Duplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS Plate
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 2205 / 1.4462 / UNS S32205 / UNS S31803 |
| Minimum Order Quantity | 1 Ton |
| Price | 2500-3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Stainless Steel Plate | Grade | 2205 / 1.4462 / UNS S32205 / UNS S31803 |
|---|---|---|---|
| Thickness | 0.6-30.0mm | Standard | ASTM EN GB |
| Width | 1000mm 1219mm 1500mm | Surface | 2B NO.1 |
| Brand | TISCO BAOSTEEL | MOQ | 1 Ton |
| Highlight | 10mm Duplex 2205 Stainless Steel Plate,12mm Duplex 2205 Stainless Steel Plate,16mm Duplex 2205 Stainless Steel Plate |
||
Product Description
Duplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS Plate
Products Specification
| Products Name | duplex stainless steel plate |
| Grade | 2205 / S31803 / S32205 / 1.4462 |
| Thickness | Cold Rolled 0.6 - 3.0mm , Hot Rolled 3.0 - 80.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm |
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm 1800*6000mm 2000*6000mm or cutting as request |
| Brand | POSCO TISCO BAOSTEEL JISCO ESS |
| Other Grade | 304 316L 309S 310S 321 347 2507 904L 254SMO.etc |
| Service | Cutting |
Standard Size of our 2205 Duplex Stainless Steel Plate in Stock
| Cold Rolled 2205 duplex stainless steel sheet | ||||
| 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm | 0.8*1219*2438mm | 1.0*1219*2438mm |
| 1.2*1219*2438mm | 1.5*1219*2438mm | 2.0*1219*2438mm | 2.5*1219*2438mm | 3.0*1219*2438mm |
| Hot Rolled 2205 duplex stainless steel plate | ||||
| 3.0*1500*6000mm | 4.0*1500*6000mm | 5.0*1500*6000mm | 6.0*1500*6000mm | 8.0*1500*6000mm |
| 10.0*1500*6000mm | 12.0*1500*6000mm | 14.0*1500*6000mm | 16.0*1500*6000mm | 20.0*1500*6000mm |
| 6.0*2000*6000mm | 8.0*2000*6000mm | 10.0*2000*6000mm | 12.0*2000*6000mm | 14.0*2000*6000mm |
| 16.0*2000*6000mm | ||||
Chemical Composition:
Stainless steel plate is an austenitic stainless steel that has a composition of chromium, nickel, and manganese. Its chemical composition is as follows:
| Grade | Chemical Composition (%) | |||||||
| c | si | Mn | P | s | Ni | Cr | Mo | |
| 201 | ≤0.15 | ≤0.75 | 5.5-7.5 | ≤0.06 | ≤ 0.03 | 3.5-5.5 | 16.0-18.0 | - |
| 301 | ≤0.15 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 6.0-8.0 | 16.0-18.0 | - |
| 304 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-10.5 | 18.0-20.0 | - |
| 304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | - |
| 316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
| 316Ti | ≤0.08 | ≤0.75 | ≤2.0 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
| 310S | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.045 | ≤0.03 | 19-22 | 24-26 | |
| 316L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 16 .0-1 8.0 | 2.0-3.0 |
| 321 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.013 | 17.0-1 9.0 | - |
| 405 | ≤0.08 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.6 | 11.5-14.5 | |
| 409 | ≤0.08 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.6 | 11.5-14.5 | |
| 409L | ≤0.08 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.6 | 11.5-14.5 | |
| 410 | ≤0.15 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | - | 11.5-13.5 | - |
| 430 | ≤0.12 | ≤0.75 | ≤1.0 | ≤0.040 | ≤ 0.03 | ≤0.60 | 16.0-18.0 | - |
| 420 | ≤0.05 | ≤1.0 | ≤1.0 | ≤0.04 | ≤0.03 | 0.75 | 12-14 | 0.5 |
| 430 | ≤0.12 | ≤1.0 | ≤1.0 | ≤0.04 | 0.03 | 0.5 | 16-18 | 0.75 |
| 444 | ≤0.025 | ≤1.0 | ≤1.0 | ≤0.04 | 0.03 | 1 | 17.5-19.5 | 1.75-2.5 |
| 904L | ≤0.02 | ≤1.0 | ≤2.0 | ≤0.045 | 0.035 | 23-28 | 19-23 | 4.0-5.0 |
| 2205 | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.03 | 0.02 | 4.5-6.5 | 22.0-23.0 | 3.0-3.5 |
| 2507 | ≤0.03 | ≤0.8 | ≤1.0 | ≤0.035 | 0.02 | 6.0-8.0 | 24-26 | 3.0-5.0 |
Thickness and Width:
The thickness and width of stainless steel plates can vary according to specific needs and applications. Generally speaking, the thickness of stainless steel plates can range from a very thin few millimeters to tens of millimeters, and the width is usually between tens of millimeters and several meters.
We can provide different specifications and sizes of stainless steel plates, and can choose the appropriate thickness and width according to the specific needs.
2205 stainless steel plate
| Item | 2205 Stainless Steel Plate (Hot rolled, cold rolled) |
| Standard | ASTM A240/A480M, ASTM B443/SB443, ASTM B625, B709, B618, B435, ASTM A480, A895, A693, DIN 10088, EN 10028, JIS G4304, JIS G4305, etc. |
| Thickness | Hot Rolled ( 3.0-300mm) Cold Rolled (0.3-16mm) |
| Width | 1000-3000mm |
| Length | Any as your requirements 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Material | 302, 301,310S, 310, 309, 309S, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 304, 304L,etc. |
| Specification | Cold Rolled: 1219mm * 2438mm (4′ x 8′), 1219mm * 3048mm (4′ x 10′), 1220mm * 2440mm, 1250mm * 2500mm or as your requirement. |
| Hot rolled: 1500mm * 2000mm, 1000mm * 3000mm, 1500mm * 4000mm, 1500m * 6000mm or as your requirement. | |
| Surface |
2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching, etc
|
| Value Added Services | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| MTC | Mill Test Certificate, Available as per EN 10204 3.1 |
| Package | Standard Export Seaworthy Package, or as required. |
Hot Rolled and Cold Rolled
Stainless steel plate can be manufactured using either hot rolled or cold rolled techniques. Hot rolling involves heating the steel above its recrystallization temperature and then passing it through rollers to form the desired shape. Cold rolling, on the other hand, involves passing the steel through rollers at room temperature to reduce its thickness.
Different Finishes
Stainless steel plate comes in different finishes that can affect its appearance and properties. Here are some common finishes:
| Different Finishes |
| 2B: This is a smooth, reflective finish that is produced by cold rolling followed by annealing and descaling. |
| No.1: This is a rough, dull finish that is produced by hot rolling followed by annealing and pickling. |
| SB: This is a satin finish that is produced by applying a fine abrasive material to the surface of the steel. |
| BA: This is a bright, mirror-like finish that is produced by buffing the surface of the steel with a fine abrasive material. |
| HL: This is a hairline finish that is produced by brushing the surface of the steel with a fine abrasive material. |
| Mirror: This is a highly reflective finish that is produced by polishing the surface of the steel with a very fine abrasive material. |
