12Cr1MoV Alloy Steel Plate Thickness 3.0 - 200mm Hot Rolled ASTM GB EN DIN Standard
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO 9001 |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 500 kgs |
| Price | 550 - 850 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Steel Plate | Thickness | 3.0 - 200.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Material | Carbon Steel, Alloy Steel, Stainless Steel |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | Hot Rolled alloy steel plate,12Cr1MoV alloy steel plate,Alloy Steel Plate Thickness 3mm |
||
Product Description
12Cr1MoV alloy steel plate Thickness 3.0 - 200mm Hot Rolled ASTM GB EN DIN Standard
12Cr1MoV steel is a low-alloy steel known for its excellent high-temperature strength, corrosion resistance, and ability to withstand high pressure. Due to these properties, it is widely used in industries like power generation, petrochemicals, and boilers. This article explores the key features, applications, and benefits of 12Cr1MoV steel plates.
Products Specification of our plate
|
Products
|
Alloy Steel Plate | |
|
Specification |
Length
|
2000mm, 2438mm, 3000mm, 3500mm,6000mm, 12000mm,or rolled,etc etc
|
|
Thickness
|
3.0 - 200mm,etc
|
|
|
Width
|
1000-2500mm or cutting any width as request
|
|
|
Material
|
Q235,Q255,Q275,SS400,A36,SM400A,St37-2,SA283Gr,S235JR,S235J0,S235J2,1cr6si2mo,1cr5mo,15crmo,12cr1mov,15cdv6
|
|
|
Standard
|
ASTM,AISI,JIS,GB, DIN,EN
|
|
|
Technique
|
Hot rolled / cold rolled
|
|
|
Surface
|
Black Finish ,Oiled,Shot Blasted,Spray Paint,Coated,Galvanized,Or as Your Request
|
|
|
Package
|
standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
|
|
|
Payment Term
|
T/T, L/C at sight,West Union,Paypal
|
|
|
Price Term
|
FOB,CRF,CIF,EXW all acceptable
|
|
12Cr1MoV alloy steel plate creep very close to the limit with lasting strength value with high ductility, and in the case of persistent stretching. Process resistance and weldability of the steel is good, but before welding was preheated to 300 °C, required after welding stress-relief processing.
12Cr1MoV alloy steel plate chemical composition:
| Grade | C | SI | MN | CR | MO | V |
| 12Cr1MoV | 0.07～0.15 | 0.18～0.37 | 0.41～0.70 | 0.90～1.20 | 0.25～0.35 | 0.15～0.30 |
12Cr1MoV alloy steel plate Mechanical properties:
- Tensile strength σb (MPa): ≥440 (45)
- Yield strength σs (MPa): ≥ 225 (23)
- Elongation δ5 (%): ≥22
- Reduction in area ψ (%): ≥50
- Impact energy Akv (J): ≥78
- Impact toughness value αkv (J/cm2): ≥98 (10)
- Brinell Hardness (HBS100/3000) (annealed or high temperature tempered): ≦241
12Cr1MoV alloy steel Heat Treatment Specification and Organization:
Heat treatment specifications:
- Quenching heating temperature (°C): 970; coolant: empty
- Tempering heating temperature (°C): 750; coolant: empty
12Cr1MoV alloy steel plate application:
12Cr1MoV alloy structural steel is mainly used after normalizing and high temperature tempering to produce superheated steel tubes, conduits, serpentine tubes and other corresponding forgings whose operating temperature does not exceed 570-585°C.
Our Service
1.Additional Condition: UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
2.Shipping department: a).Book shipping space b).Documents confirmation c).Shipping track d).Shipping case
3.Production control department: a).Technical evaluation b).Production Schedule c).Production Tracking d).Successfully complaint case
4.Quality control: a).Test in mill b).Inspection before Shipment c).Third Party Inspection d).About Package problem e).Quality problem case
5.Customers’ feedback and complaint: a).Quality feedback b).Service feedback c).Complaint d).Case
