Duplex S32550 Stainless Steel Plate Duplex 255 Alloy Width 1500mm 2000mm ASTM A240
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | UNS S32550 / Alloy 255 |
| Minimum Order Quantity | 1 Ton |
| Price | 2800-3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Stainless Steel Plate | Grade | UNS S32550 / Alloy 255 |
|---|---|---|---|
| Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm 2000mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | Duplex 255 Alloy Stainless Steel Plate,2000mm Stainless Steel Plate,ASTM A240 Stainless Steel Plate |
||
Product Description
Duplex S32550 Stainless Steel Plate Duplex 255 Alloy Width 1500mm 2000mm ASTM A240
Products Specification
| Product Name | Duplex S325502205 stainless steel sheet |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, etc. |
| Thickness | 0.5-30.0mm |
| Length | 2000mm, 2438mm, 3000mm, 5800mm, 6000mm, etc. |
| Surface | BA/2B/NO. 1/NO.4/8K/HL |
| Stock or not | enough stock |
| Quality test | Mill Test Certificate is supplied with shipment, Third Part Inspection is acceptable |
| Payment terms | L/C T/T (30%DEPOSIT) |
| Sample | Provided Freely |
| Container Size | 20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC: 12032mm(Length)x2352mm(Width)x2698mm(High) |
| Delivery time | Within 7-15 Working Days |
Standard Size of our S32550 Duplex Stainless Steel Plate in Stock
| Cold Rolled S32550 duplex stainless steel sheet | ||||
| 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm | 0.8*1219*2438mm | 1.0*1219*2438mm |
| 1.2*1219*2438mm | 1.5*1219*2438mm | 2.0*1219*2438mm | 2.5*1219*2438mm | 3.0*1219*2438mm |
| Hot Rolled S32550 duplex stainless steel plate | ||||
| 3.0*1500*6000mm | 4.0*1500*6000mm | 5.0*1500*6000mm | 6.0*1500*6000mm | 8.0*1500*6000mm |
| 10.0*1500*6000mm | 12.0*1500*6000mm | 14.0*1500*6000mm | 16.0*1500*6000mm | 20.0*1500*6000mm |
| 6.0*2000*6000mm | 8.0*2000*6000mm | 10.0*2000*6000mm | 12.0*2000*6000mm | 14.0*2000*6000mm |
| 16.0*2000*6000mm | ||||
UNS S32550 a highly superduplex solid solution trengthened alloy, it contains both austenitic and ferritic crystal structures, which provides high strength and wear resistance while offering superior corrosion resistance compared to 316 stainless steel. UNS S32550 Duplex Steel Plate offers superior resistance to pitting and crevice corrosion, stress corrosion cracking, and corrosion fatigue.
UNS S32550 Equivalent Grade Designation
- 2507 Cu
- ALLOY 255
- DIN EN 1.4507
- X2CrNiMoCuN25-6-3
- FERRALIUM 255
Super Duplex stainless steel UNS S32550 Chemical Composition
| Grade | C≤ | Mn≤ | P≤ | S≤ | Si≤ | Ni | Cr | Mo | N | Cu | Fe |
| UNS S32550 | 0.025 | 0.80-1.20 | 0.025 | 0.005 | 0.7 | 4.50-6.50 | 24.00-27.00 | 2.90-3.90 | 0.10-0.25 | 1.50-2.50 | Bal |
FERRALIUM 255 UNS S32550 Mechanical Properties
| Yield 0.2 % ( ksi/Mpa), Min | Tensile (ksi/Mpa), Min | Elongation ( % in 50mm ), Min | Reduction in Area, % | Hardness (HB), Max |
| 550 | 750 | 25 | 55 | 290 |
ALLOY 255 UNS S32550 Physical Properties
| Density ( Kg/m3 ) | Elastic Modulus ( Gpa ) | Co-eff of Expansion ( µm/m/°C | Thermal Condc. (W/m.K) | Electric Resistivity (nΩ.m) |
| 7850 | 200 | 14.5 | 19 | 850 |
Application of Duplex S32550 Stainless Steel Plate
UNS S32550 Duplex Steel Plate is used in a variety of industries, including oil and gas, chemical processing, and marine engineering. It is commonly used for applications that require high strength, resistance to corrosion, and an ability to withstand harsh environments:
- Oil and Gas industry equipment
- Chemical process industries
- Marine Industry and Shipbuilding
- Pollution Control
- Pulp and Paper Industry
- Food Industry
- Civil Engineering
