water proof paper,outside:steel covered with strips and pallets) |
| Similar Grade We Can Supply | 321, 310S |
| Delivery Time | About 5-7 days after receive the deposit. |
Regular Size of 1.4828 Stainless Steel Sheet / Plate in Stock
| 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm | 0.8*1219*2438mm |
| 1.0*1219*2438mm | 1.2*1219*2438mm | 1.5*1219*2438mm | 2.0*1219*2438mm |
| 2.5*1219*2438mm | 3.0*1219*2438mm | 4.0*1500*6000mm | 5.0*1500*6000mm |
| 6.0*1500*6000mm | 8.0*1500*6000mm | 10.0*1500*6000mm | 12.0*1500*6000mm |
| 14.0*1500*6000mm | 16.0*1500*6000mm | 20.0*1500*6000mm |
austenitic stainless steel 1.4828 AISI 309 UNS S30900 is a steel suitable for high-temperature applications. With a maximum service temperature in air of 1,000°C in fact, this heat-resistant austenitic stainless steel offers excellent corrosion resistance to oxidation and carbonization. Its characteristics make it ideal for making industrial furnace and boiler components, expansion tubes and bellows, electrical heating elements, aeronautical engineering, and automotive exhaust systems.
CHEMICAL COMPOSITION Werkstoff 1.4828 AISI 309 UNS S30900
| Element | Min | Max |
|---|---|---|
| C | — | 0.20 |
| S | — | 0.015 |
| P | — | 0.045 |
| Yes | 1.50 | 2.00 |
| Mn | — | 2.00 |
| Cr | 19.00 | 21.00 |
| Ni | 11.00 | 13.00 |
| N | — | 0.11 |
MECHANICAL FEATURES 1.4828 AISI 309 UNS S30900
| Material | League | Rm min (MPa) | Rp 0.2 min (MPa) | A% min | Z% min | Hardness max (HB) |
|---|---|---|---|---|---|---|
| AISI 309 | 1.4828 | 500 – 750 | 230 | 30 | 55 | 220 |
PHYSICAL PROPERTIES1.4828 AISI 309 UNS S30900
- Specific gravity: 7.9 kg/dm³ at 20°C
- Modulus of elasticity: 206,000 N/mm² at 20°C
- Thermal conductivity: 15 W/m.K at 20°C
- Specific heat: 500 J/g.K at 20°C
- Coefficients of linear expansion: 16.5 (20° – 200°C), 17.5 (20° – 400°C), 18.0 (20° – 600°C)
- Electrical resistivity: 0.85 Ω mm²/m at 20°C
- Amagnetic
CORRESPONDENCE AND SPECIFICATIONS 1.4828 AISI 309 UNS S30900
- EN 10095: X15 Cr Ni Si 20-12
- W: 1.4828
- JIS: SUH309
- AISI: 309
- UNS: S30900
Applications of 1.4828 Stainless Steel
- Industrial furnaces and boiler components
- Tubes and expansions bellows
- Electrical heating elements
- Aeronautical engineering
- Automotive exhaust systems
