Alloy 2205 Duplex Stainless Steel Plate Alloy S31803 S32205 EN 1.4462 Duplex Alloy Plate
| Place of Origin | China |
|---|---|
| Brand Name | TISCO POSCO BAOSTEEL |
| Certification | ISO |
| Model Number | 2205 / 1.4462 / UNS S32205 / UNS S31803 |
| Minimum Order Quantity | 1 Ton |
| Price | 2500-3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Stainless Steel Plate | Grade | 2205 / 1.4462 / UNS S32205 / UNS S31803 |
|---|---|---|---|
| Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | EN 1.4462 Duplex Stainless Steel Plate,Alloy 2205 Duplex Stainless Steel Plate,Alloy S31803 Duplex Stainless Steel Plate |
||
Product Description
Alloy 2205 Duplex Stainless Steel Plate Alloy S31803 S32205 EN 1.4462 Duplex Alloy Plate
Products Specification
| Item | Alloy 2205 duplex stainless steel plate |
| Standard | ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc |
| Surface |
2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror ,brushcheckered ,embossed,hair line, sand blast,etching,etc |
| Thickness | 0.1~200mm |
| Width | 1000mm,1219mm,1500mm,1800mm,2000mm,etc |
| Length | 2000mm,2440mm,3000mm,5800mm,6000mm,etc |
| Package | Standard export package,suit for all kinds of transport,or as required. |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc |
| Payment term | TT,L/C,Western Union |
2205(UNS S32205,EN 1.4462)stainless steel plates are divided into cold-rolled plates and hot-rolled plates. Common size Thickness: 3.0mm-10.0mm, width has two kinds of width: 1800mm and 2000mm. Length: 6000mm or more (can be cut according to customer requirements). 2205 stainless steel alloy is a duplex stainless steel composed of 21% chromium, 2.5% molybdenum and 4.5% nickel-nitrogen alloy. Conventional size thickness: 0.5mm-40.0mm, width: 1000mm, 1219mm, 1500, 1800mm, 2000mm, 2500mm, etc.; length: generally cold rolled 2000mm or 2438mm, hot Rolled to 6000mm.
Standard Size of our 2205 Duplex Stainless Steel Plate in Stock
| Cold Rolled 2205 duplex stainless steel sheet | ||||
| 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm | 0.8*1219*2438mm | 1.0*1219*2438mm |
| 1.2*1219*2438mm | 1.5*1219*2438mm | 2.0*1219*2438mm | 2.5*1219*2438mm | 3.0*1219*2438mm |
| Hot Rolled 2205 duplex stainless steel plate | ||||
| 3.0*1500*6000mm | 4.0*1500*6000mm | 5.0*1500*6000mm | 6.0*1500*6000mm | 8.0*1500*6000mm |
| 10.0*1500*6000mm | 12.0*1500*6000mm | 14.0*1500*6000mm | 16.0*1500*6000mm | 20.0*1500*6000mm |
| 6.0*2000*6000mm | 8.0*2000*6000mm | 10.0*2000*6000mm | 12.0*2000*6000mm | 14.0*2000*6000mm |
| 16.0*2000*6000mm | ||||
205 Duplex Stainless Steel Plate Chemical Analysis
Typical Values (Weight %)
| Carbon | Chromium | Nickel | Molybdenum | Nitrogen | Others |
|---|---|---|---|---|---|
| 0.020 | 22.1 | 5.6 | 3.1 | 0.18 | S=0.001 |
| PREN = [Cr%] = 3.3 [Mo%] = 16 [N%] ≥ 34 | |||||
2205 Duplex Stainless Steel Plate Mechanical Properties at Room Temperature
| ASTM A 240 | Typical | |
|---|---|---|
| Yield Strength 0.2%, ksi | 65 min. | 74 |
| Tensile Strength, ksi | 90 min. | 105 |
| Elongation, % | 25 min. | 30 |
| Hardness RC | 32 max. | 19 |
2205 Duplex Stainless Steel Plate Tensile Properties at Elevated Temperatures
| Temperature °F | 122 | 212 | 392 | 572 |
|---|---|---|---|---|
| Yield Strength 0.2%, ksi | 60 | 52 | 45 | 41 |
| Tensile Strength, ksi | 96 | 90 | 83 | 81 |
2205 Duplex Stainless Steel Plate APPLICATIONS:
-
Chemical processing, transport and storage – pressure vessels, tanks, piping, and heat exchangers
-
Oil and gas exploration and processing equipment – piping, tubing, and heat exchangers
-
Marine and other high chloride environments
-
Effluent scrubbing systems
-
Pulp and paper industry – digesters, bleaching equipment, and stock-handling systems
-
Cargo tanks for ships and trucks
-
Food processing equipment
-
Biofuels plants
FAQ
Q. What are your company's main products ?
A: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q. How do you control quality ?
A: Mill Test Certification is supplied with shipment, Third Party Inspection is available.
Q. What are the advantages of your company ?
A: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q. Can you provide sample ?
A: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7days
